5962-9561320HUA datasheet, PDF

Datasheet> All Categories > storage> 5962-9561320HUA

5962-9561320HUA: DescriptionStandard SRAM, 512KX8, 45ns, CMOS, CDFP36, CERAMIC, DFP-36; Categorystorage; File Size3MB，939 Pages; ManufacturerWhite Electronic Designs Corporation; Websitehttp://www.wedc.com/

Download Datasheet Parametric View All

5962-9561320HUA Overview

Standard SRAM, 512KX8, 45ns, CMOS, CDFP36, CERAMIC, DFP-36

5962-9561320HUA Parametric

Parameter Name	Attribute value
Maker	White Electronic Designs Corporation
package instruction	CERAMIC, DFP-36
Reach Compliance Code	unknown
Is Samacsys	N
Maximum access time	45 ns
I/O type	COMMON
JESD-30 code	R-CDFP-F36
JESD-609 code	e0
length	23.365 mm
memory density	4194304 bit
Memory IC Type	STANDARD SRAM
memory width	8
Number of functions	1
Number of terminals	36
word count	524288 words
character code	512000
Operating mode	ASYNCHRONOUS
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
organize	512KX8
Output characteristics	3-STATE
Package body material	CERAMIC, METAL-SEALED COFIRED
encapsulated code	DFP
Encapsulate equivalent code	FL36,.5
Package shape	RECTANGULAR
Package form	FLATPACK
Parallel/Serial	PARALLEL
power supply	5 V
Certification status	Not Qualified
Filter level	MIL-STD-883
Maximum seat height	3.18 mm
Maximum standby current	0.0026 A
Minimum standby current	2 V
Maximum slew rate	0.16 mA
Maximum supply voltage (Vsup)	5.5 V
Minimum supply voltage (Vsup)	4.5 V
Nominal supply voltage (Vsup)	5 V
surface mount	YES
technology	CMOS
Temperature level	MILITARY
Terminal surface	TIN LEAD
Terminal form	FLAT
Terminal pitch	1.27 mm
Terminal location	DUAL
width	12.955 mm
Base Number Matches	1

Preview

Download Datasheet

View All

NOT MEASUREMENT
