CLD-DS20 Rev 15D
Product family data sheet
Cree
®
XLamp
®
XP-G LEDs
ProDuCt DEsCriPtion
The
XLamp
®
XP-G
LeD
delivers
unprecedented levels of light output
and efficacy for a single die LED. The
XLamp XP-G LeD continues Cree’s
history of innovation in LEDs for lighting
applications with wide viewing angle,
symmetrical package, unlimited floor life
and electrically neutral thermal path.
FEAturEs
•
•
•
•
•
•
•
Available in white, outdoor white and
80-CRI, 85-CRI and 90-CRI white
ANSI-compatible chromaticity bins
Maximum drive current: 1500 mA
Low thermal resistance: 4 °C/W
Wide viewing angle: 125°
Unlimited floor life at
≤ 30 ºC/85% RH
Reflow solderable - JEDEC J-STD-020C
Electrically neutral thermal path
RoHS and REACh compliant
UL
®
recognized component (E349212)
•
•
•
tAbLE oF ContEnts
Characteristics
............................................2
Flux Characteristics
....................................3
Relative Spectral Power Distribution
.........7
Relative Flux vs. Junction Temperature.....7
electrical Characteristics
............................8
Relative Flux vs. Current .............................8
Relative Chromaticity vs Current and
Temperature
................................................9
Typical Spatial Distribution......................
10
Thermal Design
........................................
10
Performance Groups – Luminous Flux... 11
Performance Groups – Chromaticity......
12
Cree’s Standard Chromaticity Regions
Plotted on the 1931 CIE Curve ................
15
Cree’s Standard Cool White Kits Plotted
on ANSI Standard Chromaticity
Regions
.....................................................
17
Cree’s Standard Warm and Neutral
White Kits Plotted on ANSI Standard
Chromaticity Regions ..............................
18
Cree’s Standard Chromaticity Kits ..........
20
Bin and Order Code Formats
...................
21
XLamp XP-G LeDs are the ideal choice
for lighting applications where high
light output and maximum efficacy are
required, such as LeD light bulbs, outdoor
lighting, portable lighting, indoor lighting
and solar-powered lighting.
www.CRee.Com/XLAmp
Reflow Soldering Characteristics ............
22
Notes
........................................................ 23
Mechanical Dimensions
..........................
25
Tape and Reel
...........................................
26
Packaging .................................................
27
Copyright © 2009-2017 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
and XLamp
®
are
registered trademarks and the Cree logo is a trademark of Cree, Inc. UL
®
and the UR logo are registered trademarks of UL LLC.
Cree, Inc.
4600 Silicon Drive
Durham, NC 27703
USA Tel: +1.919.313.5300
XLamp
®
Xp-G LED
ChArACtEristiCs
Characteristics
Thermal resistance, junction to solder point
Viewing angle (FWHM)
Temperature coefficient of voltage
ESD withstand voltage (HBM per Mil-Std-883D)
DC forward current
Reverse voltage
Forward voltage (@ 350 mA, 25 °C)
Forward voltage (@ 700 mA, 25 °C)
Forward voltage (@ 1000 mA, 25 °C)
Forward voltage (@ 1500 mA, 25 °C)
LeD junction temperature
unit
°C/W
degrees
mV/°C
v
mA
v
v
v
v
v
°C
2.9
3.05
3.15
3.25
150
Minimum
typical
4
125
-2.1
8000
1500
5
3.25
Maximum
Copyright © 2009-2017 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
and XLamp
®
are registered trademarks and the Cree logo is a trademark of
Cree, Inc. UL
®
and the UR logo are registered trademarks of UL LLC.
2
XLamp
®
Xp-G LED
FLuX ChArACtEristiCs (t
J
= 25 °C)
The following table provides order codes for XLamp XP-G LEDs. For a complete description of the order code nomenclature, please see
the Bin and Order Code Formats section (page 21). For definitions of the chromaticity kits, please see the Cree’s Standard Chromaticity
Kits section (page 20).
Minimum Luminous
Flux (lm) @ 350 mA
Code
R5
51
6200 K
R4
R3
R5
53
6000 K
R4
R3
R5
50
6200 K
R4
R3
R5
e1
6500 K
R4
R3
R5
e2
5700 K
R4
R3
Flux (lm)
139
130
122
139
130
122
139
130
122
139
130
122
139
130
122
Chromaticity
Kit
CCt
order Codes
70 CRI Typical
XPGWHT-L1-0000-00H51
XPGWHT-L1-0000-00G51
XPGWHT-L1-0000-00F51
XPGWHT-L1-0000-00H53
XPGWHT-L1-0000-00G53
XPGWHT-L1-0000-00F53
XPGWHT-L1-0000-00H50
XPGWHT-L1-0000-00G50
XPGWHT-L1-0000-00F50
XPGWHT-L1-0000-00HE1
XPGWHT-L1-0000-00GE1
XPGWHT-L1-0000-00FE1
XPGWHT-L1-0000-00HE2
XPGWHT-L1-0000-00GE2
XPGWHT-L1-0000-00FE2
Notes
•
Cree maintains a tolerance of ±7% on flux and power measurements, ±0.005 on chromaticity (CCx, CCy) measurements and a
tolerance of ±2 on CRI measurements. See the Measurements section (page 23).
•
Cree XLamp XP-G LED order codes specify only a minimum flux bin and not a maximum. Cree may ship reels in flux bins higher than
the minimum specified by the order code without advance notice. Shipments will always adhere to the chromaticity bin restrictions
specified by the order code.
Copyright © 2009-2017 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
and XLamp
®
are registered trademarks and the Cree logo is a trademark of
Cree, Inc. UL
®
and the UR logo are registered trademarks of UL LLC.
3
XLamp
®
Xp-G LED
FLuX ChArACtEristiCs - ContinuED
Chromaticity
Kit
CCt
Minimum Luminous
Flux (lm) @ 350 mA
Code
R5
R4
E3
5000 K
R3
R2
Q5
R5
R4
F4
4750 K
R3
R2
Q5
R5
R4
e4
4500 K
R3
R2
Q5
R4
F5
4250 K
R3
R2
Q5
R4
e5
4000 K
R3
R2
Q5
Z5
4000 K
R2
Q5
Flux (lm)
139
130
122
114
107
139
130
122
114
107
139
130
122
114
107
130
122
114
107
130
122
114
107
114
107
XPGWHT-01-0000-00GE5
XPGWHT-01-0000-00FE5
XPGWHT-01-0000-00EE5
XPGWHT-L1-0000-00FE5
XPGWHT-L1-0000-00EE5
XPGWHT-L1-0000-00DE5
XPGWHT-L1-0000-00EZ5
XPGWHT-L1-0000-00DZ5
XPGWHT-H1-0000-00EE5
XPGWHT-H1-0000-00DE5
XPGWHT-H1-0000-00EZ5
XPGWHT-H1-0000-00DZ5
XPGWHT-01-0000-00GF5
XPGWHT-01-0000-00FF5
XPGWHT-01-0000-00EF5
XPGWHT-L1-0000-00FF5
XPGWHT-L1-0000-00EF5
XPGWHT-L1-0000-00DF5
XPGWHT-01-0000-00HE4
XPGWHT-01-0000-00GE4
XPGWHT-01-0000-00FE4
XPGWHT-01-0000-00EE4
XPGWHT-L1-0000-00FE4
XPGWHT-L1-0000-00EE4
XPGWHT-L1-0000-00DE4
XPGWHT-01-0000-00HF4
XPGWHT-01-0000-00GF4
XPGWHT-01-0000-00FF4
XPGWHT-01-0000-00EF4
XPGWHT-L1-0000-00FF4
XPGWHT-L1-0000-00EF4
XPGWHT-L1-0000-00DF4
70 CRI Typical
XPGWHT-01-0000-00HE3
XPGWHT-01-0000-00GE3
XPGWHT-01-0000-00FE3
XPGWHT-01-0000-00EE3
XPGWHT-L1-0000-00FE3
XPGWHT-L1-0000-00EE3
XPGWHT-L1-0000-00DE3
order Codes
75 Cri typical
80 CRI Minimum
Notes
•
Cree maintains a tolerance of ±7% on flux and power measurements, ±0.005 on chromaticity (CCx, CCy) measurements and a
tolerance of ±2 on CRI measurements. See the Measurements section (page 23).
•
Cree XLamp XP-G LED order codes specify only a minimum flux bin and not a maximum. Cree may ship reels in flux bins higher than
the minimum specified by the order code without advance notice. Shipments will always adhere to the chromaticity bin restrictions
specified by the order code.
Copyright © 2009-2017 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
and XLamp
®
are registered trademarks and the Cree logo is a trademark of
Cree, Inc. UL
®
and the UR logo are registered trademarks of UL LLC.
4
XLamp
®
Xp-G LED
FLuX ChArACtEristiCs - ContinuED
Chromaticity
Minimum
Luminous
Flux (lm) @
350 mA
Code
R3
F6
3750 K
R2
Q5
Q4
R3
e6
3500 K
R2
Q5
Q4
Z6
3500 K
Q5
Q4
R2
F7
3250 K
Q5
Q4
Q3
R2
Q5
Q4
e7
3000 K
Q3
Q2
P4
P3
Q5
Q4
Z7
3000 K
Q3
Q2
P4
P3
Flux
(lm)
122
114
107
100
122
114
107
100
107
100
114
107
100
93.9
114
107
100
93.9
87.4
80.6
73.9
107
100
93.9
87.4
80.6
73.9
XPGWHT-L1-0000-00DZ7
XPGWHT-L1-0000-00CZ7
XPGWHT-L1-0000-00BZ7
XPGWHT-H1-0000-00DZ7
XPGWHT-H1-0000-00CZ7
XPGWHT-H1-0000-00BZ7
XPGWHT-P1-0000-00AZ7
XPGWHT-P1-0000-009Z7
XPGWHT-P1-0000-008Z7
XPGWHT-U1-0000-009Z7
XPGWHT-U1-0000-008Z7
XPGWHT-01-0000-00FE6
XPGWHT-01-0000-00EE6
XPGWHT-01-0000-00DE6
XPGWHT-L1-0000-00EE6
XPGWHT-L1-0000-00DE6
XPGWHT-L1-0000-00CE6
XPGWHT-L1-0000-00DZ6
XPGWHT-L1-0000-00CZ6
XPGWHT-L1-0000-00EF7
XPGWHT-L1-0000-00DF7
XPGWHT-L1-0000-00CF7
XPGWHT-L1-0000-00BF7
XPGWHT-L1-0000-00EE7
XPGWHT-L1-0000-00DE7
XPGWHT-L1-0000-00CE7
XPGWHT-L1-0000-00BE7
XPGWHT-H1-0000-00DE7
XPGWHT-H1-0000-00CE7
XPGWHT-H1-0000-00BE7
XPGWHT-P1-0000-00BE7
XPGWHT-P1-0000-00AE7
XPGWHT-P1-0000-009E7
XPGWHT-P1-0000-008E7
XPGWHT-U1-0000-009E7
XPGWHT-U1-0000-008E7
XPGWHT-H1-0000-00DF7
XPGWHT-H1-0000-00CF7
XPGWHT-H1-0000-00BF7
XPGWHT-H1-0000-00DE6
XPGWHT-H1-0000-00CE6
XPGWHT-H1-0000-00DZ6
XPGWHT-H1-0000-00CZ6
70 CRI Typical
XPGWHT-01-0000-00FF6
XPGWHT-01-0000-00EF6
XPGWHT-01-0000-00DF6
XPGWHT-L1-0000-00EF6
XPGWHT-L1-0000-00DF6
XPGWHT-L1-0000-00CF6
XPGWHT-H1-0000-00EF6
XPGWHT-H1-0000-00DF6
XPGWHT-H1-0000-00CF6
80 CRI Typical
order Codes
Kit
CCt
80 CRI Minimum
85 Cri Minimum
90 CRI Minimum
Notes
•
Cree maintains a tolerance of ±7% on flux and power measurements, ±0.005 on chromaticity (CCx, CCy) measurements and a
tolerance of ±2 on CRI measurements. See the Measurements section (page 23).
•
Cree XLamp XP-G LED order codes specify only a minimum flux bin and not a maximum. Cree may ship reels in flux bins higher than
the minimum specified by the order code without advance notice. Shipments will always adhere to the chromaticity bin restrictions
specified by the order code.
Copyright © 2009-2017 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
and XLamp
®
are registered trademarks and the Cree logo is a trademark of
Cree, Inc. UL
®
and the UR logo are registered trademarks of UL LLC.
5
