09-52-2097 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> The connector> 09-52-2097

09-52-2097: DescriptionHeaders & Wire Housings KK 156 PBC Assy RtAn 09 Ckt Tin; CategoryThe connector The connector; File Size141KB，5 Pages; ManufacturerMolex; Websitehttps://www.molex.com/molex/home; Environmental Compliance

Download Datasheet Parametric View All

09-52-2097 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	09-52-2097	-	-	View	Buy Now

09-52-2097 Overview

Headers & Wire Housings KK 156 PBC Assy RtAn 09 Ckt Tin

09-52-2097 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Molex
Reach Compliance Code	compliant
Is Samacsys	N
Other features	POLARIZED
Connector type	BOARD CONNECTOR
Contact to complete cooperation	NOT SPECIFIED
Contact point gender	FEMALE
Contact material	NOT SPECIFIED
DIN compliance	NO
Filter function	NO
IEC compliance	NO
MIL compliance	NO
Plug information	MULTIPLE MATING PARTS AVAILABLE
Mixed contacts	NO
Installation method	RIGHT ANGLE
Installation type	BOARD
Number of rows loaded	1
Options	GENERAL PURPOSE
Terminal pitch	3.96 mm
Termination type	SOLDER
Total number of contacts	9
UL Flammability Code	94V-2
Base Number Matches	1

Preview

Download Datasheet

View All

A REF

.308

7.82

.464

11.79

.620

15.75

CENTER HOOK(S)

LOCATED BETWEEN

CIRCUITS

.156

.005

3.96

0.13

.312

.005

7.92

0.13

.468

.005

11.89

0.13

.624

.005

15.85

0.13

.780

.005

19.81

0.13

.936

.010

23.77

0.25

1.092

.010

27.74

0.25

1.248

.010

31.70

0.25

1.404

.010

35.66

0.25

1.560

.010

39.62

0.25

1.716

.010

43.59

0.25

1.872

.010

47.55

0.25

2.028

.014

51.51

0.36

2.184

.014

55.47

0.36

NONE

4&5

5&6

4 & 5,

8&9

6 & 7,

11 & 12

5 & 6,

9 & 10

5 & 6,

10 & 11

REF

.776

19.71

+.038

-.000

+0.97

-0.00

.075

1.91

.932

23.67

1.088

27.64

1.244

31.60

1.400

35.56

1.556

39.52

1.712

43.48

1.868

47.45

2.024

51.41

2.180

55.37

2.336

59.33

SEE NOTE 8

CENTER HOOK(S)

SEE CHART FOR LOCATION(S)

.31

7.9

REF

NOTES:

1. HOUSING MATERIAL: NYLON, UL 94V-2

2. FINISH:

(197) OVERALL REFLOWED MATTE TIN: 0.00152/.000060 MIN.

OVER 0.00127/.000050 MIN. NICKEL OVERALL.

(208) SELECT GOLD: .000015/0.00038 MIN.

SELECT TIN: .000100/0.00254 MIN.

OVERALL NICKEL UNDERPLATE: .000050/0.00127 MIN.

(909) OVERALL HOT TIN DIP: .000100/0.00254 MIN.

3. PRODUCT SPECIFICATION: PS-08-50

4. PACKAGING INFO: SEE CHARTS.

5. SOLDERABILITY SPECIFICATION: SMES-152.

6. TOP ENTRY OPTIONS: SEE DRAWING SDA-2145-002.

7. BOTTOM ENTRY OPTIONS: SEE DRAWING SDA-2145-003

8. .183/4.64 DIMENSION IS BOTTOM OF HOUSING TO CENTER OF MATING PIN AND

DOES NOT REFLECT CENTER OF THE CONNECTOR HOUSING WINDOW DIMENSION.

9. THIS PART CONFORMS TO CLASS B REQUIREMENTS OF COSMETIC SPECIFICATION

PS-45499-002.

2016/08/22

2016/08/24

2016/08/26

DIMENSION UNITS

REV.

SHT

THIS DRAWING CONTAINS INFORMATION THAT IS PROPRIETARY TO MOLEX ELECTRONIC TECHNOLOGIES, LLC AND SHOULD NOT BE USED WITHOUT WRITTEN PERMISSION

GENERAL TOLERANCES

(UNLESS SPECIFIED)

SCALE

INCH/MM

DRWN BY

DATE

NTS

DIM C TOLERANCE

INCH

0.01

0.015

4 PLACES

3 PLACES

2 PLACES

0.25

107740

MKIPPER

JBELL

FSMITH

SAMIEC

CHK'D BY

DATE

1998/10/09

DATE

PCB LAYOUT: COMPONENT SIDE

RECOMMENDED PCB THICKNESS: .062/1.57

RELEASE STATUS

FORMAT: Eng-lega-master-tb-prod-A

REVISION: C

DATE: 2016/02/04

SAMIEC

APPR BY

KK 156 PCB ASSY

RIGHT ANGLE ENTRY

PRODUCT CUSTOMER DRAWING

SERIES

MATERIAL NUMBER

CUSTOMER

1 PLACES

0.38

0 PLACES

ANGULAR TOL

SAMIEC

DRAWING SIZE

1998/10/09

THIRD ANGLE PROJECTION

EC NO:

DRWN:

CHK'D:

APPR:

RELEASE DATE

DRAFT WHERE APPLICABLE

MUST REMAIN

WITHIN DIMENSIONS

REV

2145

DOCUMENT NUMBER

SEE CHART

GENERAL MARKET

DOC TYPE DOC PART

SHEET NUMBER

SDA-2145-001

PSD

000

1 OF *
