intel® Desktop Board DB75EN
Executive Series
Built for Business:
Make your pc your favorite spot for work:
Intel® Desktop Board DB75EN maximizes • VGA and DVI-D graphics output with dual
display capability
employee productivity, PC performance,
and data security with Intel® Small Business • Great network connectivity with integrated
Advantage
1
. With five onboard SATA ports
10/100/1000 network connection.
including one SATA 6.0 Gb/s port and multiple • Rich sound quality of Intel® High Definition
legacy connectivity options, including a parallel
Audio
3
with 5.1-channel surround sound
port, PS/2 port, the Intel® Desktop Board • Certified with the following operating sys-
DB75EN delivers remarkable expansion pos-
tems: Windows*7, openSUSE*, and RedHat*
sibilities for both legacy and the latest periph-
Linux*.
erals. Intel® Desktop Board DB75EN supports
up to 32 GB
2
DDR3 1333/1066 MHz memory
iNTEL® SMALL BuSiNESS ADVANTAGE
1
using 4 DIMMS and has VGA
8
and DVI-D
8
graphics output with dual display capability.
– The right Solution for Any Small Business
Supports the 2 and 3 Generation intel®
core™ processors in the LGA 1155 package
nd
rd
The boxed intel® Desktop Board
DB75EN solution includes:
• ATX 2.2 compliant I/O shield
• SATA cables
• Board and back panel I/O layout
• Integration guide
• Intel® Express Installer driver
and software DVD
The Intel® Desktop Board DB75EN is based
on the Intel® B75 Express Chipset and sup-
ports 2
nd
and 3
rd
generation Intel® Core™
Processors in the LGA 1155 package. The visibly
smart Intel Core processor family provides
amazing performance and stunning visuals
with smart features, so the PC adapts to your
needs.
3, 4
The combination of performance
and hardware-based protection makes Intel
Core processor-based PCs the ideal choice
for your small business.
Intel® Small Business Advantage
1
comes with
built-in IT support.
5
Once configured, this
state-of-the-art technology continually mon-
itors your security software and alerts you
if it’s been compromised by viruses or mal-
ware.
6
It will automatically back-up your com-
pany’s data and manage routine maintenance
tasks like running software updates, defrag-
ging disk drives and deleting cookies and
temporary internet files after hours, so your
employees won’t be interrupted.
6, 7
VALuE-ADDED SoFTWArE
check out the vast range of software and special offers
Security
Protect against antivirus threats with industry-
leading solutions from McAfee* (60-day license)
and ESET* Smart Security
Enhance your PC performance with Intel® Small
Business Advantage, Splashtop* Remote Desktop,
and Laplink PCmover*
Monitor PC health with Intel® Desktop Utilities
Business and Office
utilities
2
intel® Desktop Board DB75EN
Features and Benefits
16
7
5
15
14
Executive Series
13
10
9
8
1
Supports the 3
rd
-generation intel®
core™ processors, including the intel®
core™ i7, the intel® core™ i5 processors
and other intel® processors in the
LGA1155 package for exceptional
performance
2
intel® B75 Express chipset pcH
3
Dual-channel DDr3 with four connec-
tors for 1600/1333 MHz memory
support (32 Gb
6
max):
Supports 1.2 V
to 1.8 V memory voltage control
for maximum DIMM compatibility
4
Five SATA ports:
Facilitate high-speed
storage and data transfers with one
6.0 Gb/s port and four 3.0 Gb/s ports
8
pci Express* 3.0 ×16 graphics connector:
Delivers up to 8 GT/s bandwidth
9
one pci Express* ×1 connector
10
Two pci connectors
11
Eight uSB 2.0 ports:
Four back panel ports
and four additional ports via internal headers
12
Four uSB 3.0 ports:
Two back panel ports
and two additional ports via internal headers
13
VGA and DVi-i:
Dual independent display
capability for multiple display support
14
pS/2:
Supports keyboard or mouse
15
parallel:
Supports legacy parallel peripherals
and security dongles
16
MicroATX form factor
9.6” (24.38cm)
1
11
2
3
12
5
integrated 10/100/1000 Network
connection
6
TpM Header:
Improve platform security
with an optional TPM module
7
Six-channel Intel® High Definition
Audio
3
:
Audio subsystem with three
analog audio outputs (5.1+ 2 indepen-
dent multi-streaming)
4
6
9.6” (24.38cm)
12
15
5
7
11
13
12
3
intel® Desktop Board DB75EN
Technical Specifications
Executive Series
procESSor
processor Support
• Intel® Core™ i7 and Intel® Core™ i5 processors and other
Intel® processors in the LGA1155 package
• Supports Intel® 64 architecture
7
cHipSET
intel® B75 Express chipset
• Intel® 82B75 Platform Controller Hub (PCH)
pEripHErAL coNNEcTiViTY
• One SATA (6.0 Gb/s) ports
• Four SATA (3.0 Gb/s) ports
• Integrated 10/100/1000 Network Connection
• Eight Hi-Speed USB 2.0 ports (four back panel ports
and six additional ports via three internal headers)
• Four Super Speed USB 3.0 ports (two back panel ports
and two ports via internal header
• Parallel Port connectivity
SYSTEM BioS
• 96 Mb Flash EEPROM with Intel® Platform Innovation
Framework for EFI Plug and Play
• Advanced configuration and power interface V3.0b,
SMBIOS 2.5
• Intel® Express BIOS update support
SYSTEM MEMorY
Memory capacity
• Four 240-pin DIMM connectors supporting up to four
double-sided DIMMs (32 GB
6
max)
Memory Types
• DDR3 1600/13335 SDRAM memory support
• Non-ECC Memory
Memory Modes
• Dual- or single-channel operation support
Memory Voltage
• 1.2 V to 1.8 V
HArDWArE MANAGEMENT FEATurES
• Processor fan speed control
• System chassis fan speed control
• Voltage and temperature sensing
• Fan sensor inputs used to monitor fan activity
• ACPI-compliant power management control
iNTEL® pro 10/100/1000 NETWorK coNNEcTioN
• Low-power design
EXpANSioN cApABiLiTiES
• Two PCI bus add-in card connectors
• One PCI Express* ×1 bus add-in card connector
• One PCI Express 3.0 ×16 graphics connector
HEADErS
• One serial port header
• S/PDIF audio header
• TPM header
AuDio
• Eight-channel Intel® High Definition Audio
3
codec
JuMpErS AND FroNT-pANEL coNNEcTorS
Jumpers
• Single configuration jumper design
• Jumper access for BIOS maintenance mode
Front-panel connectors
• Reset, HDD LED, power LEDs, power on/off
• Front-panel Super-Speed USB 3.0 header
• Front-panel Hi-Speed USB 2.0 headers
• Front-panel audio header
MEcHANicAL
Board Style
• MicroATX 2.2-compliant
Board Size
• 9.6” × 9.6” (24.38 cm × 24.38 cm)
Baseboard power requirements
• ATX 12 V
ENViroNMENT
operating Temperature
• 0° C to +55° C
Storage Temperature
• -20°C to +70°C
rEGuLATioNS AND SAFETY STANDArDS
united States and canada
CSA/UL 60950-1, First Edition (Binational Standard)
Europe
(Low Voltage Directive 2006/95/EC) EN 60950-1
international
IEC 60950-1
EMc rEGuLATioNS (tested in representative chassis)
united States
FCC 47 CFR Part 15, Subpart B
canada
ICES-003 Class B
Europe
(EMC Directive 2004/108/EC) EN 55022 and EN 55024
Australia / New Zealand
EN 55022 Class B
Japan
VCCI V-3, V-4 Class B
South Korea
KN-22 and KN-24
Taiwan
CNS 13438 Class B
international
CISPR 22 Class B
ENViroNMENTAL coMpLiANcE EuropE
Europe
RoHS (Directive 2002/95/EC)
china
China RoHS (MII Order # 39)
1 Requires Intel® Core™ i3 processor or above.
2 System resources and hardware (such as PCI and PCI Express*) require physical
memory address locations that can reduce available addressable system memory.
This could result in a reduction of as much as 1 GB or more of physical addressable
memory being available to the operating system and applications, depending on
the system configuration and operating system.
3 (Turbo) Requires a system with Intel® Turbo Boost Technology. Intel® Turbo Boost
Technology and Intel® Turbo Boost Technology 2.0 are only available on select
Intel® processors. Consult your PC manufacturer. Performance varies depending
on hardware, software and system configuration. For more information, visit http://
www.intel.com/go/turbo
4 (Built-in visuals) Built-in visual features are not enabled on all PCs and optimized
software may be required. Check with your system manufacturer. Learn more at
http://www.intel.com/go/biv
5 Requires an Intel® Small Business Advantage
1
enabled system and proper configu-
ration. Availability of features will depend upon the setup and configuration by
your PC manufacturer. Consult your system manufacturer.
6 (SBA/Security/After-hours) Requires an Intel® Small Business Advantage
1
enabled
system and a third-party security application pre-configured by your PC manufac-
turer. Certain maintenance tasks require internet access. For after-hours feature
to work, the PC must be connected to AC power.
7 (SBA/Data Backup) Requires an Intel® Small Business Advantage
1
enabled system
and proper configuration. Data Backup & Restore may be replaced by your PC
manufacturer. Consult your system manufacturer.
8 Requires a processor with Intel® HD Graphics.
INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL®
PRODUCTS. NO LICENSE, EXPRESS OR IMPLIED, BY ESTOPPEL OR OTHERWISE,
TO ANY INTELLECTUAL PROPERTY RIGHTS IS GRANTED BY THIS DOCUMENT.
EXCEPT AS PROVIDED IN INTEL’S TERMS AND CONDITIONS OF SALE FOR SUCH
PRODUCTS, INTEL ASSUMES NO LIABILITY WHATSOEVER, AND INTEL DISCLAIMS
ANY EXPRESS OR IMPLIED WARRANTY, RELATING TO SALE AND/OR USE OF INTEL
PRODUCTS INCLUDING LIABILITY OR WARRANTIES RELATING TO FITNESS FOR A
PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT OF ANY PATENT,
COPYRIGHT, OR OTHER INTELLECTUAL PROPERTY RIGHT.
Intel products are not intended for use in medical, life-saving, or life-sustaining
applications. Intel may make changes to specifications and product descriptions
at any time, without notice.
All products, dates, and figures specified are preliminary based on current expec-
tations, and are subject to change without notice. Availability in different channels
may vary.
Actual Intel® Desktop Board may differ from the image on the box.
Copyright © 2012 Intel Corporation. All rights reserved. Intel, the Intel logo, and Intel
Core are trademarks of Intel Corporation in the U.S. and other countries.
* Other names, brands, and logos may be claimed as the property of others.
