Scalable and
power-efficient
multi-market MCUs
LPC54000 Series of MCUs
Offering a wide range of performance and feature scalability, the LPC54000 series of
single and dual core MCUs delivers improved power-efficiency for a variety of always-
on applications.
TARGET APPLICATIONS
}
Portable fitness and activity trackers
}
Health and wellness monitoring
}
Intelligent sensing and motion tracking
}
Home and building automation
}
Industrial/commercial sensor nodes
}
Mobile handsets and tablets
}
Fleet management and asset tracking
}
Gaming and USB accessories
}
Home and building automation
OVERVIEW
The LPC54000 series represents the next-generation of
industry-leading power efficiency. With added scalability
and feature integration, these breakthrough devices enable
continued growth for always-on applications.
The LPC54100 and LPC54110 families, based on the ARM
®
Cortex
®
-M4 core, offer an optional Cortex
®
-M0+ co-processor
for added flexibility.
The LPC54110 family finds the right balance between
feature integration and power efficiency with the ARM
®
Cortex
®
-M4 achieving an active mode current of 80 µA/
MHz. With an industry-leading dual-core option, the
LPC5411x MCU can shut down the Cortex
®
-M4 for a tiered
power approach and use the Cortex
®
-M0+ to perform less
taxing tasks, achieving an even lower active mode of
60 µA/MHz.
The optional on-chip digital microphone (DMIC) subsystem
on the LPC54110 family dramatically reduces power
consumed in applications that demand voice input and
processing, achieving the stringent power efficiencies
needed for always-on voice-activation in battery-operated
products.
LOW-POWER ARCHITECTURE
The LPC54000 series is architected
for power efficiency. In addition to the
dual-core optimization, the low-power
interfaces can wake the CPU from
power down once data is received. The
12-bit, 12-channel ADC delivers 5 Msps
operation at full spec, including 1.62 V,
which performs conversion while the CPU
is asleep.
The low-power flash is writable at 1.62
V. Core and peripheral voltages are
automatically scaled for reduced power
consumption at any frequency. An
asynchronous peripheral bus enables
reduced peripheral clock speed without
affecting the CPU clock, which minimizes
peripheral power consumption.
COMPREHENSIVE ENABLEMENT
SOLUTIONS
LPCOpen
}
Extensive suite of robust peripheral
drivers, stacks and middleware
}
Includes software examples
demonstrating use of peripheral drivers
and middleware
}
Operating system abstraction (OSA)
layer with FreeRTOS application
examples
Integrated Development Environments
(IDE)
}
IAR Embedded Workbench
}
ARM Keil Microcontroller
Development Kit
®
®
LPC54000 SERIES BLOCK DIAGRAM
System
DMA
Low-Power Management
Single V
DD
power supply,
reduced power modes,
automatic voltage scaling
Clock Generation Unit
ARM
®
Cortex
®
-M4
(100 MHz, MPU, FPU)
Core
Timers
32-bit General Purpose
SCTimer/PWM
24-bit Multi-Rate
WWDT
RTC/Alarm
Micro-Tick
Cortex
®
-M0+
Co-processor
Multilayer Bus Matrix
Repetitive
Interrupt
Low-Power Analog
ADC
12-bit, 12-ch., 5 Msps
Advanced Connectivity
DMIC Subsystem
Low Power Interfaces
I
2
C
UART
SPI
I
2
S
Memory
Flash
Up to 512 KB
RAM
Up to 192 KB
Temp. Sensor
Crystal-less USB 2.0
GPIO (Up to 50)
ROM
Bootloader
I C/SPI Drivers (LP54110)
2
Optional
LPC54000 SERIES OF POWER-EFFICIENT MCUS
Parts
LPC54113J128BD64
LPC54113J256BD64
LPC54113J256UK49
LPC54114J256BD64
LPC54114J256UK49
LPC54101J256UK49
LPC54101J512UK49
LPC54101J256BD64
LPC54101J512BD64
LPC54102J256UK49
LPC54102J512UK49
LPC54102J256BD64
LPC54102J512BD64
Core
M4
M4
M4
M4/M0+
M4/M0+
M4
M4
M4
M4
M4/M0+
M4/M0+
M4/M0+
M4/M0+
Flash
(kbit)
128
256
256
256
256
256
512
256
512
256
512
256
512
RAM
(kbit)
96
192
192
192
192
104
104
104
104
104
104
104
104
Digital
Crystal-less
Package
Microphone
FS USB
name
Subsystem
Yes
Yes
Yes
Yes
Yes
No
No
No
No
No
No
No
No
Yes
Yes
Yes
Yes
Yes
No
No
No
No
No
No
No
No
LQFP64
LQFP64
WLCSP49
LQFP64
WLCSP49
WLCSP49
WLCSP49
LQFP64
LQFP64
WLCSP49
WLCSP49
LQFP64
LQFP64
Recommended
Development
Board
OM13089
OM13089
OM13089
OM13089
OM13089
OM13077
OM13077
OM13077
OM13077
OM13077
OM13077
OM13077
OM13077
ROM
}
Common bootloader for the LPC54000
Series
}
In-system flash programming over a
serial connection: erase, program,
verify
}
ROM or flash-based bootloader with
open-source software and host-side
programming utilities
}
Providing commonly used I
2
C and
SPI drivers in the LPC54110 family of
products
Development Hardware
}
LPCExpresso development boards
– Low-cost evaluation
– Arduino
™
R3 compatible shields
}
LPCXpresso
– No-cost, as well as a professional
integrated development environment
(IDE) for LPC MCUs
– Eclipse and GCC-based IDE for
C/C++ editing, compiling and
debugging
www.nxp.com/LPC54000
NXP and the NXP logo are trademarks of NXP B.V. All other product or service names are the property of their respective
owners. ARM, Cortex, and Keil are registered trademarks of ARM Limited (or its subsidiaries) in the EU and/or elsewhere.
All rights reserved. © 2016 NXP B.V.
Document Number:
LPC54000SERFS REV 0
Date of release: February 2016
Document order number: 9397 750 17616
