SOLID STATE SENSOR
DS Series
Digital Vane in Miniature switch package
Features
Fits mounting dimension of popular
snap-action switches.
Tested to over 10 million operations.
Two actuator mounting positions.
Available with lever, roller and
simulated roller actuators.
Sold state sinking output using hall
effect technology
Mates with Amp 102241-1 or
equivalent.
Material Specifications:
- Case, cover, actuating button:
Thermoplastic Polyester (PBT)
UL94V-0
Applications:
Pedal position sensing
Door/lid interlock
Joystick position sensing
End of travel sensing
Specifications
Supply voltage (VDC)
Supply Current
Output Type
Output Current (mA max.)
Sensor State (Button at rest)
Operating Temperature
Storage Temperature
4.5 to 24
15mA max at 25°C
Sink
20
Normally OFF
-40°C to 85°C
-40°C to 125°C
Dimensions mm
Note: Sensor requires the use of an external pull-up resistor. The value is dependent on the supply voltage. See chart below.
UL File No: E23301
Part Number Examples:
Lever
Actuation
Length
(inch/mm)
N/A
0.87
22.0
1.04
26.5
1.4
35.7
1,58
40.2
2.34
58.4
2.52
63.9
0.81
20.5
.99
25.0
1.29
32.7
DS1101UC
Simulated
Roller
1.47
37.2
High
Lever
Actuator
Ratio
N/A
Std.
High
Std.
High
Std.
High
Std.
High
Std.
Max
Pretravel
(inch/mm)
0.06
1.50
0.08
2.08
0.14
3.48
0.17
4.27
0.28
7.13
0.32
8.08
0.53
13.48
0.07
1.85
0.12
3.08
0.15
3.8
0.25
6.34
Operate
Point
(inch/mm)
0.58
14.70
0.60
15.2
0.6
15.2
0.60
15.2
0.60
15.2
0.60
15.2
0.60
15.2
0.81
20.57
.81
20.57
0.73
18.5
0.73
18.5
Operate
Point
Tolerance
(+/-
inch/cm)
0.02
0.60
0.03
0.69
0.05
1.15
0.06
1.42
0.09
2.38
0.11
2.69
0.18
4.49
0.02
0.62
0.04
1.03
0.05
1.27
0.08
2.11
Min
Overtravel
(inch/mm)
0.04
1.00
0.04
1.04
0.07
1.73
0.08
2.14
0.14
3.58
0.16
4.04
0.27
6.74
0.04
0.92
0.06
1.54
0.07
1.9
0.12
3.17
Max
Movement
Differential
(inch/max)
0.01
0.20
0.01
0.23
0.02
0.38
0.02
0.47
0.03
0.79
0.04
0.9
0.06
1.5
0.01
0.21
0.01
0.34
0.02
0.42
0.03
0.7
29
48
Max
Operating
Force (g)
PART
NUMBER
DS1101AA
DS1101JA
DS1101KA
DS1101JD
DS1101KD
DS1101JJ
DS1101KJ
DS1101RA
DS1101TA
DS1101SC
Lever Style
N/A
SS Leaf
SS Leaf
SS Leaf
SS Leaf
SS Leaf
SS Leaf
Roller
Roller
Simulated
Roller
84
84
53
43
28
23
14
99
59
Open Collector Sinking Block Diagram
Recommended pull-up resistor values
Volts DC:
Ohms:
5
1K
9
1.8K
12
2.4K
15
3K
24
3K
Specifications subject to change without notice.
Contact
Call, fax or visit our website
For more information.
ZF Electronics Corporation
11200 88th Avenue
Pleasant Prairie, WI 53158
Phone:
Web:
E-Mail:
Fax:
262.942.6500
www.cherrycorp.com
cep_sales@zf.com
262.942.6566
© 2008 ZF Electronics Corporation Revised 030211
