Connectors for Aluminum/Copper Code Conductor
COMPRESSION
Two Way Connectors for 600V to 35KV 90°C Applications
AL and CU concentric conductors and compact code AL strandings
Conductor
Code
10 Str.
8 Str.
6 Str.
4 Str.
2 Str./3 Str.
1 Str.
1/0
2/0
3/0
4/0
250 kcmil
300 kcmil
350 kcmil
400 kcmil
500 kcmil
600 kcmil
700 kcmil
750 kcmil
1000 kcmil
Color
Code
Red
Blue
Gray
Green
Pink
Gold
Tan
Olive
Ruby
White
Red
Blue
Brown
Green
Pink
Black
Purple
Yellow
Dim. (in.)
A
1.00
1.19
1.63
1.81
1.81
2.38
2.38
2.50
2.81
3.66
3.91
3.97
4.97
4.97
4.97
5.22
5.44
5.69
6.69
E
.27
.28
.35
.46
.51
.56
.62
.70
.77
.86
.92
.99
1.09
1.18
1.28
1.36
1.44
1.50
1.77
Cat. No.
Designed for aluminum/copper metals, these
two-way connectors permit aluminum conduc-
tors to be spliced to copper conductors, as well
as aluminum-to-aluminum conductors.
60500
60501
60507
60512
60516
60522
60530
60536
60542
60548
60554
60560
60565
60568
60571
60574
60576
60578
60584
Material – High Conductivity Wrought Aluminum
Finish – Electro-Tin Plated
®
®
Aluminum Reducing Connectors for 600V 90°C Applications
Cat. No.
60905
60910
60915
60925
60930
60935
60940
60945
60950
60955
60960
60965
60970
60975
60980
60985
Cable Size
Aluminum
Copper
8
6
4
1
1/0
2/0
3/0
4/0
250 kcmil
300 kcmil
350 kcmil
400 kcmil
500 kcmil
600 kcmil
700 kcmil
750 kcmil
10
8
6
3
2
1
1/0
2/0
3/0
4/0
4/0
250 kcmil
350 kcmil
400 kcmil
500 kcmil
500 kcmil
Dimensions (in.)
A
E
m
1e
1m
2c
2c
2d
2m
3f
4
4h
5h
5h
5h
5j
5l
5m
s
X
k
w
e
L
f
g
n
1
1p
1r
1j
1X
1k
1d
Color
Key
Blue
Gray
Green
Gold
Tan
Olive
Ruby
White
Red
Blue
Brown
Green
Pink
Black
Purple
Yellow
Die
Code
24
29
37
45
50
54
60
66H
71H
76H
87H
94H
99H
106H
112H
115H
Reducing connectors are designed for splicing
aluminum to copper conductors of equal
ampacities. Connectors are made in the right
combination of equivalent sizes. (Example: one
end for 4/0 aluminum, the other end for 2/0
copper.)
• Material – High Conductivity Wrought
Aluminum
• Finish – Electro-TIn Plated
Selection table gives aluminum/copper equivalents for all sizes. Connectors are filled with a high temperature oxide
inhibiting compound.
Installing Tools: TBM5(s) #10
➔
4/0
TBM6(s) #10
➔
350 kcmil
TBM8(s) #10
➔
350 kcmil
RUBY DIE
RUBY DIE
RUBY DIE
RUBY DIE
1/0 CU
T&B
3/0 AL
E
A
Tooling: Pg. 79-100
Die Selector Chart: Pg. 105-109
Smaller I.D. end
for Copper cable
Larger I.D. end
for Alum. cable
© 2002 Thomas & Betts Corporation. Specifications are subject to change without notice.
