1N4004W
Features
•
•
•
•
•
•
Halogen
free available upon request by adding suffix "-HF"
Lead free assembly
Surface Mount Package Ideally Suited for Automatic Insertion
For general purpose
rectification
Easy pick and place
Lead Free Finish/RoHS Compliant("P" Suffix
designates RoHS Compliant. See ordering information)
1A 400V
Standard Recovery
Rectifier
SOD-123
A
B
Mechanical Data
•
•
•
•
•
Epoxy meets UL 94 V-0 flammability rating
Moisture Sensitivity Level 1
Terminals: Solderable per MIL-STD-202, Method 208
Polarity: Indicated by Cathode Band
Weight: 0.01 grams (approx.)
Marking Code:
Z44
Parameter
Non-repetitive peak reverse voltage
Value
400
280
1
7.5
350
357
150
-55~+150
Unit
Absolute maximum Ratings
Symbol
C
E
V
RM
V
R
V
R(RMS)
I
O
I
FSM
P
D
R
θJA
T
J
T
stg
Reverse Voltage
RMS reverse voltage
Average rectified output current
Non-repetitive peak forward surge current @t=8.3ms
Power dissipation
Thermal resistance from junction to ambient
Junction temperature
Storage temperature
V
V
A
A
mW
℃/W
℃
℃
H
D
G
J
DIM
A
B
C
D
E
G
H
J
Electrical Characteristics @ 25
O
C Unless Otherwise Specified
Parameter
Reverse voltage
Reverse current
Forward voltage
Total capacitance
Symbol
V
(BR)
I
R
V
F
C
tot
I
R
=100μA
V
R
=400V
I
F
=1A
V
R
=4V,f=1MHz
Test conditions
Min
400
5
1.1
15
Typ
Max
Unit
V
μA
V
pF
DIMENSIONS
INCHES
MM
MIN
MAX
MIN
MAX
.140
.152
3.55
3.85
.100
.112
2.55
2.85
.055
.071
1.40
1.80
-----
.053
-----
1.35
.012
.026
0.30
.66
.006
-----
0.15
-----
-----
.01
-----
.25
-----
.006
-----
.15
SUGGESTED SOLDER
PAD LAYOUT
0.093
NOTE
0.048”
0.036”
www.mccsemi.com
Revision:
B
1 of 3
2016/08/17
MCC
Micro Commercial Components
R
Ordering Information :
Device
Part Number-TP
Note : Adding "-HF" suffix for halogen free, eg. Part Number-TP-HF
Packing
Tape&Reel:
3Kpcs/Reel
