This document was generated on 01/27/2015
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Overview:
Description:
74712-4002
Active
Ganged RF
6.25mm Pitch Ganged RF Header, Vertical, 8 Circuits
Documents:
Drawing (PDF)
Product Specification PS-74854-001 (PDF)
Packaging Specification PK-74712-001 (PDF)
RoHS Certificate of Compliance (PDF)
Series
LR19980
E107635
image - Reference only
EU RoHS
RoHS Compliant by
Exemption
REACH SVHC
Not Reviewed
Low-Halogen Status
Not Reviewed
China RoHS
Agency Certification
CSA
UL
General
Product Family
Series
Application
Comments
Component Type
Overview
Product Name
Style
UPC
Backplane Connectors
74712
Backplane
Port Numbered 2 Loaded
PCB Header
Ganged RF
Ganged RF
N/A
822350740081
Need more information on product
environmental compliance?
Email productcompliance@molex.com
For a multiple part number RoHS Certificate of
Compliance, click here
Please visit the Contact Us section for any
non-product compliance questions.
Physical
Circuits (Loaded)
Circuits (maximum)
Circuits Detail
Color - Resin
Durability (mating cycles max)
First Mate / Last Break
Flammability
Guide to Mating Part
Keying to Mating Part
Material - Metal
Material - Plating Mating
Material - Resin
Net Weight
Number of Columns
Number of Pairs
Number of Rows
Orientation
PC Tail Length
PCB Locator
PCB Retention
PCB Thickness - Recommended
Packaging Type
Pitch - Mating Interface
Pitch - Termination Interface
Polarized to PCB
Stackable
Surface Mount Compatible (SMC)
Temperature Range - Operating
Termination Interface: Style
2
8
2
Black, Natural
500
No
94V-0
No
Yes
Copper
Gold
High Temperature Thermoplastic, Polyester
8.876/g
4
N/A
2
Vertical
2.24mm
Yes
None
4.50mm
Tray
6.25mm
6.25mm
Yes
No
Yes
-40°C to +85°C
Through Hole - Compliant Pin
Search Parts in this Series
74712Series
Mates With
74642 Ganged RF Receptacle
Electrical
Current - Maximum per Contact
Data Rate
Real Signals (per 25mm)
Shield Type
Shielded
Voltage - Maximum
1A
3.0 Gbps
8
N/A
No
50V AC
Material Info
Reference - Drawing Numbers
Packaging Specification
Product Specification
Sales Drawing
PK-74712-001
PS-74854-001
SD-74712-002
This document was generated on 01/27/2015
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
