This document was generated on 03/01/2018
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Overview:
Description:
0349690140
Active
Stac64 Single, Multi-Pocket and Hybrid Header System
Stac64 Hybrid Receptacle Assembly, 14 Circuit, Black, Polarization A
Documents:
3D Model
Drawing (PDF)
Product Specification PS-34969-100-001 (PDF)
General
Product Family
Series
Application
Comments
Application Specification AS-34729-020-001 (PDF)
Packaging Specification PK-31301-201 (PDF)
RoHS Certificate of Compliance (PDF)
Series image - Reference only
Crimp Housings
34969
Power, Signal, Wire-to-Board
Current is dependent on connector size, ambient
temperature, blade size and related factors. 2.80mm –
30.0A; 0.64mm - 6.0A. . Polarization A, 10 x 0.64 and 4
x 2.8
Stac64 Single, Multi-Pocket and Hybrid Header System
Stac64
887191311913
14
21 x 0.64 and 4 x 2.8
Black
Receptacle
No
Yes
No
Modified Polystyrene
7.690/g
2
Carton
No
2.54mm, 5.25mm
Yes
1
No
-40°C to +105°C
30.0A, 6.0A
N/A
EU ELV
Compliant
EU RoHS
China RoHS
Compliant
REACH SVHC
Not Contained Per
-ED/01/2018 (15
January 2018)
Halogen-Free
Status
Not Relevant
Need more information on product
environmental compliance?
Email productcompliance@molex.com
Please visit the Contact Us section for any
non-product compliance questions.
China ROHS
ELV
RoHS Phthalates
Not Relevant
Compliant
Not Contained
Overview
Product Name
UPC
Physical
Circuits (maximum)
Circuits Detail
Color - Resin
Gender
Glow-Wire Capable
Keying to Mating Part
Lock to Mating Part
Material - Resin
Net Weight
Number of Rows
Packaging Type
Panel Mount
Pitch - Mating Interface
Polarized to Mating Part
Ports
Stackable
Temperature Range - Operating
Electrical
Current - Maximum per Contact
Solder Process Data
Lead-freeProcess Capability
Material Info
Reference - Drawing Numbers
Application Specification
Packaging Specification
Product Specification
Sales Drawing
Search Parts in this Series
34969 Series
Mates With
34773 , 34772 Stac64 Hybrid Receptacle
Connector
Use With
CTX64 Terminal 34803
AS-34729-020-001
PK-31301-201
PS-34969-100-001
SD-34969-010
This document was generated on 03/01/2018
