BB5500HCV datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Module/solution> BB5500HCV

BB5500HCV: DescriptionSingle Board Computers Intel Server Board S5500HCV; CategoryModule/solution; File Size4MB，191 Pages; ManufacturerIntel; Websitehttp://www.intel.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

BB5500HCV Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	BB5500HCV	-	-	View	Buy Now

BB5500HCV Overview

Single Board Computers Intel Server Board S5500HCV

BB5500HCV Parametric

Parameter Name	Attribute value
Product Attribute	Attribute Value
Manufacturer	Intel
Product Category	Single Board Computers
RoHS	Details
Form Factor	SSI EEB
Processor Brand	Intel
Processor Type	Intel Xeon 5500/5600
Frequency	2.53 GHz, 2.4 GHz
Memory Size	144 GB
Interface Type	Ethernet, LAN, PCI, PS2, Serial, SATA, USB
Operating Supply Voltage	3.3 V, 5 V, 12 V
Maximum Operating Temperature	+ 55 C
Dimensions	12 in x 13 in
Packaging	Bulk
Description/Function	Monolithic printed circuit board with features that support the pedestal server markets
Memory Type	DDR3
Battery Backup Switching	Backup Battery
Chipsets	5520, 5500, 82801 JIR
Core	Intel Xeon 5500/5600
Minimum Operating Temperature	0 C
Factory Pack Quantity	10

Preview

Download Datasheet

View All

Intel®

Server Boards S5520HC,

S5500HCV, and S5520HCT

Technical Product Specification

Intel order number E39529-013

Revision 1.9

June 2011

Enterprise Platforms and Services Division

Intel®

Server Boards S5520HC, S5500HCV, and S5520HCT TPS

Disclaimers

Information in this document is provided in connection with Intel

products. No license, express or implied, by

estoppel or otherwise, to any intellectual property rights is granted by this document. Except as provided in Intel's

Terms and Conditions of Sale for such products, Intel assumes no liability whatsoever, and Intel disclaims any

express or implied warranty, relating to sale and/or use of Intel products including liability or warranties relating to

fitness for a particular purpose, merchantability, or infringement of any patent, copyright or other intellectual property

right. Intel products are not intended for use in medical, life saving, or life sustaining applications. Intel may make

changes to specifications and product descriptions at any time, without notice.

Designers must not rely on the absence or characteristics of any features or instructions marked "reserved" or

"undefined." Intel reserves these for future definition and shall have no responsibility whatsoever for conflicts or

incompatibilities arising from future changes to them.

The Intel

Server Boards S5520HC, S5500HCV and S5520HCT may contain design defects or errors known as

errata which may cause the product to deviate from published specifications. Refer to the Intel

Server Boards

S5520HC, S5500HCV and S5520HCT Specification Update for published errata.

Intel Corporation server baseboards contain a number of high-density VLSI and power delivery components that

need adequate airflow to cool. Intel‘s own chassis are designed and tested to meet the intended thermal

requirements of these components when the fully integrated system is used together. It is the responsibility of the

system integrator that chooses not to use Intel developed server building blocks to consult vendor datasheets and

operating parameters to determine the amount of air flow required for their specific application and environmental

conditions. Intel Corporation can not be held responsible if components fail or the server board does not operate

correctly when used outside any of their published operating or non-operating limits.

Intel, Pentium, Itanium, and Xeon are trademarks or registered trademarks of Intel Corporation.

*Other brands and names may be claimed as the property of others.

Revision 1.9

Intel order number E39529-013

iii

Table of Contents

Intel®

Server Boards S5520HC, S5500HCV, and S5520HCT TPS

Table of Contents

Introduction .......................................................................................................................... 1

1.1

Chapter Outline ........................................................................................................ 1

1.2

Server Board Use Disclaimer .................................................................................. 1

2. Overview ............................................................................................................................... 2

2.1

Intel

Server Boards S5520HC, S5500HCV and S5520HCT Feature Set .............. 2

* The PCI Express* Gen 1 slot (x8 Mechanically, x4 Electrically) is not available when the

SAS module slot is in use and vice versa. ................................................................................. 4

**The Trusted Platform Module is only availabe in S5520HCTServer Board Layout ................ 4

Server Board Layout .................................................................................................................. 5

2.1.1

Server Board Connector and Component Layout .................................................... 5

2.1.2

Server Board Mechanical Drawings ........................................................................ 8

2.1.3

Server Board Rear I/O Layout ............................................................................... 16

3. Functional Architecture ..................................................................................................... 17

3.1

Intel

5520 and 5500 I/O Hub (IOH) ...................................................................... 20

3.1.1

Intel

QuickPath Interconnect ................................................................................ 20

3.1.2

PCI Express* Ports ................................................................................................ 20

3.1.3

Enterprise South Bridge Interface (ESI) ................................................................ 21

3.1.4

Manageability Engine (ME) .................................................................................... 21

3.1.5

Controller Link (CL) ................................................................................................ 21

3.2

Processor Support ................................................................................................. 22

3.2.1

Processor Population Rules .................................................................................. 22

3.2.2

Mixed Processor Configurations. ........................................................................... 22

3.2.3

Intel

Hyper-Threading Technology (Intel

HT) ..................................................... 24

3.2.4

Enhanced Intel SpeedStep

Technology (EIST) ................................................... 24

3.2.5

Intel

Turbo Boost Technology .............................................................................. 24

3.2.6

Execute Disable Bit Feature .................................................................................. 24

3.2.7

Core Multi-Processing ........................................................................................... 25

3.2.8

Direct Cache Access (DCA) .................................................................................. 25

3.2.9

Unified Retention System Support ......................................................................... 25

3.3

Memory Subsystem ............................................................................................... 27

3.3.1

Memory Subsystem Nomenclature ........................................................................ 27

3.3.2

Supported Memory ................................................................................................ 29

3.3.3

Processor Cores, QPI Links and DDR3 Channels Frequency Configuration ........ 30

3.3.4

Publishing System Memory ................................................................................... 32

3.3.5

Memory Interleaving .............................................................................................. 32

3.3.6

Memory Test .......................................................................................................... 33

3.3.7

Memory Scrub Engine ........................................................................................... 33

3.3.8

Memory RAS ......................................................................................................... 33

3.3.9

Memory Population and Upgrade Rules ................................................................ 34

Intel order number E39529-013

Revision 1.9

Intel®

Server Boards S5520HC, S5500HCV, and S5520HCT TPS

Table of Contents

3.3.10 Supported Memory Configuration .......................................................................... 36

3.3.11 Memory Error Handling .......................................................................................... 38

3.4

ICH10R .................................................................................................................. 39

3.4.1

Serial ATA Support ................................................................................................ 39

3.4.2

USB 2.0 Support .................................................................................................... 41

3.5

PCI Subsystem ...................................................................................................... 42

3.5.1

PCI Express* Riser Slot (S5520HC – Slot 6) ......................................................... 43

3.6

Intel

SAS Entry RAID Module AXX4SASMOD (Optional Accessory) .................. 44

3.6.1

SAS RAID Support ................................................................................................ 45

3.7

Baseboard Management Controller ....................................................................... 47

3.7.1

BMC Embedded LAN Channel .............................................................................. 48

3.8

Serial Ports ............................................................................................................ 49

3.9

Floppy Disk Controller ........................................................................................... 49

3.10

Keyboard and Mouse Support ............................................................................... 49

3.11

Video Support ........................................................................................................ 49

3.11.1 Video Modes .......................................................................................................... 49

3.11.2 Dual Video ............................................................................................................. 50

3.12

Network Interface Controller (NIC) ........................................................................ 51

3.12.1 MAC Address Definition ......................................................................................... 51

3.13

*Trusted Platform Module (TPM) – Supported only on S5520HCT ....................... 52

3.13.1 Overview ................................................................................................................ 52

3.13.2 TPM security BIOS ................................................................................................ 52

3.13.3 Intel

Trusted Execution Technology (Intel

TXT) ................................................. 55

3.14

ACPI Support ......................................................................................................... 59

3.15

Intel

Virtualization Technology ............................................................................. 60

3.15.1 Intel

Virtualization Technology for Directed IO (VT-d) .......................................... 60

4. Platform Management ........................................................................................................ 61

4.1

Feature Support ..................................................................................................... 61

4.1.1

IPMI 2.0 Features .................................................................................................. 61

4.1.2

Non-IPMI Features ................................................................................................ 61

4.2

Optional Advanced Management Feature Support ............................................... 63

4.2.1

Enabling Advanced Management Features ........................................................... 63

4.2.2

Keyboard, Video, and Mouse (KVM) Redirection .................................................. 63

4.2.3

Media Redirection .................................................................................................. 64

4.2.4

Web Services for Management (WS-MAN) ........................................................... 65

4.2.5

Embedded Web server .......................................................................................... 66

4.2.6

Lightweight Directory Authentication Protocol (LDAP) .......................................... 66

4.3

Platform Control ..................................................................................................... 67

4.3.1

Memory Open and Closed Loop Thermal Throttling .............................................. 68

4.3.2

Fan Speed Control ................................................................................................. 68

4.4

Intel

Intelligent Power Node Manager .................................................................. 70

Revision 1.9

Intel order number E39529-013

BB5500HCV Related Products

	BB5500HCV	BB5500HCVR	S5500HCVR
Description	Single Board Computers Intel Server Board S5500HCV	Single Board Computers	Single Board Computers Intel Server Board S5500HCV
Product Attribute	Attribute Value	Attribute Value	Attribute Value
Manufacturer	Intel	Intel	Intel
Product Category	Single Board Computers	Single Board Computers	Single Board Computers
Form Factor	SSI EEB	SSI EEB	SSI EEB
Processor Brand	Intel	Intel	Intel
Processor Type	Intel Xeon 5500/5600	Intel Xeon 5500/5600	Intel Xeon 5500/5600
Frequency	2.53 GHz, 2.4 GHz	2.53 GHz, 2.4 GHz	2.53 GHz, 2.4 GHz
Memory Size	144 GB	144 GB	144 GB
Interface Type	Ethernet, LAN, PCI, PS2, Serial, SATA, USB	Ethernet, LAN, PCI, PS2, Serial, SATA, USB	Ethernet, LAN, PCI, PS2, Serial, SATA, USB
Operating Supply Voltage	3.3 V, 5 V, 12 V	3.3 V, 5 V, 12 V	3.3 V, 5 V, 12 V
Maximum Operating Temperature	+ 55 C	+ 55 C	+ 55 C
Dimensions	12 in x 13 in	12 in x 13 in	12 in x 13 in
Description/Function	Monolithic printed circuit board with features that support the pedestal server markets	Monolithic printed circuit board with features that support the pedestal server markets	Monolithic printed circuit board with features designed to support the pedestal server markets
Memory Type	DDR3	DDR3	DDR3
Battery Backup Switching	Backup Battery	Backup Battery	Backup Battery
Chipsets	5520, 5500, 82801 JIR	5520, 5500, 82801 JIR	5520, 5500
Core	Intel Xeon 5500/5600	Intel Xeon 5500/5600	Intel Xeon 5500/5600
Minimum Operating Temperature	0 C	0 C	0 C
RoHS	Details	-	Details
Packaging	Bulk	-	Bulk
Factory Pack Quantity	10	-	5

Recommended Resources

Moving magnet phono equalization circuit and microphone input circuit

Power supply circuit diagram without power transformer

Simple two-tone generator circuit diagram

Moisture meter circuit diagram

IBM-PC/XT power supply circuit diagram 01

Circuit diagram of Zhengye luxury two-way linked shutter ventilation fan

Simple wireless microphone: If your radio has an FM receiving band, you might as well make a wireless microphone to add a lot of fun to your life. Here is a wireless microphone with an effective distance of about 100 meters in a...; fighting RF/Wirelessly

[STM32 IIC+24LC512] Parameter reading, writing and storage issues: [color=rgb(51,51,51)][backcolor=rgb(255,255,255)][size=5]As the title says: Use the IIC interface of STM32 to control the reading and writing of 24LC512. The parameters can be written into the chip no...; gasasong stm32/stm8

I'm urgently looking for the program code for DSP control to write to CF card. Related information is also OK. Thanks for your help!: How to use DSP to control writing data to CF card? What is the specific process? Please give me some advice. I need the program code of DSP to control writing data to CF card. Related information is a...; chenyi9258 Embedded System

Intermittent misfire caused by faulty ignition coil: Fault phenomenon: A Shanghai GM Wuling LZW6360Ei7 minibus equipped with an electronic fuel injection engine. The vehicle had serious acceleration failure and "cylinder missing" phenomenon, so it could...; 村口的大爷 Automotive Electronics

Questions about using Keil software: [i=s] This post was last edited by paulhyde on 2014-9-15 03:13 [/i] My keil software can find the STC51 series model when I start to build a project. However, after using the keil software to build a ...; STM32MSP430 Electronics Design Contest

Basic skills and professional theoretical knowledge required by power supply engineers (salary evaluation): The design process of switching power supply products is actually a process of optimization and compromise. Engineers often hesitate between various electrical performance parameters, such as the comp...; lhx654321 Power technology

Shortcut: L0 L1 L2 L3 L4 L5 L6 L7 L8 L9 LA LB LC LD LE LF LG LH LI LJ LK LL LM LN LO LP LQ LR LS LT LU LV LW LX LY LZ M0 M1 M2 M3 M4 M5 M6 M7 M8 M9 MA MB MC MD ME MF MG MH MI MJ MK ML MM MN MO MP MQ MR MS MT MU MV MW MX MY MZ N0 N1 N2 N3 N4 N5 N6 N7 N8 NA NB NC ND NE NF NG NH NI NJ NK NL NM NN NO NP NQ NR NS NT NU NV NX NZ O0 O1 O2 O3 OA OB OC OD OE OF OG OH OI OJ OK OL OM ON OP OQ OR OS OT OV OX OY OZ P0 P1 P2 P3 P4 P5 P6 P7 P8 P9 PA PB PC PD PE PF PG PH PI PJ PK PL PM PN PO PP PQ PR PS PT PU PV PW PX PY PZ Q1 Q2 Q3 Q4 Q5 Q6 Q8 Q9 QA QB QC QE QF QG QH QK QL QM QP QR QS QT QV QW QX QY R0 R1 R2 R3 R4 R5 R6 R7 R8 R9 RA RB RC RD RE RF RG RH RI RJ RK RL RM RN RO RP RQ RR RS RT RU RV RW RX RY RZ

Popular Components
