CXA2530-0000-000N00T427F datasheet, PDF

Datasheet> All Categories > LED optoelectronic/LED> CXA2530-0000-000N00T427F

CXA2530-0000-000N00T427F: DescriptionHigh Power LEDs - White White, 3440lm; CategoryLED optoelectronic/LED; File Size2MB，17 Pages; ManufacturerCree; Websitehttp://www.cree.com/; Environmental Compliance

Download Datasheet Parametric View All

CXA2530-0000-000N00T427F Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	CXA2530-0000-000N00T427F	-	-	View	Buy Now

CXA2530-0000-000N00T427F Overview

High Power LEDs - White White, 3440lm

CXA2530-0000-000N00T427F Parametric

Parameter Name	Attribute value
Product Attribute	Attribute Value
Manufacturer	Cree
Product Category	High Power LEDs - White
RoHS	Details
Product	White CoB LEDs
Package / Case	COB - Chip-on-Board
Illumination Color	White (Warm White)
Wavelength/Color Temperature	2700 K
Luminous Intensity	-
Luminous Flux/Radiant Flux	3440 lm
Color Rendering Index - CRI	80
Viewing Angle	115 deg
Lens Color/Style	Tinted, Clear
If - Forward Current	800 mA
Vf - Forward Voltage	37 V
Power Rating	61 W
Mounting Style	SMD/SMT
Length	23.85 mm
Width	23.85 mm
Height	1.7 mm
Maximum Operating Temperature	+ 85 C
Minimum Operating Temperature	- 40 C
Packaging	Tube
Features	-
Type	High Power LEDs
LED Size	23.85 mm x 23.85 mm x 1.7 mm
Lens Shape	Round Flat
Lens Dimensions	19 mm
Factory Pack Quantity	100
Vr - Reverse Voltage	-

Preview

Download Datasheet

View All

CLD-DS54 Rev 9A

Product family data sheet

Cree

XLamp

CXA2530 LED

ProDuCt DEsCriPtion

The XLamp

CXA2530 LeD array expands

Cree’s family of high‑flux, multi‑die

arrays, offering high performance in an

easy‑to‑use platform. With XLamp LED

lighting‑class reliability, the CXA2530’s

uniform emitting surface enables both

directional and non‑directional lighting

applications and luminaire designs.

Available in 2‑step and 4‑step color

consistency, and featuring a 19‑mm

optical source, the CXA2530 brings new

levels of flux and efficacy to this form

factor.

The

CX Family LED Design Guide

provides basic information on the

requirements to use the CXA2530 LED

successfully in luminaire designs.

fEAturEs

•

Available in 4‑step, 3‑step and 2‑step

EasyWhite

bins at 2700 K, 3000 K,

3500 K, 4000 K & 5000 K CCT and

4‑step EasyWhite bins at 5700 K &

6500 K CCT

•

Available in ANSI white bins at

4000 K, 5000 K, 5700 K & 6500 K

CCT

•

Available in 70‑, 80‑, 90‑ and

93‑minimum CRI options

Forward voltage option: 36‑V class

85 °C binning and characterization

Maximum drive current: 1600 mA

115° viewing angle, uniform

chromaticity profile

Top‑side solder connections

Thermocouple attach point

NEMA SSL‑3 2011 standard flux bins

RoHS and REACh compliant

recognized component

(E349212)

tAbLE of ContEnts

Characteristics ............................................2

Operating Limits ..........................................2

Flux Characteristics, EasyWhite

Order

Codes and Bins

...........................................3

Flux Characteristics, ANSI White Order

Codes and Bins

...........................................6

Relative Spectral Power Distribution .........7

Electrical Characteristics ............................7

Relative Luminous Flux vs. Current............8

Typical Spatial Distribution.........................9

Performance Groups ‑ Brightness .............9

Performance Groups ‑ Chromaticity ....... 10

Cree EasyWhite

Bins Plotted on the

1931 CIE Color Space .............................. 13

Cree ANSI White Bins Plotted on the

1931 CIE Color Space .............................. 13

Bin and Order Code Formats ................... 14

Mechanical Dimensions .......................... 14

Thermal Design

........................................ 15

Notes ........................................................ 16

Packaging ................................................. 17

WWW.CREE.Com/XLAmp

, XLamp

and

EasyWhite

are registered trademarks and the Cree logo is a trademark of Cree, Inc. UL

and the UR logo are registered trademarks of UL LLC.

Cree, Inc.

4600 Silicon Drive

Durham, NC 27703

USA Tel: +1.919.313.5300
