Open Construction
Wirewound Surface Mount Inductors
RF INDUCTORS
Physical Parameters
Inches
A
0.090 Max.
B
0.068 Max.
C
0.060 Max.
D
0.050 (Ref. only)
E
0.018 (Ref. only)
F
0.040 (Ref. only)
G
0.070
H
0.040
I
0.030
Millimeters
2.29 Max.
1.73 Max.
1.52 Max.
1.27 (Ref. only)
0.44 (Ref. only)
1.03 (Ref. only)
1.78
1.02
0.76
Operating Temperature Range
–40°C to +125°C
Inductance and Q
tested on HP4291A using
HP16193A test fixture, or equivalent
Packaging
Tape & reel (8mm): 7" reel,
2000 pieces max.
-2N8K
-3N0K
-3N3K
-5N6K
-6N8K
-7N5K
-8N2K
-10NK
-12NK
-15NK
-18NK
-22NK
-24NK
-27NK
-33NK
-36NK
-39NK
-43NK
-47NK
-56NK
-68NK
-82NK
-91NK
-101K
-111K
-121K
-151K
-181K
-221K
-241K
-271K
-331K
-391K
-471K
-561K
-621K
-681K
-751K
-821K
-102K
-122K
-152K
-182K
-222K
-272K
2.8
3.0
3.3
5.6
6.8
7.5
8.2
10
12
15
18
22
24
27
33
36
39
43
47
56
68
82
91
100
110
120
150
180
220
240
270
330
390
470
560
620
680
750
820
1000
1200
1500
1800
2200
2700
Optional Tolerances: 8.2nH & Lower J = 5%
All Other Values: J = 5% G = 2%
*Complete part # must include series # PLUS the dash #
LAND PATTERN
DIMENSIONS
For further surface finish information,
refer to TECHNICAL section of this catalog.
PAGE
12
www
.
delevan
.
com
E-mail: apisales@delevan.com
270 Quaker Rd., East Aurora NY 14052 • Phone 716-652-3600 • Fax 716-652-4814
IN
D
(n UCT
H) A
±1 NC
0% E
IN
D
FR UCT
EQ AN
UE CE
NC T
Q
Y EST
MI
(M
NI
Hz
MU
)
M
Q
TE
FR ST
EQ
UE
NC
Y
SR
(M
F
Hz
MI
)
NI
MU
DC
M
(M
MA RES
Hz
XI IST
)
MU A
CU M NC
R
( E
MA RE OH
NT MS
XI
MU R )
M ATI
(m NG
A)
DA
SH
NU
MB
ER
*
Series
0805R
0805
SERIES 0805 CERAMIC CORE
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
200
200
200
200
150
150
150
150
150
100
100
100
100
100
100
100
50
25
25
25
25
25
25
7.9
7.9
7.9
7.9
7.9
80
65
50
65
50
50
50
60
50
50
50
55
50
55
60
55
60
60
60
60
60
65
65
65
50
50
50
50
50
44
48
48
48
33
23
23
23
23
23
20
18
16
16
16
16
1500
1500
1500
1000
1000
1000
1000
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
250
250
250
250
250
250
250
250
250
100
50
50
50
50
50
50
25
25
7.9
7.9
7.9
7900
7900
6000
5500
5500
4500
4700
4200
4000
3400
3300
2600
2000
2500
2050
1700
2000
1650
1650
1550
1450
1300
1200
1200
1000
1100
920
870
850
690
650
600
560
375
340
220
200
200
200
100
100
100
80
60
50
0.06
0.06
0.08
0.08
0.11
0.14
0.12
0.10
0.15
0.17
0.20
0.22
0.22
0.25
0.27
0.27
0.29
0.34
0.31
0.34
0.38
0.42
0.48
0.46
0.48
0.51
0.56
0.64
0.70
1.0
1.0
1.4
1.5
1.7
1.9
2.2
2.2
2.3
2.35
2.50
2.50
2.50
2.50
2.70
2.95
800
800
600
600
600
600
600
600
600
600
600
500
500
500
500
500
500
500
500
500
500
400
400
400
400
400
400
400
400
350
350
310
290
220
210
210
190
180
180
170
170
170
170
160
150
