Halogen and Antimony Free. “Green” Device (Note 3)
SOT553
(TOP View)
SIP-3L
•
•
•
•
•
•
Applications
•
•
•
•
•
•
Smart E-Meters
Tamper Protection Switch
Door, Lids and Tray Position Switch
Proximity and Position Switches
Level Detects
On/Off Switch Digital Contact-Less Switch in Industrial and
Consumer Products
Notes:
1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.
2. See http://www.diodes.com/quality/lead_free.html for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green"
and Lead-free.
3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and
6. Stresses greater than the 'Absolute Maximum Ratings' specified above may cause permanent damage to the device. These are stress ratings only;
functional operation of the device at these or any other conditions exceeding those indicated in this specification is not implied. Device reliability may be
affected by exposure to absolute maximum rating conditions for extended periods of time.
7. The absolute maximum V
DD
of 7V is a transient stress rating and is not meant as a functional operating condition. It is not recommended to
operate the device at the absolute maximum rated conditions for any period of time.
Recommended Operating Conditions
(@T
A
= +25°C, unless otherwise specified.)
Symbol
V
DD
V
OUT_MAX
T
A
Parameter
Supply Voltage
Maximum output pin voltage
Operating Temperature Range
Operating
Operating
Operating
Conditions
Rating
2.5 to 5.5
5.5
-40 to +125
Unit
V
V
°
C
Electrical Characteristics
(@T
A
= +25°C, VDD = 3V, unless otherwise specified.)
Symbol
V
OUT_ON
Ioff
Parameter
Output On Voltage (V
OL
)
Output Leakage Current
I
OUT
= 1mA
V
OUT
= 5.5V, Output off
During ‘awake’ period,
T
A
= +25° V
DD
= 3V
C,
During ‘awake’ period,
T
A
= -40 to +125° V
DD
= 2.5V to 5.5V
C,
During ‘sleep’ period,
T
A
= +25° V
DD
= 3V
C,
During ‘sleep’ period,
T
A
= -40 to +125° V
DD
= 2.5V to 5.5V
C,
Average Supply Current
Awake Time
Period
Duty Cycle
T
A
= +25° V
DD
= 3V
C,
T
A
= -40 to +125° V
DD
= 2.5V to 5.5V
C,
(Note 8)
(Note 8)
-
Conditions
Min
—
—
—
—
—
—
—
—
—
—
—
Typ
0.1
<
0.1
3
—
5
—
8
—
75
75
0.1
Max
0.3
1
6
12
10
28
16
40
125
125
—
Unit
V
µA
mA
mA
µA
µA
µA
µA
µs
ms
%
I
DD
(awake)
Supply Current
I
DD
(sleep)
I
DD
(sleep)
I
DD
(avg)
Tawake
Tperiod
D.C.
Note:
8. When power is initially turned on, the operating V
DD
must be within its correct operating range (2.5V to 5.5V) to guaranteed the output sampling.
The output state is valid after the second operating cycle (typical 150ms).
10. Parameters values over operating temperature range are not tested in production, they are guaranteed by design, process control and characterization.
The magnetic characteristics may vary with supply voltage, operating temperature and after soldering.
11. Maximum and minimum hysteresis is guaranteed by design and characterization.
