M I C
of Crystek Corporation
ROWAVE
A Division
Temperature Range:
Rated Power:
Frequency Range:
VSWR:
Impedance:
Attenuation Tolerance:
-40°C to +85°C
2 Watts Max
DC to 1 GHz
1:1.3 Max
50 Ohms
±0.3 dB
The Attenuator offers end users a rugged BNC attenuator housing for easy connection.
The CATTEN-08R0-BNC provides 2 Watts of power dissipation. Tolerance matching
is used to provide superior temperature tracking to individual components. Attenuator
frequency range is from DC to 1 GHz.
Product Control:
Crystek Part Number:
Revision Level:
CATTEN-08R0-BNC
D
Release Date:
Responsible:
03-Feb-2016
K. Piotrowicz
CRYSTEK
CORPORATION
12730 Commonwealth Drive • Fort Myers, Florida 33913
Phone: 239-561-3311 • 800-237-3061
Fax: 239-561-1025 • www.crystek.com
Page 1 of 2
M I C
of Crystek Corporation
ROWAVE
A Division
Part Number
CATTEN-01R0-BNC
CATTEN-01R5-BNC
CATTEN-02R0-BNC
CATTEN-03R0-BNC
CATTEN-04R0-BNC
CATTEN-05R0-BNC
CATTEN-06R0-BNC
CATTEN-07R0-BNC
CATTEN-08R0-BNC
CATTEN-09R0-BNC
CATTEN-0100-BNC
CATTEN-0150-BNC
CATTEN-0200-BNC
Attenuation Max Power
(dB)
(Watts)
1.0
1.5
2.0
3.0
4.0
5.0
6.0
7.0
8.0
9.0
10.0
15.0
20.0
2
2
2
2
2
2
2
2
2
2
2
2
2
8 dB Data
Freq.
(MHz)
0.3
5.3
40.3
70.3
90.3
100.3
110.3
160.3
200.2
250.2
300.2
350.2
400.2
450.2
Atten
(dB)
8.0
8.0
8.0
8.0
8.0
8.0
8.0
8.0
8.0
8.0
8.0
8.1
8.1
8.1
8.1
8.1
8.1
8.1
8.1
8.2
8.2
8.3
Return
Loss
(dB)
63.4
52.7
45.6
43.5
42.4
41.9
41.4
39.9
38.2
34.2
31.8
31.5
31.8
31.2
30.6
29.6
27.9
27.6
31.3
30.0
25.6
35.2
2.590
(65.79)
1.480
(37.59)
500.2
550.1
600.1
0.550
(13.97)
650.1
700.1
BNC
Male
BNC
Female
800.1
900.0
1000.0
Rev D
CRYSTEK
CORPORATION
12730 Commonwealth Drive • Fort Myers, Florida 33913
Phone: 239-561-3311 • 800-237-3061
Fax: 239-561-1025 • www.crystek.com
Page 2 of 2
