Data Sheet

4.0 Amp

SINGLE PHASE SILICON BRIDGE

Mechanical Dimensions

KBL400 . . . 410 Series

Description

Mechanical Data:

Mounting Position - Any.

Weight - 0.3 Ounce.

Features

n

COMPACT SIZE

n

LOW LEAKAGE CURRENT

n

200 AMP SURGE OVERLOAD RATING

n

MEETS UL SPECIFICATION 94V-0

Electrical Characteristics @ 25

o

C.

Maximum Ratings

Peak Repetitive Reverse Voltage...V

RRM

RMS Reverse Voltage...V

R(rms)

DC Blocking Voltage...V

DC

Average Forward Rectified Current...I

F(av)

T

A

= 25°C

Non-Repetitive Peak Forward Surge Current...I

FSM

8.3 mS Single ½ Sine Wave Imposed on Rated Load

Forward Voltage...V

F

Bridge Element @ 4.0 Amps

DC Reverse Current...I

R

@ Rated DC Blocking Voltage

Typical Thermal Resistance...R

θJC

Operating & Storage Temperature Range...T

J

, T

STRG

T

A

= 25°C

T

A

=100°C

KBL400 . . . 410 Series

KBL400

50

35

50

KBL401

100

70

100

KBL402

200

140

200

KBL404

400

280

400

KBL406

600

420

600

KBL408

800

560

800

KBL410

1000

700

1000

Units

Volts

Amps

Volts

............................................. 4.0 ...............................................

............................................. 2 0 0 ...............................................

............................................. 1.1 ...............................................

............................................. 1 0 ...............................................

µAmps

............................................. 5.0 ............................................... mAmps

............................................. 1 0 ...............................................

......................................... -55 to 150 ..........................................

°C

/ W

°C
