QFN-28 to DIP-28 SMT Adapter (0.5 mm pitch, 5 x 5 mm body)
DIMENSIONS
REF.
A
A2
B
C
D
E
F
G
H
MIN.
mm
TYP.
4.00
4.00
1.50
0.30
0.20
0.50
MAX.
MIN.
inches
TYP.
MAX.
0.300
0.100
0.025
Top View (SMT Footprint)
B
A
C
E
D
A2
(Representative drawing only - not to scale)
1
© 2009 Proto Advantage, a Concept to Life Solutions Inc. Company
Bottom View (DIP Pins)
F
H
G
(Representative drawing only - not to scale)
Side View (DIP Pins)
F
(Representative drawing only - not to scale)
