2-Port DVI Splitter with Audio and Signal
Booster, Single-Link 1920x1200 at 60Hz/1080p
(DVI F/2xF), TAA
MODEL NUMBER:
B116-002A
Highlights
q
Transmits a DVI-D Single Link
video signal and 3.5mm audio
signal to two sets of DVI
monitors and speakers
q
Supports DVI Single Link
computer video resolutions up to
1920 x 1200, and HD
resolutions up to 1080p.
q
Built-in signal booster extends
the distance between the splitter
and connected monitors past
the 16 ft. (5 m.) distance
limitation
q
Expand the number of
connected monitors/speakers by
cascading up to 3 levels of
Description
With Tripp Lite's 2-Port DVI + Audio Splitter, you can transmit a DVI-D Single Link video signal and 3.5
mm. audio signal to two sets of monitors and speakers. Supports DVI Single Link computer video
resolutions up to 1920 x 1200, and HD resolutions up to 1080p. The unit is HDCP, EDID, and DDC
compatible. A built-in signal booster allows you to extend the distance between the splitter and connected
monitors past the 16 ft. (5 m.) distance limitation.
q
q
splitters together
Supports HDCP, EDID and DDC
Compliant with the Federal
Trade Agreements Act (TAA) for
GSA Schedule purchases
System Requirements
For source video resolutions anywhere from 1600 x 1200 @ 60Hz to 1920 x 1200 @ 60Hz - The distance
between the splitter and the connected monitor/speakers must not exceed 49 ft. (15 m.). This distance
can be extended by using a B120-000-SL DVI extender. The B120-000-SL can be located up to 65 ft. (20
q
q
Video graphics card with a DVI-
D or DVI-I connector
Monitors with a DVI-D or DVI-I
connector
m.) from the splitter, and 16 ft. (5 m.) from the connected monitor.
q
For source video resolutions lower than 1600 x 1200 @ 60Hz -
The distance between the splitter and
the connected monitor/speakers must not exceed 65 ft. (20 m.). This distance can be extended by using a
B120-000-SL DVI extender. The B120-000-SL can be located up to 114 ft. (35 m.) from the splitter, and
16 ft. (5 m.) from the connected monitor.
Speakers and/or monitor with a
3.5 mm. audio connector
Package Includes
q
B116-002A
Mounting Hardware
External Power Supply with
NEMA 1-15P Plug (Input: 100-
240V, 50/60Hz, 0.5A; Output:
5V, 2A, 5 ft.)
The number of connected monitors/speakers can be expanded by cascading up to three levels of splitters.
Plug and Play...no software or drivers required. Mounting hardware is included with the product, and
allows it to be rackmounted, wallmounted or pole-mounted. Compliant with the Federal Trade Agreements
Act (TAA) for GSA Schedule purchases.
q
q
Features
q
Transmit a DVI-D Single Link video signal and 3.5 mm. audio signal to two sets of monitors and
speakers
1/3
q
Owner’s Manual
q
Supports DVI Single Link computer video resolutions up to 1920 x 1200, and HD resolutions up to
1080p
q
HDCP, EDID, and DDC compatible
Built-in signal booster allows you to extend the distance between the splitter and connected monitors
past the 16 ft. (5 m.) distance limitation
q
q
The number of connected monitors/speakers can be expanded by cascading up to three levels of
splitters
q
Plug and Play...no software or drivers required. Mounting hardware is included with the product, and
allows it to be rackmounted, wallmounted or pole-mounted
q
Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases
Specifications
OVERVIEW
UPC Code
AC Adapter
037332156747
Input: 100-240V, 50/60Hz, 0.5A; Output: 5V, 2A, 5 ft.
PHYSICAL
Shipping Dimensions (hwd / in.)
Shipping Dimensions (hwd / cm)
Shipping Weight (lbs.)
Shipping Weight (kg)
Unit Dimensions (hwd / in.)
Unit Dimensions (hwd / cm)
Unit Weight (lbs.)
Unit Weight (kg)
Color
7.00 x 2.40 x 6.40
17.78 x 6.10 x 16.26
1.10
0.50
1.1 x 4.5 x 2.5
2.8 x 11.4 x 6.4
0.5
0.23
Black
ENVIRONMENTAL
Operating Temperature Range
Storage Temperature Range
Operating Humidity Range
Storage Humidity Range
32º to 104º F (0° to 40°C)
-4º to 140º F (-20° to 60° C)
20 to 90%
20 to 90%
COMMUNICATIONS
Max 1024 x 768 Range (ft)
Max 480P Range (ft)
80
80
2/3
Max 1440 x 900 Range (ft)
Max 1080i Range (ft)
Max 1080P Range (ft)
Max 480i Range (ft)
Max 640 x 480 Range (ft)
Max 800 x 600 Range (ft)
Max 1600 x 1200 Range (ft)
Max 1920 x 1200 Range (ft)
Max 720P Range (ft)
80
65
65
80
80
80
80
65
80
CONNECTIONS
Ports
Side A - Connector 1
Side A - Connector 2
Side B - Connector 1
Side B - Connector 2
2
DVI-I (FEMALE)
3.5MM (FEMALE)
(2) DVI-I (FEMALE)
(2) 3.5MM (FEMALE)
FEATURES & SPECIFICATIONS
Technology
DVI; Stereo Audio
WARRANTY
Product Warranty Period
(Worldwide)
3-year limited warranty
© 2018 Tripp Lite. All rights reserved. All product and company names are trademarks or registered trademarks of their respective holders. Use of them does
not imply any affiliation with or endorsement by them. Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice.
Tripp Lite uses primary and third-party agencies to test its products for compliance with standards. See a list of Tripp Lite's testing agencies:
https://www.tripplite.com/products/product-certification-agencies
3/3
