Motor Driven Card Reader/Writer
Versatile Hybrid Reader/Writer Handles
Both Magnetic and IC Cards
s
Durable 4-wheel, 2-belt drive with roller
3S4YR-MKW
s
s
s
s
accommodates discrepancies in card thickness
to accept warped or bent cards
Metal blade shutter prevents tampering
Compact size and light weight allow easy
installation in any terminal
Two integrated chip station positions available
Adjustable to card thicknesses of 0.20 mm,
0.40 mm, and 0.76 mm
(PET, paper, or PVC cards)
s
HiCo write capability available
s
Watermark capability available
Ordering Information
Magnetic Tracks Supported (R, R/W)
1
R/W
R/W
R/W
R/W
R/W
R/W
—
—
—
—
R/W
—
2
R/W
R/W
R/W
R/W
R/W
—
R/W
R/W
R/W
—
R/W
R/W
3
R/W
R/W
R/W
R/W
R/W
—
—
—
—
R/W
—
R/W
Center
—
—
—
—
—
—
—
—
—
—
—
—
JIS II
—
—
—
—
—
—
—
—
—
—
—
—
IC Contact
ISO 7816
Option
Option
Option
Option
Option
Option
Option
Option
Option
Option
Interface
TTL
TTL
TTL
TTL
TTL
TTL
TTL
TTL
TTL
TTL
TTL
Shutter
Yes
Yes
Option
Option
Yes
Option
Option
Option
Yes
Option
Option
Option
Cover
No
No
No
No
No
No
No
No
No
No
No
No
Cable
No
No
No
No
No
No
No
No
No
No
No
No
Color
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Part Number
3S4YR-MKW1JD
3S4YR-MKW1XD
3S4YR-MKW1PC
3S4YR-MKW1PCH
3S4YR-MKW1PD
3S4YR-MKW3PC
3S4YR-MKW4PC
3S4YR-MKW4PCH
3S4YR-MKW4PD
3S4YR-MKW5PC
3S4YR-MKW6PC
3S4YR-MKW7PCk
ISO 7816/CP8 TTL
Note: Only the MKW1PCH and MKW4PCH are capable of writing HiCo cards. All models can read HiCo cards.
3S4YR-MKW
s
TYPICAL APPLICATIONS
• Cash Dispensers
• Automatic Teller Machines (ATM)
• POS Terminals
• Credit Card Checkers
• ID Card Checkers
• Electronic Lock Systems
• Medical Patient Systems
• Health Control Systems
3S4YR-MKW
s
ACCESSORIES
Description
IC Contact, chip on the front, lower position
IC Contact, chip on the front, upper and lower positions
Shutter for MKW1PC, MKW1PCH, MKFW1PC
Shutter for MKW3PC
Shutter for MKW4PC, MKW4PCH
Shutter for MKW5PC
Shutter for MKW6PC
Shutter for MKW7PC
MM Sensor Holder (MM sensor itself must be purchased from the manufacturer.)
Watermark Reader Head. Cannot be used to write track 1.
Watermark Circuit Board. Cannot be used to write track 1.
Part Number
IC CONTACT J
IC CONTACT X
SHUTTER MK3
SHUTTER MK4
SHUTTER MK5
SHUTTER MK6
SHUTTER MK7
MM HOLDER
WATERMARK HEAD
WATERMARK PCB
(See note 2)
(See note 2)
(See note 1)
(See note 1)
SHUTTER MKD1
Note 1: Consult your Omron sales representative for IC contact accessories. Special configurations can be supplied.
2: Watermark Reader Head and Watermark Circuit Board must be ordered together.
Specifications
Part number
Recommended card type
Recording method
Card feeding speed
Motor type
Service life
(See note)
Operating power supply
Amplifier
Motor
Control logic
Current consumption
Amplifier
Motor
Control logic
Mounting location
Mounting orientation
Ambient temperature
Ambient humidity
Vibration
Shock
Dimensions
Weight
Note: One pass denotes one round trip.
2
With shutter
Without shutter
Operation
Storage
Operation
Storage
Magnetic card
IC card
3S4YR-MKW
ISO 7810-7813
ISO 7816/1, 2
FM decoding (F2F)
20 cm/sec
±
10% (7.87 in/sec)
DC motor
1,200,000 passes min.
24 VDC
±
10%
24 VDC
±
10%
5 VDC
±
5%
260 mA max.
1.7 A max.
330 mA max.
Anywhere not directly subject to water or rain
Stripe top or stripe bottom
-5° to 55°C (23° to 131°F)
-25° to 70°C (-13° to 158°F)
45% to 85% RH without condensation
30% to 90% RH
10 to 55 Hz, 2 mm double amplitude, for 30 minutes in X, Y, and Z directions
300 m/sec
2
(30 G) in each of X, Y, and Z directions
247L x 106W x 92H mm (9.72L x 4.17W x 3.62H in)
222L x 98W x 92H mm (8.74L x 3.86W x 3.62H in)
Approx. 1.9 kg (4.2 lbs) when fully equipped
