NXP evaluation kit
JN5169-EK004
Easy development of ZigBee & IEEE 802.15.4
applications with NFC
Providing all the hardware and software components for full application design, this kit
simplifies development for systems running ZigBee and IEEE 802.15.4 network stacks, and
enables easy, secure NFC commissioning for faster, simpler installations.
KEY FEATURES
`
Two carrier boards with integrated NFC tag (NT3H1101)
`
NFC reader expansion board for Raspberry Pi
`
Two expansion boards with sensors and buttons
`
Two JN5169 USB dongles
`
One Wi-Fi dongle compatible with Raspberry Pi
`
Complete software development kit (SDK)
- GNU-based toolchain with C compiler
- Flash programmer
- Eclipse IDE
- Microcontroller and peripheral libraries
KEY BENEFITS
`
Quick and easy product development
`
Integrated secure NFC commissioning SW and HW
`
Free, unrestricted Eclipse-based SDK
`
Hardware platform supports all sensors, displays, LEDs,
switches
KEY APPLICATIONS
`
Internet of Things (IoT)
`
ZigBee LightLink (LL)
`
`
`
`
`
ZigBee home automation
Home and building automation
Smart lighting
Remote controls
Wireless sensor networks
The NXP JN5169-EK004 evaluation kit is specifically designed
for use with the NXP JN516x series, a range of ultra-low-
power, high-performance wireless microcontrollers suitable
for home-automation and smart-lighting applications. This
comprehensive kit – which includes a series of wireless
carrier boards, plug-in expansion boards, USB dongles,
remote control, Raspberry Pi single board computer (with
programmed micro-SDcard acting as a border-router), and a
complete software design kit – provides everything necessary
for system development.
The supplied Raspberry Pi single-board computer, which runs
NXP OpenWRT firmware, makes it easy to develop solutions
that include sensor-equipped objects as part of the Internet of
Things (IoT).
Thanks to the pre-loaded Smart Home Demonstration, based
on a ZigBee PRO Home Automation application, designers can
quickly produce demonstrators or proof-of-concept products.
The same software can then be used for end products, using
JN5169 ICs or modules. Moreover, the evaluation kit supports
the ZigBee Light Link and Home Automation profiles, as well
as pure IEEE802.15.4 applications. Descriptions and examples
of these protocols/profiles are available in Application Notes
from the NXP Wireless Connectivity TechZone (www.nxp.com/
techzones/wireless-connectivity/overview.html).
The kit also includes a network sniffer license from Ubilogix,
free for use for 45 days, plus a JTAG extension board. The
network sniffer works with the second USB dongle as the
primary device. The JTAG expansion board is compatible
with the Beyond® Semiconductor debug probe, which can
be purchased separately at www.beyondsemi.com/beyond-
debug-key.
The JN5169-EK004 evaluation kit can be ordered using the
reference JN5169HA/EVAL1. Expansion nodes are available in
two kits, the JN516x-XK010 ZigBee Generic Node Expansion
Kit and the JN516x-XK020 ZigBee Lighting/Sensor Node
Expansion Kit.
JN5169 WIRELESS MICROCONTROLLER
The JN5169 is an ultra-low-power, high-performance wireless
microcontroller suitable for ZigBee applications. It features
512 kB embedded Flash, 32 kB RAM and 4 kB EEPROM memory,
allowing OTA upgrade capability without external memory.
The 32-bit RISC processor offers high coding efficiency
through variable width instructions, a multi-stage instruction
pipeline and low-power operation with programmable clock
speeds. It also includes a 2.4 GHz IEEE 802.15.4-compliant
transceiver and a comprehensive mix of analog and digital
peripherals. The best-in-class Rx operating current (down to
13 mA and with a 0.7 µA sleep timer mode) gives excellent
battery life and allows direct operation from a coin cell. It
integrates a 10 dBm power amplifier, which greatly extends
the operating range of the device and thereby improves the
robustness of the connectivity.
JN5169 block diagram
JN5169-EK004 KIT CONTENTS
`
Raspberry Pi single-board computer with programmed
micro-SDcard (to act as border-router) and microSD adaptor
`
5 V DC power supply unit (universal type) for Raspberry Pi
RJ45 Ethernet cable for Linksys router
`
`
`
`
`
`
`
`
`
12 V DC power supply unit (universal type) for carrier boards
RJ45 Ethernet cable
USB Wi-Fi dongle compatible with Raspberry Pi
NFC reader PN7120 expansion board for Raspberry Pi
Two JN5169 USB dongles with integrated antenna
Two JN5169 standard-power modules with integrated
antenna (both pre-fitted to Carrier Boards)
Two generic Expansion Boards
JTAG Expansion Board
Two carrier boards containing NFC tag NT3H1101
- one pre-fitted with Generic Expansion Board and JN5169
module with integrated antenna
- one pre-fitted with Lighting/Sensor Expansion Board and
JN5169 module with integrated antenna
5-way 2.1 mm daisy-chain power-extender cable
USB-to-USB extension cable
Two USB-A-to-Mini-B cables
USB to Micro USB cable (for supplying Raspberry Pi)
9 packs of AAA batteries
`
`
`
`
`
www.nxp.com
© 2015 NXP Semiconductors N.V.
All rights reserved. Reproduction in whole or in part is prohibited without the prior written consent of the copyright owner. The
information presented in this document does not form part of any quotation or contract, is believed to be accurate and reliable and
may be changed without notice. No liability will be accepted by the publisher for any consequence of its use. Publication thereof
does not convey nor imply any license under patent- or other industrial or intellectual property rights.
Date of release: December 2015
Document order number: 9397 750 17675
Printed in the Netherlands
