370-001 Cable Sealing Backshell with Rotatable
Coupling for 38999 Series III Type Connectors
How To Order
Sample Part Number
Series/Basic Part No.
Connector Designator
Angular Function
Basic Part No.
Finish
Shell Size
Dash No.
Strain Relief Style
Length
370
- low Profile
H
= 38999
A
= 90°
001
370
H
S
001
M
17
03
D
1.5
M
M-10
MIL-DTL-38999 Type
A Thread
C Typ.
B
= 45°
S
= Straight
See Material and Finish Table
15, 17, 19
See Dash Number Table
D
= Nut
1/2 inch increments (e.g. 6 = 3 inches); Straight only
Minimum Order Length 1.5 Inch (See Note 1)
Straight (S)
Length ± .060 (1.52)
O-Ring
45° (B)
E
90° (A)
G
F
H
STRAIN RELIEF STYLE D
.135 (3.4)
Max
Dimensions
Shell
Size
15
17
19
A Thread
M22 X 1 -- 6H
M25 X 1 -- 6H
M28 X 1 -- 6H
C Typ.
1.07 (27.2)
1.21 (30.7)
1.36 (34.5)
E Max
.645 (16.4)
.738 (18.7)
.926 (23.5)
F Max
2.359 (59.9)
2.469 (62.7)
2.659 (67.5)
G Max
.700 (17.8)
.885 (22.5)
.975 (24.8)
H Max
2.369 (60.2)
2.459 (62.5)
2.629 (66.8)
Cable
Range
Z
Materials and Finishes
1
NF
Aluminum/Cadmium, olive drab
ME
Aluminum/Electroless nickel
MT
Aluminum/ Nickel PTFE
ZR
Aluminum/ Black zinc-nickel
Dash
No.
03
04
06
Dash Number
Cable Range
Z Max
.630 (16.0)
.755 (19.2)
.942 (23.9)
Min
.156 (4.0)
.188 (4.8)
.281 (7.1)
Max
.250 (6.4)
.312 (7.9)
.438 (11.1)
