3.2
THESE DRAWINGS ARE THE PROPERTY OF QUALTEK
ELECTRONICS AND NOT TO BE REPRODUCED FOR
OR COMMUNICATED TO A THIRD PARTY WITHOUT
THE EXPRESS WRITTEN PERMISSION OF AN OFFICER
OF QUALTEK ELECTRONICS.
4.8
REVISION
REV.
DESCRIPTION
DATE
APPROVED
15 ±
0.5
0
1
12 ±
0.5
14.5 ± 0.3
R1.3
43.5
35.5 ± 0.5
24 ±
0.5
0
14 ± 0.2
C
2
3
C-C
1.0
A-A
0.8
2 ± 0.05
5
14.5
10.2
27
35.5 ± 0.2
27.3 ±
0
0.2
16 ±
0.5
0
Ø6
3
0.8
31.2
A
USE ONLY WITH A 250V FUSE
A
4.8
.4
Ø3
Ø3.4
4.8
PANEL CUTOUT
C
NOTES:
RATING: 10A 250V AC
APPROVALS: UL, cUL, TUV
DUAL FUSEHOLDER
FUSES NOT INCLUDED - RECOMMENDED SIZE: 5 X 20MM
RoHS COMPLIANT
Dim
range
(mm)
0-1
1-6
6-18
18-50
50-120
120-250
250-500
Tolerance
+/-
(mm)
0.30
0.40
0.45
0.50
0.70
0.90
1.20
CONTROLLED
Qualtek Electronics Corp.
Part Number:
Description:
PPC DIVISION
719WA-00/48
AC RECEPTACLE
UNIT: mm
Drawn / Date
R. Nuti
11-29-11
Checked / Date
11-29-11
Approved / Date
LY / 11-29-11
31.5 ±
0.2
0
34
