Circular Connectors Conforming to JIS C 5432
JR Series
Features
1. These round connectors conform to
JIS C 5432 "Circular connectors for
electric appliances."
Nov.1.2018 Copyright 2018 HIROSE ELECTRIC CO., LTD. All Rights Reserved.
Product Specifications
Shell size
13
16
Ratings
Rated
current
21
Number of contacts
3
5
7
10, 14
10
16
26
4
5, 16
24
Number of contacts
3, 5
7, 10, 14
10, 16, 26
4, 5
16, 24
Rated current
10A
5A
10A
5A
10A
5A (Crimp type : 3A)
5A (Contact numbers A and B only : 10A)
30A
10A
5A (Crimp type : 3A)
Rated voltage
AC250, DC350V
AC1000V, DC1400V
AC250, DC350V
-25 to +85ç
-10 to +60ç
Conditions
Measured at DC 1A
Measured at DC 500V
AC 1,000V for 1 minute
JR 25-4, 5 contacts : AC 3,000V for 1 minute
10 to 55Hz/cycle, amplitude : 0.75mm, 3 directions,
2 hours each
Acceleration : 490m/s
2
, duration : 11ms,
6 axis directions, 3 cycles each
500 times
25
Shell size
13
16
21
25
Ratings
Items
1. Contac resistance
2. Insulation resistance
Operating temperature range
Storage temperature range
Specifications
Ratings
Rated
voltage
5mø max.
JR 21-16 contact crimping type : 10mø max.
JR 25-24 contact crimping type : 10mø max.
1,000Mø min.
JR 25-4 and 5 contacts : 10,000Mø min.
3. Withstanding voltage No flashover or dielectric breakdown.
4. Vibration resistance
5. Shock resistance
6. Mating cycles
No electrical discontinuity for 10µs or greater
No electrical discontinuity for 10µs or greater
Contact resistance : 10mø max.
Insulation resistance : 1,000Mø min.
-40ç : 30 minutes
➝
Normal temperature : 10 to
7. Temperature cycle JR 25-4 and 5 contacts : Insulation resistance : 15 minutes
➝
100ç : 30 minutes
➝
Normal
10,000Mø min.
temperature : 10 to 15 minutes, left for 5 cycles
8. Moisture resistance
Insulation resistance (when dry) 100Mø min.
5,000Mø min. : JR 25-4 , 5 contacts
Temperature : 40ç, relative humidity: 90 to 95%,
left for 96 hours
■
Materials / Finish
Part
Shell
Insulator
Contact
Material
Aluminum alloy
Phenol resin
PPS resin
Copper alloy
Finish
Nickel plating
--------------
Silver plating
Remarks
--------------
UL94V-0
--------------
In cases where the application will demand a high level of reliability, such as automotive,
please contact a company representative for further information.
2018.8⑥
1
JR Series●Circular Connectors Conforming to JIS C 5432
Product Number Structure
Refer to the chart below when determining the product specifications from the product number.
Please select from the product numbers listed in this catalog when placing orders.
JR 16 P A - 10 S C
(**)
❶
❷
❸
❹
❺
❻
❼
½
tNumber
of contacts
qModel
name : JR Series
wShell
size : The shell size is the outer shell diameter of the
yContact
form
mating end of the plug.
P : Male contact
S : Female contact
eShell
type
P : Threaded lock plug
J : Threaded lock jack
uContact
termination method:
R : Threaded lock receptacle BP : Bayonet-lock plug
None : Solder termination
RC : Threaded lock receptacle cap BR : Bayonet-lock receptacle
C
: Crimp termination
rShell
variation : Letters such as A, B, C, etc. indicate
variations in the shell.
iOther
specifications : A two-digit number is added to
indicate other specifications.
Nov.1.2018 Copyright 2018 HIROSE ELECTRIC CO., LTD. All Rights Reserved.
Solder Type
Threaded lock plug
Ｅ
３
Ｚ
Ø
Ｃ
Ø
Ａ
Ｂ
JR25PH-4S
Part No.
JR13PK-3P(71)
JR13PK-5P(71)
JR16PK-7P(71)
JR16PK-10P(71)
JR21PK-10P(71)
JR21PK-16P(71)
JR25PK-16P(71)
JR25PK-24P(71)
JR25PH-4P
JR25PH-5P
JR13PK-3S(71)
JR13PK-5S(71)
JR16PK-7S(71)
JR16PK-10S(71)
JR21PK-10S(71)
JR21PK-16S(71)
JR25PK-16S(71)
JR25PK-24S(71)
JR25PH-4S
HRS No.
114-0501-7 71
114-0502-0 71
114-0503-2 71
114-0504-5 71
114-0505-8 71
114-0506-0 71
114-0507-3 71
114-0508-6 71
114-0626-2
114-0624-7
114-0509-9 71
114-0510-8 71
114-0511-0 71
114-0512-3 71
114-0513-6 71
114-0514-9 71
114-0515-1 71
114-0516-4 71
114-0627-5
No. of
contacts
3
5
7
10
20.5
16
24
4
5
3
5
7
10
20.5
16
24
4
24.7
M30×1
33.8
18
56.5
M26×1
29.8
15
53.5
12.7
16.3
M18×1
M22×1
21.8
25.8
8.5
11.5
45.5
49.5
24.7
M30×1
33.8
18
56.5
M26×1
29.8
15
53.5
ØA
12.7
16.3
B
M18×1
M22×1
ØC
21.8
25.8
ØD
8.5
11.5
E
45.5
49.5
JIS No.
CNR01SPM013003
CNR01SPM013005
CNR01SPM016007
CNR01SPM016010
CNR01SPM021010
CNR01SPM021016
CNR01SPM025016
CNR01SPM025024
--------------
--------------
CNR01SPF013003
CNR01SPF013005
CNR01SPF016007
CNR01SPF016010
CNR01SPF021010
CNR01SPF021016
CNR01SPF025016
CNR01SPF025024
--------------
2
Ø
Ｄ
Ｙ
４
１
２
Ｘ
