QUICK REFERENCE DATA
DESCRIPTION
Nominal case size
Ø D x L in inches (mm)
Operating temperature
Rated capacitance range, C
R
Tolerance on C
R
Rated voltage range, U
R
Life validation test at 85 °C
DC leakage current
36D
36DE, 36DX
I = k CV
I in μA, C in μF, V in Volts
VALUE
1.453 x 2.250 (36.9 x 57.2) to 3.078 x 8.750 (78.2 x 222.3)
-40 °C to +85 °C (36DX)
-40 °C to +95 °C (36DE)
190 μF to 50 000 μF
+75 %, -10 % (10 WV
DC
to 100 WV
DC
)
+50 %, -10 % (200 WV
DC
to 450 WV
DC
)
10 WV
DC
to 450 WV
DC
1000 h:
CAP
± 15 % from initial measurement.
ESR
1.5 x initial specified limit
k = 6.0 at +25 °C, k = 36 at +65 °C, k = 50 at +85 °C
k = 4.0 at +25 °C, k = 32 at +85 °C
DIMENSIONS
in inches (millimeters)
LARGE CAN CAPACITORS
CASE
CODE
AN
AY
AA
AM
AB
AL
AC
AD
AE
AF
EN
EA
EM
EB
EL
EC
ED
NOMINAL
D
± 0.032 (0.8)
1.375 (35.0)
1.375 (35.0)
1.375 (35.0)
1.375 (35.0)
1.375 (35.0)
1.375 (35.0)
1.375 (35.0)
1.375 (35.0)
1.375 (35.0)
1.375 (35.0)
1.750 (44.0)
1.750 (44.0)
1.750 (44.0)
1.750 (44.0)
1.750 (44.0)
1.750 (44.0)
1.750 (44.0)
L
± 0.063 (1.6)
1.625 (41.0)
1.875 (48.0)
2.125 (54.0)
2.625 (67.0)
3.125 (79.0)
3.625 (92.0)
4.125 (105.0)
4.625 (117.0)
5.125 (130.0)
5.625 (143.0)
1.625 (41.0)
2.125 (54.0)
2.625 (67.0)
3.125 (79.0)
3.625 (92.0)
4.125 (105.0)
4.625 (117.0)
D
(Max.)
1.453 (36.9)
1.453 (36.9)
1.453 (36.9)
1.453 (36.9)
1.453 (36.9)
1.453 (36.9)
1.453 (36.9)
1.453 (36.9)
1.453 (36.9)
1.453 (36.9)
1.828 (46.4)
1.828 (46.4)
1.828 (46.4)
1.828 (46.4)
1.828 (46.4)
1.828 (46.4)
1.828 (46.4)
WITH INSULATION SLEEVE
L
(Max.)
1.750 (44.5)
2.000 (50.8)
2.250 (57.2)
2.750 (69.9)
3.250 (82.6)
3.750 (95.3)
4.250 (108.0)
4.750 (120.7)
5.250 (133.4)
5.750 (146.1)
1.750 (44.5)
2.250 (57.2)
2.750 (69.9)
3.250 (82.6)
3.750 (95.3)
4.250 (108.0)
4.750 (120.7)
P TERMINAL
H (Max.)
1.849 (47.0)
1.099 (53.3)
1.349 (59.7)
1.849 (72.4)
1.349 (85.1)
1.849 (97.8)
1.349 (110.5)
1.849 (123.2)
1.349 (125.9)
1.849 (148.6)
1.849 (47.0)
2.349 (59.7)
2.849 (72.4)
3.349 (85.1)
3.849 (97.8)
4.349 (110.5)
4.849 (123.2)
TERMINAL
SPACING
M ± 0.016 (0.4)
0.500 (12.7)
0.500 (12.7)
0.500 (12.7)
0.500 (12.7)
0.500 (12.7)
0.500 (12.7)
0.500 (12.7)
0.500 (12.7)
0.500 (12.7)
0.500 (12.7)
0.750 (19.1)
0.750 (19.1)
0.750 (19.1)
0.750 (19.1)
0.750 (19.1)
0.750 (19.1)
0.750 (19.1)
TYPICAL
WEIGHT
(g)
43.0
54.0
63.0
82.0
105.0
122.0
129.0
162.0
179.0
201.0
71.0
102.0
133.0
167.0
198.0
230.0
252.0
Revision: 20-Jul-16
Document Number: 42066
1
For technical questions, contact:
aluminumcaps4@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
36D, 36DE, 36DX
www.vishay.com
Vishay Sprague
LARGE CAN CAPACITORS
DIMENSIONS
in inches (millimeters)
CASE
CODE
EE
EF
BY
BA
BM
BB
BL
BC
BD
BE
BF
CB
CL
CC
CD
CE
CF
DB
DL
DC
DD
DE
DF
DJ
NOMINAL
D
± 0.032 (0.8)
1.750 (44.0)
1.750 (44.0)
2.000 (51.0)
2.000 (51.0)
2.000 (51.0)
2.000 (51.0)
2.000 (51.0)
2.000 (51.0)
2.000 (51.0)
2.000 (51.0)
2.000 (51.0)
2.500 (64.0)
2.500 (64.0)
2.500 (64.0)
2.500 (64.0)
2.500 (64.0)
2.500 (64.0)
3.000 (76.0)
3.000 (76.0)
3.000 (76.0)
3.000 (76.0)
3.000 (76.0)
3.000 (76.0)
3.000 (76.0)
L
± 0.063 (1.6)
5.125 (130.0)
5.625 (143.0)
1.875 (48.0)
2.125 (54.0)
2.625 (67.0)
3.125 (79.0)
3.625 (92.0)
4.125 (105.0)
4.625 (117.0)
5.125 (130.0)
5.625 (143.0)
3.125 (79.0)
3.625 (92.0)
4.125 (105.0)
4.625 (117.0)
5.125 (130.0)
5.625 (143.0)
3.125 (79.0)
3.625 (92.0)
4.125 (105.0)
4.625 (117.0)
5.125 (130.0)
5.625 (143.0)
8.625 (219.0)
D
(Max.)
1.828 (46.4)
1.828 (46.4)
2.078 (52.8)
2.078 (52.8)
2.078 (52.8)
2.078 (52.8)
2.078 (52.8)
2.078 (52.8)
2.078 (52.8)
2.078 (52.8)
2.078 (52.8)
2.578 (65.5)
2.578 (65.5)
2.578 (65.5)
2.578 (65.5)
2.578 (65.5)
2.578 (65.5)
3.078 (78.2)
3.078 (78.2)
3.078 (78.2)
3.078 (78.2)
3.078 (78.2)
3.078 (78.2)
3.078 (78.2)
WITH INSULATION SLEEVE
L
(Max.)
5.250 (133.4)
5.750 (146.1)
2.000 (50.8)
2.250 (57.2)
2.750 (69.9)
3.250 (82.6)
3.750 (95.3)
4.250 (108.0)
4.750 (120.7)
5.250 (133.4)
5.750 (146.1)
3.250 (82.6)
3.750 (95.3)
4.250 (108.0)
4.750 (120.7)
5.250 (133.4)
5.750 (146.1)
3.250 (82.6)
3.750 (95.3)
4.250 (108.0)
4.750 (120.7)
5.250 (133.4)
5.750 (146.1)
8.750 (222.3)
P TERMINAL
H (Max.)
5.349 (135.9)
5.849 (148.6)
2.099 (53.3)
2.349 (59.7)
2.849 (72.4)
3.349 (85.1)
3.849 (97.8)
4.349 (110.5)
4.849 (123.2)
5.349 (135.9)
5.849 (148.6)
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
TERMINAL
SPACING
M ± 0.016 (0.4)
0.750 (19.1)
0.750 (19.1)
0.875 (22.2)
0.875 (22.2)
0.875 (22.2)
0.875 (22.2)
0.875 (22.2)
0.875 (22.2)
0.875 (22.2)
0.875 (22.2)
0.875 (22.2)
1.125 (28.6)
1.125 (28.6)
1.125 (28.6)
1.125 (28.6)
1.125 (28.6)
1.125 (28.6)
1.250 (31.8)
1.250 (31.8)
1.250 (31.8)
1.250 (31.8)
1.250 (31.8)
1.250 (31.8)
1.250 (31.8)
TYPICAL
WEIGHT
(g)
269.0
318.0
113.0
133.0
176.0
213.0
261.0
381.0
326.0
337.0
408.0
329.0
400.0
473.0
562.0
607.0
675.0
496.0
598.0
700.0
802.0
944.0
1004.0
1403.0
DIMENSIONS
in inches (millimeters)
BRACKETS (RoHS-COMPLIANT)
TYPE
2 Feet
3 Feet
3 Feet
3 Feet
PART NUMBER
1245860035A
1245860036A
1245860037A
1245860038A
A
1.375 (34.9)
2.000 (50.8)
2.500 (63.5)
3.000 (76.2)
B
1.781 (45.2)
2.500 (63.5)
3.000 (76.2)
3.500 (88.9)
HEIGHT
J ± 0.032 (0.81)
0.063 (1.6)
0.250 (6.4)
0.093 (2.4)
C
2.218 (56.3)
2.875 (73.0)
3.375 (85.7)
3.875 (98.4)
DIAMETER
S ± 0.010 (0.25)
0.313 (8.0)
0.313 (8.0)
0.688 (17.5)
DIAMETER
T ± 0.010 (0.25)
0.438 (11.1)
0.438 (11.1)
-
FIGURE NUMBER
1
2
2
2
SCREW INSERT TERMINAL DIMENSIONS
TERMINAL CODE
A
B
D
THREAD
10-32 NF-28
10-32 NF-28
1/4-28 NF-28
THREAD DEPTH
0.219 (5.6)
0.375 (9.5)
0.344 (8.7)
NOTES
All cases codes
All cases codes
C and D dia. codes only
Revision: 20-Jul-16
Document Number: 42066
2
For technical questions, contact:
aluminumcaps4@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
36D, 36DE, 36DX
www.vishay.com
DIMENSIONS AND AVAILABLE FORMS
SCREW INSERT TERMINALS
M
S
T
J
Vishay Sprague
PVC
sleeve
L
Nom.
L
Max.
M
Vent
D
Nom.
D
Max.
Insulation disc
LARGE CAN BRACKETS
B
0.187
[4.8]
A
0.375 [9.5]
30°
0.218
[5.5]
0.312
[7.9]
0.250 [6.3]
2 holes
0.149 [3.8] dia.
0.281
[7.1]
0.562
[14.3]
0.750
[19.1]
0.125
[3.2]
0.125
[3.2]
A
0.406 [10.3]
0.156
[4.0]
B
0.500
[12.7]
0.25 [6.3]
30°
30°
15°
0.406 [10.3]
C
0.176
[4.5]
0.281 [7.1]
0.125
[28.6]
0.750
[19.1]
0.375 [9.5]
0.035
[0.9]
C
2 holes
0.201 [5.1] dia.
0.035 [0.9]
ORDERING EXAMPLE
Electrolytic capacitor 36DX series: 36DX 392 G 075 BB 2 A
DESCRIPTION
CODE
36DX
392
G
075
BB
2
A
Revision: 20-Jul-16
EXPLANATION
Product type
Capacitance value (3900 μF)
Tolerance (G = -10 % / +75 %; F = -10 % / +50 %)
Voltage rating at 85 °C (75 V)
Can size (see dimensions table)
PVC insulating sleeve
Terminal code (low insert 10-32 screw thread)
Document Number: 42066
3
For technical questions, contact:
aluminumcaps4@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
36D, 36DE, 36DX
www.vishay.com
Vishay Sprague
ELECTRICAL DATA AND ORDERING INFORMATION
(original / improved ratings)
CAPACITANCE (μF)
TYPE 36D
15 V
DC
AT +85 °C, SURGE = 18 V
13 000
2700
5500
5500
8400
12 000
1300
2600
3900
5200
6000
9000
15 000
3900
10 000
190
TYPE 36DE
10 V
DC
AT +85 °C, SURGE = 12 V
23 000
40 000
24 000
TYPE 36DX
15 V
DC
AT +85 °C, SURGE = 18 V
7500
15 000
22 000
34 000
50 000
4500
9000
13 000
20 000
30 000
50 000
AA
AB
AC
AF
BC
25 V
DC
AT +85 °C, SURGE = 30 V
AA
AB
AC
AF
BC
CC
36DX452G025AA2A
36DX902G025AB2A
36DX133G025AC2A
36DX203G025AF2A
36DX303G025BC2A
36DX503G025CC2A
36DX752G015AA2A
36DX153G015AB2A
36DX223G015AC2A
36DX343G015AF2a
36DX503G015BC2A
AA
25 V
DC
AT +85 °C, SURGE = 30 V
BB
40 V
DC
AT +85 °C, SURGE = 50 V
BB
36DE243G040BB2A
36DE403G025BB2A
36DE233G010AA2A
AC
25 V
DC
AT +85 °C, SURGE = 30 V
AA
AB
40 V
DC
AT +85 °C, SURGE = 50 V
AC
BB
BC
50 V
DC
AT +85 °C, SURGE = 65 V
AA
AB
AC
AE
BB
BC
CC
75 V
DC
AT +85 °C, SURGE = 95 V
BB
CC
350 V
DC
AT +85 °C, SURGE = 400 V
AB
36D191F350AB2A
36D392G075BB2A
36D103G075CC2A
36D132G050AA2A
36D262G050AB2A
36D392G050AC2A
36D522G050AE2A
36D602G050BB2A
36D902G050BC2A
36D153G050CC2A
36D552G040AC2A
36D842G040BB2A
36D123G040BC2A
36D272G025AA2A
36D552G025AB2A
36D133G015AC2A
CASE CODE
PART NUMBER
Revision: 20-Jul-16
Document Number: 42066
4
For technical questions, contact:
aluminumcaps4@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
36D, 36DE, 36DX
www.vishay.com
Vishay Sprague
CASE CODE
30 V
DC
AT +85 °C, SURGE = 40 V
PART NUMBER
ELECTRICAL DATA AND ORDERING INFORMATION
(original / improved ratings)
CAPACITANCE (μF)
TYPE 36DX
4000
8000
18 000
26 000
2900
5800
8700
20 000
34 000
2400
4800
7200
11 000
16 000
24 000
40 000
41 000
1400
4200
10 000
17 000
1700
850
2000
2800
3400
7400
500
10 000
3100
3300
5100
230
2000
3100
3500
Statements about product lifetime are based on calculations and internal testing. They should only be interpreted as estimations. Also due to external factors, the
lifetime in the field application may deviate from the calculated lifetime. In general, nothing stated herein shall be construed as a guarantee of durability.
AA
AB
AF
BC
40 V
DC
AT +85 °C, SURGE = 50 V
AA
AB
AC
BC
CC
50 V
DC
AT +85 °C, SURGE = 65 V
AA
AB
AC
AF
BC
BF
CF
DC
75 V
DC
AT +85 °C, SURGE = 95 V
AA
AC
BC
CC
100 V
DC
AT +85 °C, SURGE = 125 V
AB
200 V
DC
AT +85 °C, SURGE = 250 V
AC
BC
BC
CC
DF
250 V
DC
AT +85 °C, SURGE = 300 V
AB
DJ
350 V
DC
AT +85 °C, SURGE = 400 V
DF
DF
DJ
450 V
DC
AT +85 °C, SURGE = 525 V
AC
DF
DJ
DJ
36DX402G030AA2A
36DX802G030AB2A
36DX183G030AF2A
36DX263G030BC2A
36DX292G040AA2A
36DX582G040AB2A
36DX872G040AC2A
36DX203G040BC2A
36DX343G040CC2A
36DX242G050AA2A
36DX482G050AB2A
36DX722G050AC2A
36DX113G050AF2A
36DX163G050BC2A
36DX243G050BF2A
36DX403G050CF2A
36DX413G050DC2A
36DX142G075AA2A
36DX422G075AC2A
36DX103G075BC2A
36DX173G075CC2A
36DX172G100AB2A
36DX851F200AC2A
36DX202F200BC2A
36DX282F200BC2A
36DX342F200CC2A
36DX742F200DF2A
36DX501F250AB2A
36DX103F250DJ2A
36DX312F350DF2A
36DX332F350DF2A
36DX512F350DJ2A
36Dx231F450AC2A
36DX202F450DF2A
36DX312F450DJ2A
36DX352F450DJ2A
Revision: 20-Jul-16
Document Number: 42066
5
For technical questions, contact:
aluminumcaps4@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
京公网安备 11010802033920号
EEWORLD
