AQY414SX Overview

TRANSISTOR OUTPUT SOLID STATE RELAY

AQY414SX Parametric

Parameter Name	Attribute value
state	ACTIVE
Optoelectronic device type	TRANSISTOR OUTPUT

Preview

Download Datasheet

View All

TESTING

GU (General Use) Type

SOP Series

1- Channel (Form B)

4-Pin Type

(6-pin)

4.3±0.2

.169±.008

4.4±0.2

.173±.008

2.1±0.2

.083±.008

PhotoMOS

RELAYS

3. Tape and reel

The device comes standard in a tape and

reel (1,000 pcs./reel) to facilitate automatic

insertion machines.

4. Controls low-level analog signals

PhotoMOS relays feature extremely low

closed-circuit offset voltage to enable con-

trol of low-level analog signals without dis-

tortion.

5. Low-level off state leakage current

In contrast to the SSR with an off state

leakage current of several milliamps, the

PhotoMOS relay features a very small off

state leakage current of 1nA even with the

rated load voltage of 350 V (AQY410S).

(4-pin)

Approx. 70%

Volume

inch

Footprint

Approx. 70%

2. Low on resistance for normally-

closed type

This has been realized thanks to the built-

in MOSFET processed by our proprietary

method, DSD (Double-diffused and Se-

lective Doping) method.

Cross section of the normally-closed type of

power MOS

Passivation membrane

Intermediate

Source electrode Gate electrode

insulating

membrane

Gate

oxidation

membrane

N–

FEATURES

Drain

electrode

1. SO package 4-Pin type in super min-

iature design

The device comes in a super-miniature

SO package 4-Pin type measuring (W)

4.3

(L) 4.4

(H) 2.1 mm

(W) .169

(L)

.173

(H) .083 inch

—approx. 70% of the

volume and 70% of the footprint size of SO

package 6-pin type PhotoMOS Relays.

TYPICAL APPLICATIONS

• Telecommunications (PC, Electoronic

Notepad)

• Measuring and Testing equipment

• Factory Automation Equipment

• Security equipment

• High speed inspection machines

TYPES

AC/DC type

Output rating*

Part No.

Packing quantity in tape

and reel

Load voltage

Load current

Picked from the 1/2-pin side

Picked from the 3/4-pin side

350 V

120 mA

AQY410SX

AQY410SZ

1,000 pcs.

400 V

100 mA

AQY414SX

AQY414SZ

* Indicate the peak AC and DC values.

Notes: (1) Tape package is the standard packing style. Also available in tube. (Part No. sufﬁx "X" or "Z" is not needed when ordering; Tube: 100 pcs.;

Case: 2,000 pcs.)

(2) For space reasons, the top two letters of the product number "AQY" and "S" are omitted on the product seal. The package type indicator "X"

and "Z" are omitted from the seal. (Ex. the label for product number AQY414S is 414).

RATING

AC/DC type

1. Absolute maximum ratings (Ambient temperature: 25

Item

LED forward current

LED reverse voltage

Input

Peak forward current

Power dissipation

Load voltage (peak AC)

Continuous load current

(peak AC)

Output

Peak load current

Power dissipation

Total power dissipation

I/O isolation voltage

Temperture Operating

limits

Storage

Symbol

peak

out

iso

opr

stg

AQY410S

50 mA

75 mW

350 V

0.12 A

0.3 A

400 V

0.1 A

100ms (1 shot), V

= DC

AQY414S

Remarks

f = 100 Hz, Duty factor = 0.1%

0.24 A

300 mW

350 mW

1,500 V AC

–40

C to +85

–40

F to +185

–40

C to +100

–40

F to +212

Non-condensing at low temperatures
