IFSC-1008AB-01
www.vishay.com
Vishay Dale
Low Profile, High Current Inductors
FEATURES
• Shielded construction
• Frequency range up to 5.0 MHz
• Handles high transient current spikes without
saturation
• Material categorization: for definitions of
compliance please see
www.vishay.com/doc?99912
STANDARD ELECTRICAL SPECIFICATIONS
L
0
INDUCTANCE
± 20 %
AT 100 kHz,
0.25 V, 0 A
(μH)
0.47
1.0
1.5
2.2
3.3
4.7
6.8
10.0
22.0
DCR
25 °C
(m)
TYP.
25
37
63
80
140
190
325
360
910
HEAT
RATING
CURRENT
DC
I
DC
(A)
(3)
MAX.
3.33
2.34
1.98
1.70
1.31
1.08
0.90
0.68
0.45
3.70
2.60
2.20
1.85
1.45
1.20
1.00
0.75
0.50
SATURATION
CURRENT
DC
I
SAT
(A)
(4)
TYP.
3.90
2.70
2.30
2.15
1.70
1.50
1.15
0.85
0.56
MAX.
3.50
2.50
2.07
1.95
1.60
1.40
1.04
0.77
0.50
APPLICATIONS
• PDA/notebook/desktop/server applications
• High current POL converters
• Low profile, high current power supplies
• Battery powered devices
• DC/DC converters in distributed power systems
• DC/DC converter for field programmable gate array
(FPGA)
MAX. TYP.
29
43
72
90
155
212
370
410
1050
DIMENSIONS
in inches [millimeters]
0.098 ± 0.008
[2.5 ± 0.2]
0.079 ± 0.008
[2.0 ± 0.2]
Notes
(1)
All test data is referenced to 25 °C ambient
(2)
Operating temperature range -55 °C to +125 °C
(3)
DC current (A) that will cause an approximate
T
of 40 °C
(4)
DC current (A) that will cause L to drop approximately 30 %
0
(5)
The part temperature (ambient + temp. rise) should not exceed
125 °C under worst case operating conditions. Circuit design,
component placement, PWB trace size and thickness, airflow
and other cooling provisions all affect the part temperature. Part
temperature should be verified in the end application.
0.047 [1.2]
Max.
0.028 ± 0.012 0.028 ± 0.012
[0.7 ± 0.3]
[0.7 ± 0.3]
Typical Pad Layout
0.102 [2.6]
0.083
[2.1]
0.031 [0.8]
DESCRIPTION
IFSC-1008AB-01
MODEL
4.7 μH
INDUCTANCE VALUE
± 20 %
INDUCTANCE TOLERANCE
ER
PACKAGE CODE
e3
JEDEC
®
LEAD (Pb)-FREE STANDARD
GLOBAL PART NUMBER
I
F
S
C
1
0
0
SIZE
8
A
B
E
R
4
R
INDUCTANCE
VALUE
7
M
TOL.
0
1
PRODUCT FAMILY
PACKAGE
CODE
SERIES
Revision: 01-Mar-18
Document Number: 34294
