“Stay Connected”
with
®
Liquid Tight Cordgrips
Heyco Original Series-35 Liquid Tight Cordgrips
Straight-Thru, NPT Hubs
•
Wide range of approved cable
diameters.
•
IP 68 rated.
•
Acme threads on body prevent
skipping and speed installation.
•
For use in clearance or threaded holes.
•
All nylon construction with TPE sealing
gland resists salt water, weak acids,
gasoline, alcohol, oil, grease, and
common solvents. (This feature is not
assessed by UL.)
•
Multiple sizes for flexible cord
diameters ranging from .069˝
(1,8 mm) to 1.000˝ (25,4 mm). For
larger sizes, see Heyco-Tite Liquid
Tight Cordgrips on page 3-1.
•
We recommend using the cordgrip
with the smallest maximum diameter
that will fit your application. Cable
ranges listed are for the maximum
IP68 sealing range. Contact Heyco
for UL approved 514B cable ranges.
•
Locknuts not included.
For nylon
locknut specifications or to order
locknuts separately, see page 3-47.
•
For Heyco Liquid Tight Threaded
Plugs, see page 3-51.
•
Consult Heyco for cordgrips molded
in other colors.
PART NO. DESCRIPTION
Locknuts
Minimum Maximum Not Included*
Black Gray
in. mm.
in.
mm.
4,7
3458 3459
7,9
3228 3229
RLTF 3/8
LTF 3/8
LTF 1/2
LLTF 1/2
MRLTF 1/2
MLTF 1/2**
RLTF 3/4
LTF 3/4
LTF 1
.069 1,8 .187
.115 2,9 .312
CABLE DIA. RANGE
or
PART DIMENSIONS
A
B
C
D
E
Clearance Max. O.A. Thread
Wrenching Nut
Hole Dia. Length
Length
Thk.
Flat Size
in.
mm.
in. mm. in. mm. in. mm. in.
mm.
®
.670 17,0 1.49 37,8 .53 13,5 .20 5,1
.875 22,2 1.72 43,7 .62 15,7 .20 5,1
.75 19,1
.95 24,1
NEW!
NEW!
.170 4,3 .450 11,4
3231 3232
.230 5,8 .546 13,9
3200 3201
.250 6,4 .485 12,3
3204 3205
.450 11,4 .709 18,0
3202 3203
.250 6,4 .485 12,3
3460 3461
.450 11,4 .709 18,0
3234 3235
.590 15,0 1.000 25,4
8437 8438
.875 22,2 1.83 46,5 .62 15,7 .23 5,8 1.05 26,7
.875 22,2 1.97 50,0 .63 16,0 .23 5,8 1.30 33,0
1.068 27,1 1.97 50,0 .63 16,0 .23 5,8 1.30 33,0
1.350 34,3 2.42 61,5 .75 19,1 .28 7,1 1.65 41,9
Standard colors black and gray.
*To order Nylon or Metal Locknuts separately, see pages 3-47 and 3-48.
**For cable diameters greater than .600˝, the insulating jacket must be stripped back. Reference customer drawing 3202/3203.
For larger sizes, see
Heyco-Tite
Liquid Tight Cordgrips on page 3-1.
Acme threads
prevent skipping,
speed installation.
TPE compression
gland for sealing.
Domed sealing nut
resists snags, sheds
contaminants.
Internal ratchet
provides self-locking
against vibration.
Collet design of
body accommodates
various size cords,
cables, tubing.
Special contour
provides light seal
at mounting panel
without O-ring.
B
D***
C
A
E
SEALING NUT
SUGGESTED CLEARANCE HOLE
FOR NONTHREADED MOUNTING
Consult Heyco for your alternate material requirements!
Material
Certifications
Nylon 6/6 with TPE Sealing Gland
Listed under Underwriters’ Laboratories File E51579
Recognized Under the Component Program of Underwriters’ Laboratories File E51579
Certified by Canadian Standards Association File 93876C
94V-2
Static -40°F (-40°C) to 239°F (115°C)
Dynamic -4°F (-20°C) to 212°F (100°C)
IP 68 (70 PSI, 5 BAR)
Quick
Specs
3-19
Flammability Rating
Temperature Range
IP Rating
1-800-526-4182 • 732-286-1800 (NJ) • FAX: 732-244-8843 • www.heyco.com
