ALUMINUM ELECTROLYTIC CAPACITORS
DQ
Item
Horizontal Mounting Type, Wide Temperature Range
series
Horizontal mounting version for
φ
20 ,
φ
22 and
φ
25.
Suited for use in flat electronic devices where height space is limited.
Adapted to the RoHS directive (2002/95/EC).
DQ
High
Temperature
Specifications
Category
Temperature Range
Rated
Voltage Range
Rated
Capacitance Range
Capacitance Tolerance
Leakage Current
tan
δ
DM
Performance Characteristics
–
40 ~ +105°C (200V) ,
–
25~+105°C (400V)
200
•
400V
68 ~ 1200µF
± 20% at 120Hz, 20°C
I
3
CV
(µA) (After 5 minutes' application of rated voltage)
[C : Rated Capacitance (µF) V : Voltage (V)]
Measurement frequency : 120Hz, Temperature : 20°C
Rated voltage (V)
tan
δ
(MAX.)
200
0.15
200
3
12
400
0.15
Measurement frequency : 120Hz
Stability at Low Temperature
Rated voltage (V)
Z
–
25°C/ Z+20°C
Impedance ratio
Z
–
40°C/ Z+20°C
ZT/Z20(MAX.)
400
8
—
Capacitance change
tan
δ
Leakage current
Capacitance change
tan
δ
Leakage current
Within ±20% of initial value
200% or less of initial specified value
Initial specified value or less
Within ±15% of initial value
150% or less of initial specified value
Initial specified value or less
Endurance
After an application of DC voltage(in the range of rated DC
voltage even after over-lapping the specified ripple current)
for 2000 hours at 105°C, capacitors meet the characteristic
requirements listed at right.
After storing the capacitors under no load at 105°C for 1000
hours, and after performing voltage treatment based
on JIS C 5101-4 clause 4.1 at 20°C,
they will meet the requirements listed at right.
Shelf Life
Marking
Printed with white color letter on black sleeve.
Drawing
L
±2
Sleeve (P.E.T.)
3.5
±1
Type numbering system
(Example
: 200V 470µF)
1
2
3
4
5
6
7
8
9
10 11
12 13 14
Lead wire configurationt
GA :
Left side from the front
L DQ 2 D 4 7 1 M ER Z GA
(
HA :
Right side from the front
)
+1MAX.
Case dia.code
Configuration
Pressure relief vent
0.6
Capacitance tolerance(±20%)
8.0
±2
2.0
P
±1
φ20
: P=7.5
φ22, φ25
: P=8.5
Rated Capacitance(470µF)
Rated voltage(200V)
Series name
Type
φD
20
22
25
Code
Y
Z
A
Dimensions
V(Code)
Cap.(µF)
Co
de
φD
φD
20
200V (2D)
22
25
20
×
30
20
×
30
20
×
35
20
×
40
20
×
45
20
×
50
20
0.56
0.64
0.70
0.75
0.83
0.95
400V (2G)
22
25
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
1200
680
820
101
121
151
181
221
271
331
391
471
561
681
821
102
122
20
×
30
20
×
35
20
×
40
20
×
45
20
×
50
1.10
1.20
1.31
1.45
1.58
22
×
35
22
×
40
22
×
45
22
×
50
22
×
60
0.75
0.88
0.95
1.10
1.22
25
×
35
25
×
40
25
×
45
25
×
50
0.95
1.10
1.22
1.44
22
×
35
22
×
40
22
×
45
22
×
60
1.45
1.60
1.78
2.04
25
×
35
25
×
40
25
×
45
25
×
50
25
×
60
1.60
1.78
2.04
2.30
2.65
Case size
φ
D
×
L (mm)
Rated
ripple
Other rating also available on request.
Rated Ripple (Arms) at 105°C, 120Hz
Frequency coefficient of rated ripple current
Frequency (Hz)
Coeff.
200V
400V
50
0.81
0.77
60
0.85
0.82
120
1.00
1.00
300
1.17
1.16
1k
1.32
1.30
10k
1.45
1.41
50k~
1.50
1.43
Minimum order quantity : 50pcs.
CAT.8100V
