(2/9)
C A P A C I T O R S
REMINDERS FOR USING THESE PRODUCTS
Before using these products, be sure to request the delivery specifications.
SAFETY REMINDERS
Please pay sufficient attention to the warnings for safe designing when using these products.
REMINDERS
Do not use or store in locations where there are conditions such as gas corrosion (salt, acid, alkali, etc.).
Before soldering, be sure to preheat components.
The preheating temperature should be set so that the temperature difference between the solder temperature and product temperature
does not exceed 150°C.
Soldering corrections after mounting should be within the range of the conditions determined in the specifications.
If overheated, a short circuit, performance deterioration, or lifespan shortening may occur.
Self heating (temperature increase) occurs when the power is turned ON, so the tolerance should be sufficient for the set thermal
design.
Do not use for a purpose outside of the contents regulated in the delivery specifications.
The products listed on this catalog are intended for use in automotive electronic equipment under a normal operation and use
condition.
The products are not designed or warranted to meet the requirements of the applications listed below, whose performance and/or
quality require a more stringent level of safety or reliability, or whose failure, malfunction or trouble could cause serious damage to
society, person or property.
If you intend to use the products in the applications listed below or if you have special requirements exceeding the range or conditions
set forth in the each catalog, please contact us.
(1) Aerospace/Aviation equipment
(2) Transportation equipment (electric trains, ships, etc.)
(3) Medical equipment
(4) Power-generation control equipment
(5) Atomic energy-related equipment
(6) Seabed equipment
(7) Transportation control equipment
(8) Public information-processing equipment
(9) Military equipment
(10) Electric heating apparatus, burning equipment
(11) Disaster prevention/crime prevention equipment
(12) Safety equipment
(13) Other applications that are not considered general-purpose
applications
Please refer to the guideline of notabilia for fixed ceramic capacitors issued by JEITA(Japan Electronics and Information Technology
Association, EIAJ RCR-2335).
When designing your equipment even for automotive-purpose applications, you are kindly requested to take into consideration securing
protection circuit/device or providing backup circuits in your equipment.
20160219 / leaddisc_automotive_cs_en.fm
(3/9)
C A P A C I T O R S
Disc Type Capacitors with Lead
Product compatible with RoHS directive
Halogen-free
High Voltage Ceramic Capacitors, Automotive Grade, Safety Standard Approved
Overview of CS Series
FEATURES
AEC-Q200 compliant.
1,000 cycles guaranteed under heat shock testing at –55°C to +125°C.
It can be used as a Y capacitor for battery chargers used in automobiles (EV, PHEV).
Compliant with IEC and the safety standards of various countries.
Rated at a withstand voltage of AC.2600V.
These products shall conform to RoHS Directive due to lead(Pb) free of lead wire and internal solder material.
Compatible with halogen-free external resin coating.
APPLICATION
For use in Y capacitor for battery chargers or air-conditioners used in automobiles.
PART NUMBER CONSTRUCTION
CS 80
Series
name
Type
45
65
70
75
80
85
95
11
ZU
Temperature
characteristics
SL
B
ZU
(Z5U)
+350 to
–1000ppm/°C
±10%
+22, -56%
2GA
Rated voltage
X1:440V
Y2:300V
222
Nominal
capacitance
100
221
10pF
220pF
M
Capacitance
tolerance
J
K
M
±5%
±10%
±20%
A
Grade
classification
A
For use in
automobiles
□
Lead type
G Long lead
N Short lead
V
Taping
K
Application
classification
K
Safety
standard
A
Internal code
2GA
A Halogen-free
472 4,700pF
Please refer to P-6~8 about the product dimensions.
OPERATING TEMPERATURE RANGE
Capacitance temperature
characteristics
SL
B
Z5U
Temperature range
Operating temperature
（°C）
–25 to +125
–25 to +125
–25 to +125
Storage temperature
（°C）
–25 to +125
–25 to +125
–25 to +125
The maximum operating temperature of 125°C includes capacitor self-generated heat of up to 20°C.
The storage temperature range applies to after MLCC is mounted on board.
RoHS Directive Compliant Product: See the following for more details related to RoHS Directive compliant products. http://product.tdk.com/en/environment/rohs/
Halogen-free: Indicates that Cl content is less than 900ppm, Br content is less than 900ppm, and that the total Cl and Br content is less than 1500ppm.
Please be sure to request delivery specifications that provide further details on the features and specifications of the products for proper and safe use.
Please note that the contents may change without any prior notice due to reasons such as upgrading.
20160219 / leaddisc_automotive_cs_en.fm
