C8051T321DB28

Description
Daughter Cards & OEM Boards C8051T321 QFN28 SKT Eval Board Kit
CategoryDevelopment board/suite/development tools
File Size102KB,3 Pages
ManufacturerSilicon Laboratories
Environmental Compliance
Download Datasheet Parametric View All

C8051T321DB28 Online Shopping

Suppliers Part Number Price MOQ In stock
C8051T321DB28 - - View Buy Now

C8051T321DB28 Overview

Daughter Cards & OEM Boards C8051T321 QFN28 SKT Eval Board Kit

C8051T321DB28 Parametric

Parameter NameAttribute value
Product AttributeAttribute Value
ManufacturerSilicon Laboratories
Product CategoryDaughter Cards & OEM Boards
RoHSDetails
ProductDaughter Cards
For Use WithC8051T620DK, C8051T622DK
Description/FunctionSocket daughter card for C8051T320 QFN28
Factory Pack Quantity1
Tool Is For Evaluation OfC8051T321
Unit Weight0.001764 oz
July 31, 2012
C8051T620/1, C8051T320/1/2/3 Revision D, and
C8051T626/7 Revision B Errata
Errata Status Summary
Errata
#
Title
Impact
Status
Affected
Fixed
Revisions
Revision
Applicable
Part
Numbers
C8051T620
C8051T621
C8051T320
C8051T321
C8051T322
C8051T323
C8051T620
C8051T621
C8051T320
C8051T321
C8051T322
C8051T323
C8051T626
C8051T627
1
USB D+/D- Driver Impedance
Minor
Revision D
Not Fixed
2
GPIO Signals Driven Low After
Power Cycling
Major
Revision A - D
Not Fixed
3
Clock frequency prior to entering
Suspend Mode
Minor
Revision B
Not Fixed
Impact Definition: Each erratum is marked with an impact, as defined below:
Minor—Workaround exists.
Major—Errata that do not conform to the data sheet or standard.
Information—The device behavior is not ideal but acceptable. Typically, the data sheet will be
changed to match the device behavior.
Errata Details
1.
Description:
The output impedance of the drivers on the USB D+ and D- data lines is nominally 28
but, in some cases, may be as low as 26
.
The minimum USB specification for full-speed devices on
the D+ and D- data lines is 28
.
Impact:
This may impact systems that need to be submitted for USB compliance testing. The
specification for USB compliance is a system-level parameter, not a chip-level parameter. In most
systems, the lower impedance of the device will not be a factor. A typical PCB will add 2-3
to the
effective driver impedance and bring the system level impedance within specifications.
Workaround:
For systems that require USB certification, it is recommended to add some series
impedance (between 5 and 8 Ohms, ¼ watt or higher) to D+ and D- in the PCB design.
2.
Description:
The GPIO signals will be driven low for approximately 40 microseconds after power cycling
the device and then return to the configured reset state.
400 West Cesar Chavez, Austin, TX 78701 (512) 416-8500 FAX (512) 416-9669 www.silabs.com
C8051T620-1_T320-1-2-3ERD_T626-7ERB073112
