TECHNICAL DATA SHEET
6 Lake Street, Lawrence, MA 01841
1-800-446-1158 / (978) 620-2600 / Fax: (978) 689-0803
Website: http: //www.microsemi.com
Gort Road Business Park, Ennis, Co. Clare, Ireland
Tel: +353 (0) 65 6840044 Fax: +353 (0) 65 6822298
PNP SILICON LOW POWER TRANSISTOR
Qualified per MIL-PRF-19500/350
DEVICES
LEVELS
2N3867
2N3868
2N3867S
2N3868S
JAN
JANTX
JANTXV
JANS
ABSOLUTE MAXIMUM RATINGS
(T
C
= +25°C unless otherwise noted)
Parameters / Test Conditions
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
Collector Current
Total Power Dissipation
@ T
A
= +25°C
(1)
Operating & Storage Junction Temperature Range
THERMAL CHARACTERISTICS
Parameters / Test Conditions
Thermal Resistance, Junction-to-Ambient
Symbol
R
θJA
Max.
175
Unit
°C/mW
Symbol 2N3867
V
CBO
V
CEO
V
EBO
I
C
P
T
T
J
, T
stg
40
40
4.0
3.0
1.0
-65 to +200
2N3868
60
60
Unit
Vdc
Vdc
Vdc
mAdc
W/°C
°C
TO-5 *
2N3867, 2N3868
Note: *
Electrical characteristics for “S” suffix devices are identical to the “non S”
corresponding devices.
1/ Derate linearly 5.71mW/°C for T
A
> +25°C
2/ Derate linearly 57.1mW/°C for T
C
> +25°C
ELECTRICAL CHARACTERISTICS
(T
A
= +25°C, unless otherwise noted)
Parameters / Test Conditions
OFF CHARACTERTICS
Collector-Emitter Breakdown Current
2N3867, S
I
C
= 10μAdc
2N3868, S
Collector-Base Cutoff Current
V
CB
= 40Vdc
2N3867, S
V
CB
= 60Vdc
2N3868, S
Emitter-Base Cutoff Current
V
EB
= 4.0Vdc
Collector-Emitter Cutoff Current
V
CE
= 40Vdc
2N3867, S
V
CE
= 60Vdc
2N3868, S
2N3867, S
V
CE
= 40Vdc, T
A
= +150°C
2N3868, S
V
CE
= 60Vdc, T
A
= +150°C
T4-LDS-0170 Rev. 1 (101121)
Symbol
Min.
Max.
Unit
V
(BR)CEO
I
CBO
I
EBO
40
60
100
100
1.0
1.0
50
50
Vdc
µAdc
µAdc
TO-39 * (TP-205AD)
2N3867S, 2N3868S
I
CEX
µAdc
Page 1 of 4
TECHNICAL DATA SHEET
6 Lake Street, Lawrence, MA 01841
1-800-446-1158 / (978) 620-2600 / Fax: (978) 689-0803
Website: http: //www.microsemi.com
Gort Road Business Park, Ennis, Co. Clare, Ireland
Tel: +353 (0) 65 6840044 Fax: +353 (0) 65 6822298
ELECTRICAL CHARACTERISTICS
(T
A
= +25°C, unless otherwise noted) (CONT.)
Parameters / Test Conditions
ON CHARACTERTICS
(2)
Forward-Current Transfer Ratio
I
C
= 500mAdc, V
CE
= 1.0Vdc
I
C
= 1.5Adc, V
CE
= 2.0Vdc
I
C
= 2.5Adc, V
CE
= 3.0Vdc
I
C
= 3.0Adc, V
CE
= 5.0Vdc
I
C
= 500mAdc, V
CE
= 1.0Vdc, T
A
= -55°C
Collector-Emitter Saturation Voltage
I
C
= 500mAdc, I
B
= 50mAdc
I
C
= 1.5Adc, I
B
= 150mAdc
I
C
= 2.5Adc, I
B
= 250mAdc
Base-Emitter Saturation Voltage
I
C
= 500mA, I
B
= 50mAdc
I
C
= 1.5A, I
B
= 150mAdc
I
C
= 2.5A, I
B
= 250mAdc
DYNAMIC CHARACTERISTICS
Parameters / Test Conditions
Magnitude of Common Emitter Small-Signal Short Circuit
Forward Current Transfer Ratio
I
C
= 100mAdc, V
CE
= 5.0Vdc, f = 20MHz
Output Capacitance
V
CB
= 10Vdc, I
E
= 0, 100 kHz
≤
f
≤
1.0MHz
Iutput Capacitance
V
EB
= 3.0Vdc, I
C
= 0, 100 kHz
≤
f
≤
1.0MHz
(2) Pulse Test: Pulse Width = 300μs, Duty Cycle
≤
2.0%
Symbol
|h
fe
|
Min.
3
Max.
12
Unit
kΩ
2N3867, S
2N3868, S
V
BE(sat)
0.9
0.85
1.0
1.4
1.4
2.0
Vdc
2N3867, S
2N3868, S
2N3867, S
2N3868, S
2N3867, S
2N3868, S
2N3867, S
2N3868, S
2N3867, S
2N3868, S
h
FE
50
35
40
30
25
20
20
20
25
17
0.5
0.75
1.5
200
150
Symbol
Min.
Max.
Unit
V
CE(sat)
Vdc
C
obo
120
pF
C
ibo
800
pF
T4-LDS-0170 Rev. 1 (101121)
Page 2 of 4
TECHNICAL DATA SHEET
6 Lake Street, Lawrence, MA 01841
1-800-446-1158 / (978) 620-2600 / Fax: (978) 689-0803
Website: http: //www.microsemi.com
Gort Road Business Park, Ennis, Co. Clare, Ireland
Tel: +353 (0) 65 6840044 Fax: +353 (0) 65 6822298
SWITCHING CHARACTERISTICS
Parameters / Test Conditions
Delay Time
Rise Time
Storage Time
Fall Time
V
CC
= -30dc, V
EB
= 0
I
C
= 1.5Adc, I
B1
= 150mAdc
V
CC
= -30dc, V
EB
= 0
I
C
= 1.5Adc, I
B1
= I
B2
= 150mAdc
t
Symbol
t
t
t
Min.
Max.
35
65
500
100
100
600
Unit
nS
nS
nS
nS
d
r
s
f
t
Turn-On Time
V
CC
= 30, I
C
= 1.5Adc, I
B
= 150mA
Turn-Off Time
V
CC
= 30, I
C
= 1.5Adc, I
B
= 150mA
SAFE OPERATING AREA
DC Test
T
C
= 25°C, 1 cycle, t = 1.0s
Test 1
V
CE
= 3.33Vdc, I
C
= 3.0Adc
Test 2
V
CE
= 40Vdc, I
C
= 160mAdc
V
CE
= 60Vdc, I
C
= 80mAdc
2N3867,
2N3868, S
on
t
off
T4-LDS-0170 Rev. 1 (101121)
Page 3 of 4
TECHNICAL DATA SHEET
6 Lake Street, Lawrence, MA 01841
1-800-446-1158 / (978) 620-2600 / Fax: (978) 689-0803
Website: http: //www.microsemi.com
Gort Road Business Park, Ennis, Co. Clare, Ireland
Tel: +353 (0) 65 6840044 Fax: +353 (0) 65 6822298
PACKAGE DIMENSIONS
Dimensions
Inches
Millimeters
Min Max Min
Max
.305 .335 7.75
8.51
.240 .260 6.10
6.60
.335 .370 8.51
9.40
.200 TP
5.08 TP
.016 .019 0.41
0.48
See note 8, 14
.016 .019 0.41
0.48
.050
1.27
.250
6.35
.100
2.54
.030
0.76
.029 .045 0.74
1.14
.028 .034 0.71
0.86
.010
0.25
45° TP
45° TP
1, 2, 10, 12, 13, 14
Symbol
TO-5, 39
Note
5, 6
4, 5
7
8,9
8,9
8,9
8,9
7
5
3,4
3
10
7
CD
CH
HD
LC
LD
LL
LU
L
1
L
2
P
Q
TL
TW
R
α
NOTES:
1. Dimensions are in inches.
2. Millimeters are given for general information only.
3. Beyond r (radius) maximum, TW shall be held for a minimum length of .011 (0.28 mm).
4. Dimension TL measured from maximum HD.
5. Body contour optional within zone defined by HD, CD, and Q.
6. CD shall not vary more than .010 inch (0.25 mm) in zone P. This zone is controlled for automatic handling.
7. Leads at gauge plane .054 +.001 -.000 inch (1.37 +0.03 -0.00 mm) below seating plane shall be within .007 inch (0.18
mm) radius of true position (TP) at maximum material condition (MMC) relative to tab at MMC. The device may be
measured by direct methods or by gauging procedure.
8. Dimension LU applies between L
1
and L
2
. Dimension LD applies between L
2
and LL minimum. Diameter is
uncontrolled in and beyond LL minimum.
9. All three leads.
10. The collector shall be internally connected to the case.
11. Dimension r (radius) applies to both inside corners of tab.
12. In accordance with ASME Y14.5M, diameters are equivalent to
φx
symbology.
13. Lead 1 = emitter, lead 2 = base, lead 3 = collector.
14. For non-S-suffix devices (TO-5), dimension LL = 1.5 inches (38.10 mm) min. and 1.75 inches (44.45 mm) max. For S-
suffix types (TO-39), dimension LL = .5 inch (12.70 mm) min. and .750 inch (19.05 mm) max.
FIGURE 1.
Physical dimensions (similar to TO-5, TO-39)
T4-LDS-0170 Rev. 1 (101121)
Page 4 of 4
