Z86L98ZEM
Z8
®
In-Circuit Emulator
Product Specification
PS002603-0108
Copyright ©2008 by Zilog
®
, Inc. All rights reserved.
www.zilog.com
Warning:
DO NOT USE IN LIFE SUPPORT
LIFE SUPPORT POLICY
ZILOG'S PRODUCTS ARE NOT AUTHORIZED FOR USE AS CRITICAL COMPONENTS IN LIFE
SUPPORT DEVICES OR SYSTEMS WITHOUT THE EXPRESS PRIOR WRITTEN APPROVAL OF
THE PRESIDENT AND GENERAL COUNSEL OF ZILOG CORPORATION.
As used herein
Life support devices or systems are devices which (a) are intended for surgical implant into the body, or (b)
support or sustain life and whose failure to perform when properly used in accordance with instructions for
use provided in the labeling can be reasonably expected to result in a significant injury to the user. A
critical component is any component in a life support device or system whose failure to perform can be
reasonably expected to cause the failure of the life support device or system or to affect its safety or
effectiveness.
Document Disclaimer
©2008 by Zilog, Inc. All rights reserved. Information in this publication concerning the devices,
applications, or technology described is intended to suggest possible uses and may be superseded. ZILOG,
INC. DOES NOT ASSUME LIABILITY FOR OR PROVIDE A REPRESENTATION OF ACCURACY
OF THE INFORMATION, DEVICES, OR TECHNOLOGY DESCRIBED IN THIS DOCUMENT.
Z I L O G A L S O D O E S N O T A S S U M E L I A B I L I T Y F O R I N T E L L E C T U A L P R O P E RT Y
INFRINGEMENT RELATED IN ANY MANNER TO USE OF INFORMATION, DEVICES, OR
TECHNOLOGY DESCRIBED HEREIN OR OTHERWISE. The information contained within this
document has been verified according to the general principles of electrical and mechanical engineering.
Z8, Z8 Encore!, Z8 Encore! XP, Z8 Encore! MC, Crimzon, eZ80, and ZNEO are trademarks or registered
trademarks of Zilog, Inc. All other product or service names are the property of their respective owners.
PS002603-0108
Z86L98ZEM
Product Specification
iii
Revision History
Each instance in the revision history table reflects a change to this document from its pre-
vious revision. For more details, refer to the corresponding pages and appropriate links in
the table below.
Date
January 2008
Revision Level
03
Description
Removed 44L QFP.
Section
Emulator Kit Contents on page 4
PS002603-0108
Revision History
Z86L98ZEM
Product Specification
iv
Table of Contents
Revision History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iii
1.1 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.2 General Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1.2.1 Notes/Limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1.3 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.4 Emulator Kit Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.4.1 Additional Items Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.4.2 Optional Recommended Items . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.4.3 Minimum Requirements of Host Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.5 Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.5.1 ZDS IDE Limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.5.2 All Z8 Emulators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Customer Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
PS002603-0108
Z86L98ZEM
Product Specification
1
Z86L98ZEM Z8
In-Circuit Emulator
1.1
Features
Emulation
Z86L81/2/5/6/8
Z86L98
Z86L81/2/5/6/8
Z86L98
OTP
Z86D86*
Z86D86*
Required Accessories
28 PDIP emulation pod
28 PDIP OTP Adapter (PC ASSY#99C0667-001)
28 PDIP emulation pod and a DIP to SOIC conversion
adapter (AS-DIP 6-028-S003-1 or
AS-DIP-6-028-S003-2) from Emulation Technology
(not included with kit)
28 SOIC OTP Adapter (PC ASSY#99C0668-001)
40 PDIP emulation pod
40 PDIP OTP Adapter (PC ASSY#99C0669-001)
44 PLCC emulation pod
44 PLC OTP adapter (PC ASSY#99C0670-001)
Z86D9300ZDV 68 PLCC OTP Adapter
(PC ASSY# 99C0672-001) (not included with kit)
Package
28 PDIP
28 SOIC
40 PDIP
44 PLCC
68 PLCC
Z86L87/L89/L73
Z86L87/L89/L73
In-Circuit Emulator
Z86D73
Z86D73
Z86D93
Note: *Current OTP support is limited to 32 KByte
•
•
•
•
•
•
•
•
•
Supports up to 64 K of ROM
Varies the operating voltage from 3.0–4.0 V
Supports in-circuit emulation on target systems that operate at 3.0–4.0 V
Powers the In-Circuit Emulator (ICE) chip from either the emulator or target board
Supports IR devices that operate at up to 8 MHz
Emulates 28-pin DIP, 40-pin DIP, and 44 PLCC
Provides OTP programming for 28-pin DIP and SOIC packages, 40 PDIP, 44 PLCC
Emulates and supports all the features and functions for a specified Z8
IR micro-
controller
Multitasks to use other Windows
®
applications while Zilog Developer Studio (ZDS)
is running
PS002603-0108
