2-Port VGA with Audio over Cat5/Cat6 Extender
Splitter, Box-Style Transmitter with EDID,
1920x1440 at 60Hz, Up to 1000-ft., TAA
MODEL NUMBER:
B132-002A-2
Highlights
q
Splits a single VGA Video and
Audio signal into 2
q
EDID copy feature ensures
optimal display compatibility
q
Extends a 1920 x 1440 (60Hz)
Video and Audio signal up to
500 ft., or a 1024 x 768 (60Hz)
Video and Audio signal up to
1,000 ft., when using 24Awg,
Solid Wire Cat5e/6 cable, such
as Tripp Lite's N022-01K-GY
(Cat5) and N222-01K-GY (Cat6)
q
For optimal image quality
between 500 and 1,000 ft., use
Zero-Skew cable, such as Tripp
Lite P524-01K
Description
Tripp Lite's B132-002A-2 allows you to split a single VGA Video and Audio signal into 2. Along with a
B132-100A or B132-100A-WP-1 remote receiver unit, you can extend a 1920 x 1440 (60Hz) Video and
Audio signal up to 500 ft., or a 1024 x 768 (60Hz) Video and Audio signal up to 1,000 ft., when using
24Awg, Solid Wire Cat5e/6 cable, such as Tripp Lite's N022-01K-GY (Cat5) and N222-01K-GY (Cat6).
q
Can further expand the range
and number of
monitors/speakers by adding
B132-110A repeaters
q
Compliant with the Federal
Trade Agreements Act (TAA) for
GSA Schedule purchases
The range and number of monitors/speakers can be further expanded by adding B132-110A repeater
units. Connect up to 4 remote units in a repeater chain (3 repeaters and 1 receiver), with a set of monitor
and speakers at each location. A 1920 x 1440 (60Hz) Video and Audio signal can be extended up to 500
ft. from the first repeater in the chain to the last receiver. A 1024 x 768 (60Hz) Video and Audio signal can
q
System Requirements
For international use, a power
supply with the appropriate plug
be extended up to 1,000 ft. from the first repeater in the chain to the last receiver.
For optimal video image quality between 500 and 1,000 ft., use Zero-Skew cable, such as Tripp Lite
P524-01K. The transmitter unit features functionality that allows for the EDID information from a
connected display to be copied and sent to the connected computer, providing optimal compatibility.
Includes mounting hardware that allows unit to be wall mounted, rack mounted or pole mounted. Ideal for
digital signage situations, such as retail, schools, churches, etc. Compliant with the Federal Trade
Agreements Act (TAA) for GSA Schedule purchases.
q
type must be purchased
separately.
Package Includes
q
2 Port Extender/Splitter local
(Transmitter) unit
Mounting hardware
External Power Supply with
NEMA 1-15P Plug (Input: 100-
Features
q
q
Splits a single VGA Video and Audio signal into 2
A B132-100A or B132-100A-WP-1 remote receiver unit is required for each connected monitor
240V, 50/60Hz, 0.5A; Output:
Extends a 1920 x 1440 (60Hz) Video and Audio signal up to 500 ft., or a 1024 x 768 (60Hz) Video and
5V, 2A, 5 ft.)
Audio signal up to 1,000 ft., when using 24Awg, Solid Wire Cat5e/6 cable, such as Tripp Lite's N022-
q
q
1/3
01K-GY (Cat5) and N222-01K-GY (Cat6)
q
q
Owner's Manual
Support for video resolutions up to 1920 x 1440 (60Hz)
EDID copy feature ensures optimal display compatibility
Can further expand the range and number of monitors/speakers by adding B132-110A repeaters
Connect up to 4 remote units in a repeater chain (3 repeaters and 1 receiver), with a set of monitor and
speakers at each location
q
q
q
q
A 1920 x 1440 (60Hz) Video and Audio signal can be extended up to 500 ft. from the first repeater in the
chain to the last receiver. A 1024 x 768 (60Hz) Video and Audio signal can be extended up to 1,000 ft.
from the first repeater in the chain to the last receiver.
q
For optimal image quality between 500 and 1,000 ft., use Zero-Skew cable, such as Tripp Lite P524-
01K
q
Includes mounting hardware that allows unit to be wall mounted, rack mounted or pole mounted.
Ideal for digital signage situations, such as retail, schools, churches, etc.
Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases
q
q
Specifications
OVERVIEW
UPC Code
AC Adapter
037332178411
Input: 100-240V, 50/60Hz, 0.5A; Output: 5V, 2A, 5 ft.
PHYSICAL
Shipping Dimensions (hwd / in.)
Shipping Dimensions (hwd / cm)
Shipping Weight (lbs.)
Shipping Weight (kg)
Unit Dimensions (hwd / in.)
Unit Dimensions (hwd / cm)
Unit Weight (lbs.)
Unit Weight (kg)
Color
2.20 x 7.20 x 6.50
5.59 x 18.29 x 16.51
1.10
0.50
1 x 2.5 x 3.7
2.54 x 6.35 x 9.40
0.45
0.20
Black
COMMUNICATIONS
Max 1024 x 768 Range (ft)
Max 480P Range (ft)
Max 1440 x 900 Range (ft)
Max 1080i Range (ft)
1000
1000
500
500
2/3
