IntroDuCtIon
This document describes the product nomenclature required
to select and order Cree’s XLamp
®
XM family of LeDs. XLamp
XM family LeDs are tested and sorted into bins which are then
combined into orderable kits identified by an order code.
All XLamp LeDs are tested and sorted by color and brightness
into a unique bin. each bin contains LeDs from only one color and
brightness group and is uniquely identified by a bin code. White
XLamp LeDs are sorted by chromaticity (color) and luminous
flux (brightness). LEDs are shipped on reels containing LEDs
from one bin and are always labeled with the appropriate bin
code.
Kits contain LeDs from a number of similar bins and are fully
defined by their order codes. A full explanation of the order
codes for XLamp XM family LeDs, as well as a list of standard
order codes, is provided in this document.
www.Cree.Com/XLAmp
Copyright © 2010-2018 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
and XLamp
®
are
registered trademarks and the Cree logo is a trademark of Cree, Inc. This document is provided for informational purposes only and is not a warranty
or a specification. For product specifications, please see the data sheets available at www.cree.com. For warranty information, please contact Cree
Sales at sales@cree.com.
Cree, Inc.
4600 Silicon Drive
Durham, NC 27703
USA Tel: +1.919.313.5300
XLamp
®
Xm FamiLy LED Binning & LaBELing
bIn anD orDEr CoDE ForMats
Bin codes and order codes for XM family LEDs are configured in the following manner:
order Code
Series
XMLA = XM-L
XMLB = XM-L Gen 2
Internal code
Luminous flux group
SSSSCC-BD-HHHH-NNNGFFWWW
Chromaticity group
Color specification
L = White
0 = Cool White
B = 70 CRI minimum
H = 80 CRI minimum
P = 85 CRI minimum
U = 90 CRI minimum
Internal code
Color
WT = White
bin Code
Series
XMLA = XM-L
XMLB = XM-L Gen 2
Internal code
Luminous flux group
Color specification
L = White
0 = Cool White
B = 70 CRI minimum
H = 80 CRI minimum
P = 85 CRI minimum
U = 90 CRI minimum
SSSSCC-B-WWW-FFF-GG-AAAA
Internal code
Chromaticity group
Color
WT = White
PErForManCE GrouPs – LuMInous FLuX
XLamp XM family LEDs are tested for luminous flux and placed into one of the following luminous-flux groups:
Group Code
S2
S3
S4
S5
S6
T2
T3
T4
T5
T6
U2
U3
U4
Min. Luminous Flux
@ 700 ma (lm)
148
156
164
172
182
200
220
240
260
280
300
320
340
Max. Luminous Flux
@ 700 ma (lm)
156
164
172
182
200
220
240
260
280
300
320
340
360
