MTGBEZ-01-0000-0X0HJ040H datasheet, PDF

Datasheet> All Categories > LED optoelectronic/LED> MTGBEZ-01-0000-0X0HJ040H

MTGBEZ-01-0000-0X0HJ040H: DescriptionHigh Power LEDs - White White, 600lm; CategoryLED optoelectronic/LED; File Size1MB，19 Pages; ManufacturerCree; Websitehttp://www.cree.com/; Environmental Compliance

Download Datasheet Parametric View All

MTGBEZ-01-0000-0X0HJ040H Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	MTGBEZ-01-0000-0X0HJ040H	-	-	View	Buy Now

MTGBEZ-01-0000-0X0HJ040H Overview

High Power LEDs - White White, 600lm

MTGBEZ-01-0000-0X0HJ040H Parametric

Parameter Name	Attribute value
Product Attribute	Attribute Value
Manufacturer	Cree
Product Category	High Power LEDs - White
RoHS	Details
Product	White LEDs
Package / Case	SMD-2
Illumination Color	White (Neutral White)
Wavelength/Color Temperature	4000 K
Luminous Intensity	-
Luminous Flux/Radiant Flux	600 lm
Color Rendering Index - CRI	70
Viewing Angle	115 deg
Lens Color/Style	Clear
If - Forward Current	30 mA
Vf - Forward Voltage	225 V
Power Rating	18.5 W
Mounting Style	SMD/SMT
Length	8.9 mm
Width	8.9 mm
Height	4.85 mm
Maximum Operating Temperature	-
Minimum Operating Temperature	-
Packaging	Cut Tape
Packaging	MouseReel
Packaging	Reel
Features	-
Type	XLamp MT-G2 EasyWhite LEDs
LED Size	8.9 mm x 8.9 mm x 4.85 mm
Lens Shape	Dome
Lens Dimensions	8.4 mm
Factory Pack Quantity	100
Vr - Reverse Voltage	5 V

Preview

Download Datasheet

View All

CLD-DS49 Rev 3I

Product family data sheet

Cree

XLamp

MT-G2 EasyWhite

LEDs

ProDuCT DEsCriPTion

The XLamp

MT-G2 easyWhite

LeD

builds on the breakthrough performance

of the original MT-G by increasing lumen

output up to 25%, while providing a small,

uniform, single point source for precise

optical control. The MT-G2 shares the

same

mechanical

footprint

the

original MT-G, providing customers with

a seamless upgrade path and shortening

the LED luminaire and retrofit lamp

design cycle.

MT-G2 LeDs are designed for high-

output, directional lighting applications

and are the ideal replacement for

lighting

applications

that

currently

FEATurEs

•

Cree easyWhite color temperatures

from 2700 K to 5000 K CCT

85 °C binning and characterization

Three voltage options: 6 V, 9 V, 36 V

80 and 90 minimum CRI options

Low effective thermal resistance:

1.5 °C/W

High lumen density

Small, uniform emitting area for

excellent optical control

electrically neutral thermal path

RoHS and ReACh compliant

recognized component

(e349212)

TAbLE oF ConTEnTs

Characteristics ...........................................2

Flux Characteristics, Standard Order

Codes, Bins, 6-volt MT-G2 .........................3

Flux Characteristics, Standard Order

Codes, Bins, 9-volt MT-G2 .........................4

Flux Characteristics, Standard Order

Codes, Bins, 36-volt MT-G2 .......................5

Relative Spectral Power Distribution ........6

Relative Luminous Flux vs. Junction

Temperature ...............................................6

electrical Characteristics ...........................7

Relative Luminous Flux vs. Current...........8

Typical Spatial Distribution......................10

Performance Groups – Brightness .........10

Performance Groups – Chromaticity......11

Cree easyWhite

Color Temperatures

Plotted on the 1931 CIe Curve ................12

Bin and Order Code Formats ...................13

Reflow Soldering Characteristics

............14

Notes ........................................................15

Mechanical Dimensions ..........................17

Tape and Reel ...........................................18

Packaging .................................................19

APPLiCATions

•

MR, PAR, BR, AR and other directional

retrofit lamps

Commercial/residential directional

lighting

General illumination

use inefficient halogen lamps. MT-G2

LeDs are optimized for use in track,

accent, lamp retrofit, downlighting and

other applications where color quality,

consistency and optical control are

required.

WWW.CREE.Com/XLAmp

, XLamp

and

EasyWhite

are registered trademarks and the Cree logo is a trademark of Cree, Inc. UL

and the UR logo are registered trademarks of UL LLC.

Cree, Inc.

4600 Silicon Drive

Durham, NC 27703

USA Tel: +1.919.313.5300
