SW
-P
5
T6
PT65 series
Rotary code switches
DISTINCTIVE FEATURES
4 actuator types
Sub-miniature size
Solder and flux sealed, washable
ENVIRONMENTAL SPECIFICATIONS
• Operating temperature: -20 °C to +70 °C (-4 °F to +167 °F)
ELECTRICAL SPECIFICATIONS
• Operating voltage :
≤
42 V
• Contact load, static :
≤
0.2 A
• Contact load, dynamic :
≤
0.15 A
• Initial contact resistance : 80 mΩ max.
• Insulation resistance : 100 MΩ min.
MECHANICAL SPECIFICATIONS
• Torque : 0.7 Ncm min
• Expected life : 10,000 cycles min.
MATERIALS
• Base : UL94-V0, high temperature thermoplastic
• Cover : UL94-V0, high temperature thermoplastic
• Actuator : PA 4.6 nylon
• Contacts : gold over nickel plated phosphor bronze
• Terminals : tin plated
The company reserves the right to change specifications without notice.
1
PANEL SWITCHES
PCB
02
18
-
PCB SWITCHES
PT65 series
Rotary code switches
SOLDERING
• DIN CEI 68-2-20
• Manual soldering : 340 °C (644 °F) max. for 2 seconds max.
• Wave soldering : 280 °C (536 °F) max. for 5 seconds max.
PCB MOUNTING
PCB STRAIGHT
7.62
(.300)
5.08
(.200)
2.54
(.100)
PACKAGING
• Switches for screwdriver slot or accessory actuation (PT651
and PT657) : tubes of 50 pieces
• Switches with spindle (PT653) or segment wheel (PT655) :
trays of 50 pieces
• Accessories : bags of 50 pieces
PCB RIGHT ANGLE 2.54
2.54
(.100)
Ø1.00
(.039 DIA)
PCB RIGHT ANGLE 5.08
2.54
(.100)
2
Ø1.00
(.039 DIA)
Ø1.00
(.039 DIA)
2.54
(.100)
PT65 series
Rotary code switches
BUILD YOUR PART NUMBER
PT65
SERIES
ACTUATORS
CODES
TERMINALS
1
3
5
7
Screwdriver
Spindle
Segment wheel
Accessories
01
02
03
06
BCD
BCD complement
Hexadecimal
Hexadecimal
complement
(none)
L254
L508
Straight
Right angle,
spacing 2.54 (.100)
Right angle,
spacing 5.08 (.200)
AVAILABLE AS STANDARD PRODUCTS
SCREWDRIVER
Upper actuation
BCD
BCD
COMPLEMENT
HEXADECIMAL
HEXADECIMAL
COMPLEMENT
PT65101
PT65102
PT65103
PT65106
Side actuation
PT65101L254
PT65101L508
-
PT65103L254
PT65103L508
-
SPINDLE
Upper actuation
PT65301
-
PT65303
-
SEGMENT WHEEL
Upper actuation
PT65501
PT65502
PT65503
-
Side actuation
-
-
PT65303L254
-
ACCESSORIES
Upper actuation
PT65701
-
-
-
SCREWDRIVER SLOT - STRAIGHT TERMINALS
2.20
(.087)
7.62
(.300)
4.00
(.157)
0.27
(.011)
6.50
(.256)
2.54
(.100)
0.55
(.022)
10.00
(.393)
78
9
0
1
3.20
(.126)
10.00
(.393)
0.20
(.008)
1
C
4
8
C
2
4.00
(.157)
3
PANEL SWITCHES
PCB
23
4
5
6
PCB SWITCHES
PT65 series
Rotary code switches
ACTUATORS
PT65
1
3
8
7
Screwdriver
Spindle (grey)
Segment wheel (grey)
Accessories (see next page)
1.00
(.039)
4.40
(.173)
7.30
(.287)
3.50
(.138)
1.00
(.039)
4.00
(.157)
9
3.20
(.126)
2.85
(.112)
2.80
(.039)
9.50
(.374)
78
78
78
9
0
1
0
1
0
1.05
(.041)
9
0
1
4.00
(.157)
1.00
(.039)
7.70
(.303)
1.05
(.041)
1
3
5
7
CODES
PT65
01
02
03
06
BCD
BCD complement
Hexadecimal
Hexadecimal complement
POSITION
C
0
1
2
3
4
5
0
1
2
3
4
5
6
7
8
9
6
7
8
9
10
11
12
13
14
15
1
2
4
MARKING
8
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
3.20
(.126)
23
23
POSITION
C
0
1
2
3
4
5
6
7
8
9
1
2
4
MARKING
8
0
1
2
3
4
5
6
7
8
9
POSITION
C
0
1
2
3
4
5
6
7
8
9
1
2
4
MARKING
8
01
02
03
4
4
5
6
4
5
6
23
4
5
6
POSITION
C
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1
2
4
MARKING
8
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
06
PT65 series
Rotary code switches
TERMINALS
PT65
(none)
Straight
L254
Right angle, spacing 2.54 (.100)
L508
Right angle, spacing 5.08 (.200)
7.62
(.300)
0
1
0
1
0
1
23
23
23
9
9
2.54
(.100)
5.08
(.200)
2.54
(.100)
2.54
(.100)
2.54
(.100)
(none)
Ø1.00
(.039 DIA)
7.62
(.300)
5.08
(.200)
L254
L508
Ø1.00
(.039 DIA)
ACCESSORIES
To order separately.
ACCESSORIES ADAPTED TO YOUR APPLICATIONS
Basic model PT657 has been designed to accept different actuators with snap-in connection.
According to your application, you can choose between spindles or plastic knobs in two different lengths and a Ø 17
mm (.669) knurled wheel for lateral marking.
Standard colours are shown below. Special colours are also available on request.
P/N
SPINDLES
Length 11.6 mm
(standard)
Length 13.3 mm
PLASTIC KNOBS
Length 5.3 mm
(standard)
Length 15.7 mm
U4822
U4824
U4832
U4906
U4916
COLORS
black
grey
1.00
(.039)
1.00
(.039)
DIMENSIONS
11.60
(.457)
13.30
(.524)
black
red
red
4.00
(.157)
10.50
(.413)
3.10
(.122)
1.00
(.039)
2.10
(.083)
4.40
(.173)
4.10
(.161)
Length 4.4 mm
U4941
U4943
U4944
U4945
U4946
blue
green
grey
yellow
red
white/black
2.80
(.110)
Ø9.50
(.473 DIA)
7.70
(.303)
3.50
(.138)
KNURLED WHEEL
(unmarked - marking on request)
U4847/1
3.10
(.122)
1.00
(.039)
6.10
(.240)
5.30
(.209)
15.70
(.618)
Ø1.00
(.039 DIA)
3.10
(.122)
1.80
(.071)
7.62
(.300)
17.00
(.669)
7.20
(.283)
9.60
(.378)
2.54
(.100)
2.54
(.100)
2.54
(.100)
2.54
(.100)
78
9
5
PANEL SWITCHES
PCB
78
4
4
4
5
6
5
6
5
6
78
