Fiber Photoelectric Sensor
E3S-X3
CSM_E3S-X3_DS_E_2_1
Excellent Detection of Color
Differences
Ordering Information, Ratings, and Specifications
Amplifiers
Model
Item
E3S-X3CE4
Sturdy model
Appearance
Light source (wave length)
Power supply voltage
Current consumption
Response time
Control output
Operation indicator
Ambient illumination
Ambient temperature
Ambient humidity
Insulation resistance
Dielectric strength
Degree of protection
Material
Red LED (660 nm)
12 to 24 VDC
±10%
50 mA max.
Operate or reset: 1 ms max.
Output current: 1.5 to 4 mA, Load current: 80 mA max. (residual voltage: 2 V max.)
Light indicator (red), Stability indicator (green)
Sunlight: 10,000 lx max.; Incandescent lamp: 3,000 lx max.
Operating:
−25°C
to 55°C (with no icing)
Storage:
−25°C
to 70°C
Operating: 35% to 85%
Storage: 35% to 95%
20 MΩ min. (at 500 VDC)
between current-carrying parts and case
500 VAC at 50/60 Hz for 1 minute
between current-carrying parts and case
IEC IP66
Case: Zinc die-cast
1
E3S-X3
Fiber Units
Through-beam and Grooved-type Sensors
Sensing method
Feature
Model
E32-T11L
Long distance
E32-T12L
E32-T21L
E32-T22L
Through-beam
General-purpose
E32-TC200
E32-TC200B
E32-
TC200B4
90 mm (40 mm)
Appearance
M4 screw
3-mm dia.
M3 screw
2-mm dia.
M4 screw
M4 screw
Item
Sensing distance
250 (650) mm
*
250 mm
65 mm
Opaque:
Opaque:
(standard sens-
Opaque: 0.9-mm dia. min.
1.4-mm dia. min. 1.4-mm dia. min.
ing object)
Minimum sensing
object (copper
0.3-mm dia.
strand) (typical)
−40
to 70°C
35% to 85%
25 mm min.
Black polyethylene
0.2-mm dia.
120 mm (1 m)
*
Opaque:
1-mm dia. min.
( ): E32-TC200B4
With
E3S-
X3CE4
120 mm
Opaque:
1-mm dia. min.
Ambient operating tempera-
ture
Ambient operating humidity
Permissible bending radius
Fiber sheath materials
* Values in parentheses: when using the E39-F1 Lens Unit
Sensing method
Feature
General-purpose
Through-beam
Attachment for
E39-F5
E32-TC200F
E32-
TC200F4
90 mm (40 mm)
Flexible (resists breaking)
Model
E32-T22
E32-TC200E
E32-TC200A
E32-T11
E32-T21
Appearance
2-mm dia.
M3 screw
M3 screw
M3 screw
M4 screw
M3 screw
Item
Sensing distance
35 mm
(standard sens-
Opaque: 0.5-mm dia. min.
ing object)
Minimum sensing
object
0.1-mm dia.
(copper strand)
(typical)
−40
to 70°C
35% to 85%
25 mm min.
Black polyethylene
( ): E32-TC200F4
With
E3S-
X3CE4
120 mm
Opaque:
1-mm dia. min.
120 mm (1 m)
*
Opaque:
1-mm dia. min.
35 mm
Opaque:
0.5-mm dia.
min.
0.2-mm dia.
0.1-mm dia.
Ambient operating tempera-
ture
Ambient operating humidity
Permissible bending radius
Fiber sheath materials
4 mm min.
Vinyl chloride
* Values in parentheses: when using the E39-F1 Lens Unit
2
E3S-X3
: Indicates models that do not allow free cutting.
Sensing method
Through-beam
Side-view Through-beam
Long dis-
tance
E32-T14L
Space sav-
ing
E32-T24
Screw-
mounting
type
E32-T14
Through-beam
with lens
Suitable for ex-
plosion-proof
applications
E32-T17L
Feature
Curl cable
E32-TC200D
E32-TC200D4
90 mm (40 mm)
Model
E32-TC200C
Appearance
Item
Sensing distance
(standard sens-
ing object)
M4 screw
M6 screw
3-mm
dia.
1-mm
dia.
(): E32-TC200D4
M14 screw
With
E3S-
X3CE4
100 (600) mm
*1
Opaque: 1-mm dia.
min.
100 mm
Opaque: 1-mm dia.
min.
5,000 mm
600 mm
30 mm
80 mm
Opaque: 10-mm
Opaque: 0.5- Opaque: 4-
Opaque: 1-
mm dia. min. mm dia. min. mm dia. min. dia. min.
0.1-mm dia.
0.8-mm dia.
Minimum sensing
object (copper
0.2-mm dia.
strand) (typical)
−40
to 70°C
35% to 85%
25 mm min.
Black polyethylene
Ambient operating tempera-
ture
Ambient operating humidity
Permissible bending radius
Fiber sheath materials
Fluorocarbon
polymer-cov-
Sensing method
ered through-
beam
Withstands
chemicals and
Feature
harsh environ-
ments
Model
E32-T12F
Screen
through-beam
Four-head
through-beam
Simulta-
neous de-
tection in
four loca-
tions
E32-M21
Heat-resistant through-beam
Groove type
Suitable for
detecting over
a 10-mm area
E32-T16
Heat resistant
up to 150°C
Heat resistant
up to 300°C
No optical axis
adjustment re-
quired
E32-G14
E32-T51
E32-T61
Appearance
5-mm dia.
M3 screw
M4 screw
M4 screw
Item
Sensing distance
(standard sens-
ing object)
550 mm
Opaque: 4-mm dia.
min.
550 mm
*2
(Field of view: 10
mm width)
Opaque: 10-mm
dia. min.
0.4-mm dia.
*2
100 mm
Opaque: 2-mm dia.
min.
120 mm
Opaque: 1-mm dia.
min.
100 mm
Opaque: 1.5-mm
dia. min.
100 mm (groove
width)
Opaque: 4-mm dia.
min.
With
E3S-
X3CE4
Minimum sensing
0.9-mm dia.
object (copper
strand) (typical)
−30
to 70°C
35% to 85%
40 mm min.
Black polyethylene
covered with
fluorocarbon
polymer
0.3-mm dia.
0.1-mm dia.
0.8-mm dia.
Ambient operating tempera-
ture
Ambient operating humidity
Permissible bending radius
Fiber sheath materials
−40
to 70°C
−40
to 150°C
*3
−40
to 300°C
−40
to 70°C
25 mm min.
35 mm min.
25 mm min.
Black polyethylene
Fluororesin
SUS
Black polyethylene
*1. When using the E39-F1 Lens Unit. Ambient operating temperature specification is the same as the Lens Unit (−40 to
200°C).
*2. The sensing distance is 400 mm when a 1.0-mm-wide Slit is attached. The minimum diameter of the sensing object is
0.35 mm. The sensing distance is 300 mm when a 0.5-mm-wide Slit is attached. The minimum diameter of the sensing
object is 0.25 mm. (Use a Slit with 0.5-mm width if the sensing distance is less than 300 mm. The measurements of
distances are shown in the figure on the right.)
*3. For continuous operation, use the products within the temperature ranging from
−40°C
to 130°C.
Sensing object
3
E3S-X3
Reflective Sensors
Sensing method
Feature
Model
E32-D11L
Long distance
E32-D21L
E32-D22L
E32-DC200
Reflective
General-purpose
E32-DC200B
E32-
DC200B4
90 mm (40 mm)
: Indicates models that do not allow free cutting.
E32-DC200E
Appearance
M6 screw
M4 screw
3-mm dia.
M6 screw
M6 screw
M3 screw
Item
Sensing distance
65 mm
(white paper 3 x
(standard sens-
3 cm)
ing object)
Minimum sensing
object (copper
0.015-mm dia.
strand) (typical)
18 mm (white paper 1.5 x 1.5 cm)
( ): E32-TC200B4
With
E3S-
X3CE4
50 mm (white paper 3 x 3 cm)
12 mm (white
paper 1.5 x 1.5
cm)
0.03-mm dia.
Differential travel
Ambient operating tempera-
ture
Ambient operating humidity
Permissible bending radius
Fiber sheath materials
Sensing method
Feature
20% of sensing distance max.
−40
to 70°C
35% to 85%
25 mm min.
Black polyethylene
Reflective
General-pur-
pose
E32-DC200F
E32-
DC200F4
Flexible (resists breaking)
Expandable curl cable
E32-DC200D
E32-DC200D4
90 mm (40 mm)
Sleeve adjust-
ment
E32-DC9G
E32-DC9G4
90 mm (40 mm)
1.2-mm dia.
Model
E32-D11
E32-D21
E32-DC200C
Appearance
Item
M3 screw
M6 screw
M3 screw
M6 screw
M6 screw
( ): E32-DC200D4
( ): E32-DC9G4
With
E3S-
X3CE4
7 mm
30 mm
Sensing distance
12 mm
(white paper 1.5 (white paper 3 (white paper
(standard sens-
1.5 x 1.5 cm)
x 3 cm)
x 1.5 cm)
ing object)
Minimum sensing
object (copper
0.03-mm dia.
strand) (typical)
20% of sensing distance max.
−40
to 70°C
35% to 85%
25 mm min.
Black
polyethylene
4 mm min.
Vinyl chloride
15 mm (white paper 3 x 3 cm)
20 mm
(white paper
1.5 x 1.5 cm)
Differential travel
Ambient operating tempera-
ture
Ambient operating humidity
Permissible bending radius
Fiber sheath materials
25 mm min.
Black polyethylene
4
E3S-X3
: Indicates models that do not allow free cutting.
Sensing method
Superfine
reflector
Coaxial reflective
Side-view reflective
Reflective
covered with Heat-resist-
fluorocar-
ing reflective
bon polymer
Withstands
chemicals
and harsh
environ-
ments
E32-D12F
Minute
Feature object sens-
ing
Model
E32-D33
Positioning accuracy
Long
distance
Space
saving
Heat resis-
tant to 150°C
E32-CC200
E32-D32
E3-D14L
6-mm
dia.
E32-D24
2-mm
dia.
E32-D51
Appearance
Item
Sensing distance
(standard sens-
ing object)
3-mm 0.8-mm
dia.
dia.
M6 screw
2-mm dia.
6-mm dia.
M6 screw
With
E3S-
X3CE4
4 mm
(white paper
1.5 x 1.5 cm)
50 mm
(white paper
3 x 3 cm)
0.03-mm dia.
20 mm
(white paper
3 x 3 cm)
25 mm
(white paper
3 x 3 cm)
10 mm
(white paper
1.5 x 1.5 cm)
35 mm
(white paper
3 x 3 cm)
40 mm
(white paper
3 x 3 cm)
Minimum sensing
0.015-mm
object (copper
dia.
strand) (typical)
Differential travel
Ambient operating tempera-
ture
Ambient operating humidity
Permissible bending radius
20% of sensing distance max.
−40
to 70°C
35% to 85%
25 mm min.
40 mm min.
Black
polyethylene
covered with
fluorocarbon
polymer
Retro-reflective (with MSR function)
Transparent object detection
E32-R21+E39-R3
*4
E39-R3
Reflector
−30
to 70°C
−40
to 150°C
*1
35 mm min.
Fiber sheath materials
Black polyethylene
Fluororesin
Sensing method
Feature
Model
Heat-resistant reflective
Heat resis-
tant up to
300°C
E32-D61
Heat resis-
tant up to
400°C
E32-D73
Convergent-reflective
Detects wafers and small
differences in height
E32-L25
*3
E32-L25A*3
E32-R16+E39-R1
*4
E39-R1
Reflector
Appearance
Item
Sensing distance
(standard sens-
ing object)
M6 screw
M4 screw
1.25-mm
dia.
M6 screw
With
E3S-
X3CE4
30 to 200 mm
(with E39-R3 Reflector,
30 mm (white paper 3 x 3 cm)
Opaque: 35-mm dia.
min.)
0.3-mm dia.
100 to 1,200 mm
(with E39-R1 Reflector, 3.3 mm white paper 3 x
3 cm)
Opaque: 35-mm dia.
min.)
*2
0.6-mm dia.
0.025-mm dia.
5% max. of sensing
distance
−25
to 55°C
−40
to 70°C
Minimum sensing
object (copper
0.03-mm dia.
strand) (typical)
Differential travel
Ambient operating tempera-
ture
Ambient operating humidity
Permissible bending radius
Fiber sheath materials
−40
to 300°C
35% to 85%
25 mm min.
SUS
−40
to 400°C
---
−40
to 70°C
Black polyethylene
*1. For continuous operation, use the products within the temperature ranging from
−
40°C to 130°C.
*2. The sensing distance is 30 to 80 mm for the E39-RSA with a Tape-type Reflector, and 30 to 120 mm for the E39-RSB.
*3. Refer to
Dimensions
on pages 24 and 25 for the standards for sensing distances.
*4. The ambient operating temperature specification of the Reflectors is the same as that of the E32-R21 and E32-R16.
5
京公网安备 11010802033920号
EEWORLD
