Teccor
®
brand Thyristors
10 Amp Sensitive & Standard SCRs
Sxx10xSx & Sxx10x Series
Description
RoHS
Excellent unidirectional switches for phase control and
general switching applications such as heating, motor
control controls, converters / rectifiers and capacitive
discharge ignitions.
Sensitive gate SCRs are easily triggered with microAmps
of current as furnished by sense coils, proximity switches,
and microprocessors.
Standard phase control SCRs are triggered with few
milliamperes of current at less than 1.5V potential.
Features & Benefits
Agency Approval
Agency
Agency File Number
TO-220L Package : E71639
• RoHS compliant
• Glass – passivated
junctions
• Voltage capability up
to 1000 V
• Surge capability up
to 100 A
Applications
Main Features
Symbol
I
T(RMS)
V
DRM
/ V
RRM
I
GT
Value
10
400 to 1000
0.2 to 15
Unit
A
V
mA
Typical applications includes capacitive discharge system
for motorcycle engine CDI, portable generator engine
ignition, strobe lights and nailers, as well as generic
rectifiers, battery voltage regulators and converters. Also
controls for power tools, home/brown good and white
goods appliances.
Internally constructed isolated packages are offered for
ease of heat sinking with highest isolation voltage.
Additional Information
Schematic Symbol
Datasheet
A
Resources
Samples
K
G
© 2016 Littelfuse, Inc.
Specifications are subject to change without notice.
Revised: 05/03/16
Teccor
®
brand Thyristors
10 Amp Sensitive & Standard SCRs
Absolute Maximum Ratings — Sensitive SCRs
Symbol
I
T(RMS)
Parameter
RMS on-state current
Test Conditions
Sxx10LSy
Sxx10RSy
Sxx10DSy
Sxx10VSy
Sxx10LSy
I
T(AV)
Average on-state current
Sxx10RSy
Sxx10DSy
Sxx10VSy
T
C
= 80°C
T
C
= 95°C
T
C
= 80°C
T
C
= 95°C
6.4
A
10
A
Value
Unit
I
TSM
I
2
t
di/dt
I
GM
P
G(AV)
T
stg
T
J
Peak non-repetitive surge current
I
2
t Value for fusing
Critical rate of rise of on-state current
Peak gate current
Average gate power dissipation
Storage temperature range
Operating junction temperature range
single half cycle; f = 50Hz;
T
J
(initial) = 25°C
single half cycle; f = 60Hz;
T
J
(initial) = 25°C
t
p
= 8.3 ms
f = 60 Hz ; T
J
= 110°C
T
J
= 110°C
T
J
= 110°C
83
A
100
41
100
1
0.1
-40 to 150
-40 to 110
A
2
s
A/μs
A
W
°C
°C
Note: xx = voltage, y = sensitivity
Absolute Maximum Ratings — Standard SCRs
Symbol
I
T(RMS)
Parameter
Test Conditions
Sxx10L
RMS on-state current
Sxx10R
Sxx10D
Sxx10V
Sxx10L
I
T(AV)
Average on-state current
T
C
= 95°C
T
C
= 105°C
T
C
= 95°C
6.4
A
10
A
Value
Unit
I
TSM
I
2
t
di/dt
I
GM
P
G(AV)
T
stg
T
J
Note: xx = voltage
Peak non-repetitive surge current
I
2
t Value for fusing
Critical rate-of-rise of on-state current
Peak gate current
Average gate power dissipation
Storage temperature range
Operating junction temperature range
Sxx10R
Sxx10D
T
C
= 105°C
Sxx10V
single half cycle; f = 50Hz;
T
J
(initial) = 25°C
single half cycle; f = 60Hz;
T
J
(initial) = 25°C
t
p
= 8.3 ms
f = 60 Hz T
J
= 125°C
T
J
= 125°C
T
J
= 125°C
83
A
100
41
100
2
0.5
-40 to 150
-40 to 125
A
2
s
A/μs
A
W
°C
°C
© 2016 Littelfuse, Inc.
Specifications are subject to change without notice.
Revised: 05/03/16
Teccor
®
brand Thyristors
10 Amp Sensitive & Standard SCRs
Electrical Characteristics
(T
J
= 25°C, unless otherwise specified)
– Sensitive SCRs
Symbol
I
GT
V
GT
dv/dt
V
GD
V
GRM
I
H
t
q
t
gt
Test Conditions
V
D
= 6V R
L
= 100
Ω
V
D
= 6V R
L
= 100
Ω
V
D
= V
DRM
; R
GK
= 1kΩ ; T
J
= 110°C
V
D
= V
DRM
; R
L
= 3.3 kΩ; T
J
= 110°C
I
GR
= 10μA
I
T
= 20mA (initial)
(1)
I
G
= 2 x I
GT
; PW = 15µs; I
T
= 12A
MAX.
MAX.
TYP
.
MIN.
MIN.
MAX.
MAX.
TYP
.
6
50
4
Value
Sxx10xS2
200
0.8
8
0.2
6
8
45
5
Sxx10xS3
500
Unit
μA
V
V/μs
V
V
mA
μs
μs
NOTE: xx = voltage, x = package
(1) I
T
=2A; t
p
=50µs; dv/dt=5V/µs; di/dt=-30A/µs
Electrical Characteristics
(T
J
= 25°C, unless otherwise specified)
– Standard SCRs
Symbol
I
GT
V
GT
V
D
= 12V R
L
= 60
Ω
V
D
= 12V R
L
= 60
Ω
400V
V
D
= V
DRM
; gate open; T
J
= 100°C
dv/dt
V
D
= V
DRM
; gate open; T
J
= 125°C
V
GD
I
H
t
q
t
gt
V
D
= V
DRM
; R
L
= 3.3 kΩ; T
J
= 125°C
I
T
= 200mA (initial)
(1)
I
G
= 2 x I
GT
; PW = 15µs; I
T
= 20A
600V
800V
1000V
400V
600V
800V
MIN.
MAX.
MAX.
TYP
.
MIN.
Test Conditions
MAX.
MAX.
Value
Sxx10x
15
1.5
350
300
250
100
250
225
200
0.2
30
35
2
V
mA
μs
μs
V/μs
Unit
mA
V
NOTE: xx = voltage, x = package
(1) I
T
=2A; t
p
=50µs; dv/dt=5V/µs; di/dt=-30A/µs
Static Characteristics
Symbol
V
TM
Test Conditions
I
T
= 20A; t
p
= 380 µs
Sxx10xyy
T
J
= 25°C
T
J
= 110°C
T
J
= 25°C
Sxx10x
400 - 600V
400 - 600V
400 - 800V
1000V
400 - 800V
1000V
400 - 800V
MAX.
MAX.
Value
1.6
5
250
10
20
200
3000
500
μA
Unit
V
I
DRM
/ I
RRM
V
DRM
/ V
RRM
T
J
= 100°C
T
J
= 125°C
Note: xx = voltage, x = package, yy = sensitivity
© 2016 Littelfuse, Inc.
Specifications are subject to change without notice.
Revised: 05/03/16
Teccor
®
brand Thyristors
10 Amp Sensitive & Standard SCRs
Thermal Resistances
Symbol
Parameter
Sxx10RSy
Sxx10LSy
Sxx10VSy
R
θ(J-C)
Junction to case (AC)
Sxx10DSy
Sxx10R
Sxx10L
Sxx10V
Sxx10D
Sxx10RSy
Sxx10LSy
R
θ(J-A)
Junction to ambient
Sxx10VSy
Sxx10R
Sxx10L
Sxx10V
Note: xx = voltage, y = sensitivity
Value
1.6
3.0
1.7
1.45
1.6
3.0
1.7
1.45
40
65
85
40
50
70
Unit
°C/W
°C/W
Figure 1: Normalized DC Gate Trigger Current
vs. Junction Temperature (Sensitive SCR)
4.0
Figure 2: Normalized DC Gate Trigger Current
vs. Junction Temperature (Standard SCR)
4.0
Ratio of I
GT
/ I
GT
(T
J
= 25°C)
3.0
Ratio of I
GT
/ I
GT
(T
J
= 25°C)
3.0
2.0
2.0
1.0
1.0
0.0
-40
-15
10
35
60
85
110
0.0
-40
-15
10
35
60
85
110
125
Junction Temperature (T
J
) -- (°C)
Junction Temperature (T
J
) -- (°C)
© 2016 Littelfuse, Inc.
Specifications are subject to change without notice.
Revised: 05/03/16
Teccor
®
brand Thyristors
10 Amp Sensitive & Standard SCRs
Figure 3: Normalized DC Gate Trigger Voltage
vs. Junction Temperature
2.0
Figure 4: Normalized DC Holding Current
vs. Junction Temperature
2.0
Ratio of V
GT
/ V
GT
(T
J
= 25°C)
Ratio of I
H
/ I
H
(T
J
= 25°C)
1.5
1.5
1.0
1.0
0.5
0.5
0.0
0.0
-40
-15
10
35
60
85
110
125
-40
-15
10
35
60
85
110
125
Junction Temperature (T
J
) -- (°C)
Junction Temperature (T
J
) -- (°C)
Figure 5: On-State Current vs. On-State
Voltage (Typical)
32
T
J
= 25ºC
28
24
20
16
12
8
4
0
0.7
0.8
0.9
1.0
1.1
1.2
1.3
1.4
1.5
1.6
Figure 6: Power Dissipation (Typical) vs. RMS
On-State Current
10
Average On-State Power Dissipation
[P
D(AV)
] -- (Watts)
9
8
7
6
5
4
3
2
1
0
0
1
2
3
4
5
6
7
8
9
10
Instantaneous On-state Current
(i
T
) – Amps
Instantaneous On-state Voltage (v
T
) – Volts
RMS On-State Current [I
T(RMS)
] -- (Amps)
Figure 7: Maximum Allowable Case Temperature
vs. RMS On-State Current
130
125
120
Figure 8: Maximum Allowable Case Temperature
vs. Average On-State Current
130
125
Maximum Allowable Case
Temperature (T
C
) - °C
Maximum Allowable Case
Temperature (T
C
) - °C
115
110
105
100
95
90
85
80
75
70
0
1
2
3
4
5
6
CURRENT WAVEFORM: Sinusoidal
LOAD: Resistive or Inductive
CONDUCTION ANGLE: 180°
FREE AIR RATING
Sxx10RSy
Sxx10DSy
Sxx10VSy
Sxx10LSy
Sxx10L
Sxx10R
Sxx10D
Sxx10V
120
115
110
105
100
95
90
85
80
75
70
Sxx10RSy
Sxx10DSy
Sxx10VSy
Sxx10LSy
CURRENT WAVEFORM: Sinusoidal
LOAD: Resistive or Inductive
CONDUCTION ANGLE: 180°
FREE AIR RATING
0
1
2
3
4
5
Sxx10L
Sxx10R
Sxx10D
Sxx10V
7
8
9
10
11
6
7
RMS On-State Current [I
T(RMS)
] - Amps
Average On-State Current [I
T(AVE)
] - Amps
© 2016 Littelfuse, Inc.
Specifications are subject to change without notice.
Revised: 05/03/16
