Material
Plating
Wire Size
Wire Type
High Conductivity
Seamless Copper Tube
Electro-Tin
4/0 STR/FLEX
.44 R Ref
Color coded
barrel markings
PANDUIT
.41±.02 DIA
(2) PLS
3.36±.06
1.03±.04
Wire Strip Length
Stud Size
UL Listed Wire
Connector
1-1/16 in.
3/8 in.
Yes, for applications up to 35kv.
Consult cable manufacturer for
voltage stress relief instructions
with applications greater than
2000 volts.
90 C
Yes
PURPLE
P54
(15)
.81±.04
.38±.04
1.00±.02
UL Temperature
Rating
C.S.A Certified
Wire Connector
Panduit Color Code
on Barrel
Panduit Die Index No.
on Barrel
Alternate Industry
Die Index No. ( )
on Barrel
Beveled wire
entry
Wire inspection window
PURPLE DIE P54 (15)
PANDUIT
4/0 STR/FLEX
LCDXN4/0-38D
Stranded Copper: Class B & C,
Compact, Class G, H, I, K, M,
Locomotive
.65±.01 .81±.01
CERTIFIED
LISTED
Wire Connector
.20±.01
CORP.
02
REV
TINLEY PARK, ILLINOIS
1/11
DATE
JHNU JHNU
REVISED TONGUE THICKNESS: WAS .16
BY
CHK
DESCRIPTION
ECN
REVISED OVERALL LENGTH: WAS 3.34
LCDXN4/0-38D-X
Copper Lug - Narrow Tongue, Two-Hole, Standard Flex Barrel
SCALE
N/A
DRAWING NO / CAD FILE
LCDXN4_0-38D-CUST
