• FLUSH MOUNT GENERAL PURPOSE, HIGH PRESSURE TRANSDUCER
The AB is ideal for a wide range of applications.
That's because it has a variety of mounting
options, stainless steel construction, and wide
pressure ranges. In addition, the AB has two
thermally matched strain gages, and it is fully
compensated and calibrated. Its output is a stable
0-100 mV from an excitation of 5 Vdc.
The AB may be flush-mounted or fitted with
an external adapter. It also may be fitted with
an optional integral connector or waterproof cable
fitting. The flush mounting capability allows
it to be used in applications where sanitary or
cleaning requirements exclude using pressure
ports.
AB/HP S
ERIES
FEATURES
BENEFITS
•
•
•
•
Flush mount option
0-6 to 0-20,000 PSI ranges
Custom designs available
PSIA and bi-directional models
•
•
•
•
Permits maximum cleanliness
Wide range of applications
Adaptable to special needs
Measures vacuum referenced to
absolute or atmospheric pressures
FLUSH MOUNT GENERAL PURPOSE
,
HIGH PRESSURE TRANSDUCER
HOW TO ORDER
ABH
Model
Range
006
015
025
050
Unit
P = PSI
Reference
A = Absolute
G = Gage
S = Sealed (PSIS)
< 100 PSI
< 100 PSI
> 50 PSI
100
200
500
01K
03K
05K
10K
15K
20K
006
P
G
C
1
B
3
Special Features
3 = Barbed Fitting
at Cable
Output
B = 0-100 mV
Cable Length
1 = 3 feet
4 = 12 feet
5 = 15 feet
6 = 30 feet
7 = 50 feet
Termination
C = Cable
B = Bendix Connector
High Temperature
Note: Not all combinations are available. Minimum quantity orders apply. Contact the factory for more details.
AB/HP S
ERIES
TECHNICAL SPECIFICATIONS
RANGES
•
FLUSH MOUNT GENERAL PURPOSE
,
HIGH PRESSURE TRANSDUCER
DIMENSIONS
0-6, 15, 25, 50 PSIG or PSIA
0-100, 200, 500, 1000, 2000, 3000, 5000 PSIS
0-10,000, 15,000, 20,000 PSIS
xx.xx = inches
(xx.x) = mm
PHYSICAL
Proof Pressure
Burst Pressure
Material in Contact
with Media
Shock
Vibration
Weight
2 X rated range 30,000 PSIS (2068 B) max.
5 X rated range 50,000 PSI (3448 B) max.
<100 PSI 316L SS
≥100
PSI 15-5 PH SS
50 g’s peak (11 milliseconds)
Meets Mil-STD-810-C, Figure 514.2-5,
Curve AP, 46.3 g rms min.
2 oz (57 gm) less cable and adapter
100
±
1 mV at rated excitation @ 25°C
0.0
±
5.0 mV @ 25°C
5.0 Vdc recommended, 6.0 Vdc max.
150
±
50
Ω
115
±
25
Ω
1000 MΩ @ 50 VDC max.
4 Conductor,
shielded cable 3 ft (0.91 m) long
Pressure Ranges (PSI)
0-6
0-15 to 0-50
0-100 to 0-1000
0-2000 to 0-5000
+ Excitation: Red
+ Signal: Grn
– Excitation: Blk
– Signal: Wht
Shield
(drain)
4 conductor
color coded
shielded cable
3 ft long
(0.91 m)
0.25
(6.4)
1.15
max.
(29.2)
0.935
max. dia.
(23.8)
A
0.749 max. dia.
(19)
Pressure sensitive surface
(diaphragm)
ELECTRICAL
Full Scale Output
Zero Output
Excitation
Input Impedience
Output Impedience
Insulation Resistance
Electrical Connection
Dim. A MAX
0.271
0.232
0.238
0.273
0.287
0.295
(6.9)
(5.9)
(6.1)
(6.9)
(7.3)
(7.5)
0-10000 to 0-15000
0-20000
PERFORMANCE
Accuracy*
0.25% FSO from best fit straight line including
effects of nonlinearity, hysteresis and nonrepeatability
-54° to 93°C (-65° to 200°F)
-54° to 149°C (-65° to 300°F)
with Bendix Connector Option
-1° to 71°C (30° to 160°F)
Less than
±1%
FSO per 100°F within
compensated temperature range
Less than
±1%
per 100°F within
compensated temperature range
Operating
Temperature Range
Compensated
Temperatrue Range
Thermal
Effect on Zero
Thermal Effect
on Full Scale Output
PIN AND WIRE CODES
(Pin codes are for optional bendix connector)
Pin
Code
A
B
C
D
Wire Color
Code
Red
Green
White
Black
Function
+ Excitation
+ Signal
- Signal
- Excitation
Note: All specifications are measured at 25
°
C and rated excitation unless otherwise stated.
Note: For mounting devices, contact factory.
Note: External O-ring included.
*0.5% Accuracy for <50 PSI and
≥
10,000 PSI Units, 1% Accuracy for 20000 PSI Units.
WARRANTY/REMEDY
Honeywell warrants goods of its manufacture as being free of defective materials and faulty workmanship. Contact your local
sales office for warranty information. If warranted goods are returned to Honeywell during the period of coverage, Honeywell
will repair or replace without charge those items it finds defective. The foregoing is Buyer’s sole remedy and is in lieu of all other
warranties, expressed or implied, including those of merchantability and fitness for a particular purpose.
Specifications may change without notice. The information we supply is believed to be accurate and reliable as of this printing.
However, we assume no responsibility for its use.
While we provide application assistance personally, through our literature and the Honeywell web site, it is up to the customer
to determine the suitability of the product in the application.
Item # 1075700 M.G. 3/01 Rev. A
