PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Overview:
Description:
0761651126
Active
Impact Backplane Connector and Cable Assembly System
Impact 100 Ohm 3 Pair Vertical Backplane Header, Unguided, Dual Endwall, 10
Columns, 90 Circuits, Pin Length 4.50mm, Plated Through Hole Dimension 0.39mm,
Lead-Free
Documents:
3D Model
Drawing (PDF)
Product Specification PS-76060-999-001 (PDF)
Application Specification AS-76060-990-001 (PDF)
Agency Certification
UL
General
Product Family
Series
Application
Application Tooling Documents
Component Type
Overview
Product Name
UPC
Physical
Circuits (Loaded)
Circuits (maximum)
Color - Resin
Durability (mating cycles max)
First Mate / Last Break
Flammability
Guide to Mating Part
Keying to Mating Part
Material - Metal
Material - Plating Mating
Material - Plating Termination
Material - Resin
Net Weight
Number of Columns
Number of Pairs
Number of Rows
Orientation
PC Tail Length
PCB Locator
PCB Retention
PCB Thickness - Recommended
Packaging Type
Pitch - Mating Interface
Pitch - Termination Interface
Plating min - Mating
Polarized to PCB
Stackable
Temperature Range - Operating
Termination Interface: Style
Application Specification AS-76060-9999-001 (PDF)
Packaging Specification PK-70873-7700 (PDF)
RoHS Certificate of Compliance (PDF)
Series image - Reference only
EU ELV
Not Relevant
E29179
Backplane Connectors
76165
Conventional, Mezzanine
TM-622018799
PCB Header
Impact Backplane Connector and Cable Assembly
System
Impact
883906400620
90
90
Black
200
No
94V-0
No
None
High Performance Alloy (HPA)
Gold
Tin
High Temperature Thermoplastic
2.677/g
10
3
9
Vertical
1.40mm
No
None
1.00mm
Tray
1.90mm
1.90mm
0.762µm
No
No
-55°C to +85°C
Through Hole - Compliant Pin
EU RoHS
China RoHS
Compliant
REACH SVHC
Not Contained Per -
ED/30/2017 (7 July
2017)
Halogen-Free
Status
Low-Halogen
Need more information on product
environmental compliance?
Email productcompliance@molex.com
Please visit the Contact Us section for any
non-product compliance questions.
China ROHS
ELV
RoHS Phthalates
Green Image
Not Relevant
Not Contained
Search Parts in this Series
76165 Series
Mates With
76170 Impact 100 Ohm Daughtercard
Use With
75234 Backplane Free Standing Guide Pin
Electrical
Current - Maximum per Contact
Data Rate
Impedance
Shield Type
Shielded
Voltage - Maximum
Material Info
Reference - Drawing Numbers
Application Specification
Packaging Specification
Product Specification
Sales Drawing
Symbol/Footprint Data
0.75A
25.0 Gbps
100Ω
N/A
No
30V AC (RMS)/DC
AS-76060-990-001, AS-76060-9999-001
PK-70873-7700
PS-76060-999-001
SD-76165-001-001
SYM-76165-1126
