38-00-2417 datasheet, PDF - EEWORLD Datasheet

38-00-2417: DescriptionBoard Connector, 27 Contact(s), 1 Row(s), Female, IDC Terminal; CategoryThe connector; File Size143KB，2 Pages; ManufacturerMolex; Websitehttps://www.molex.com/molex/home

Download Datasheet Parametric Compare View All

38-00-2417 Overview

Board Connector, 27 Contact(s), 1 Row(s), Female, IDC Terminal

Parameter Name	Attribute value
Maker	Molex
Reach Compliance Code	unknown
Is Samacsys	N
Other features	POLARIZED
Connector type	BOARD CONNECTOR
Contact to complete cooperation	TIN (98)
Contact completed and terminated	TIN (98)
Contact point gender	FEMALE
DIN compliance	NO
Filter function	NO
IEC compliance	NO
JESD-609 code	e3
MIL compliance	NO
Manufacturer's serial number	7690S
Mixed contacts	NO
Installation type	CABLE
Number of rows loaded	1
Options	GENERAL PURPOSE
Termination type	IDC
Total number of contacts	27
UL Flammability Code	94V-2
Base Number Matches	1

	38-00-2417	38-00-2411	38-00-2415	38-00-2416	38-00-2418	38-00-2414
Description	Board Connector, 27 Contact(s), 1 Row(s), Female, IDC Terminal	Board Connector, 21 Contact(s), 1 Row(s), Female, IDC Terminal	Board Connector, 25 Contact(s), 1 Row(s), Female, IDC Terminal	Board Connector, 26 Contact(s), 1 Row(s), Female, IDC Terminal	Board Connector, 28 Contact(s), 1 Row(s), Female, IDC Terminal	Board Connector, 24 Contact(s), 1 Row(s), Female, IDC Terminal
Maker	Molex	Molex	Molex	Molex	Molex	Molex
Reach Compliance Code	unknown	unknown	unknown	unknown	unknown	unknown
Other features	POLARIZED	POLARIZED	POLARIZED	POLARIZED	POLARIZED	POLARIZED
Connector type	BOARD CONNECTOR	BOARD CONNECTOR	BOARD CONNECTOR	BOARD CONNECTOR	BOARD CONNECTOR	BOARD CONNECTOR
Contact to complete cooperation	TIN (98)	TIN (98)	TIN (98)	TIN (98)	TIN (98)	NOT SPECIFIED
Contact point gender	FEMALE	FEMALE	FEMALE	FEMALE	FEMALE	FEMALE
DIN compliance	NO	NO	NO	NO	NO	NO
Filter function	NO	NO	NO	NO	NO	NO
IEC compliance	NO	NO	NO	NO	NO	NO
MIL compliance	NO	NO	NO	NO	NO	NO
Manufacturer's serial number	7690S	7690S	7690S	7690S	7690S	7690
Mixed contacts	NO	NO	NO	NO	NO	NO
Installation type	CABLE	CABLE	CABLE	CABLE	CABLE	CABLE
Number of rows loaded	1	1	1	1	1	1
Options	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE
Termination type	IDC	IDC	IDC	IDC	IDC	IDC
Total number of contacts	27	21	25	26	28	24
UL Flammability Code	94V-2	94V-2	94V-2	94V-2	94V-2	94V-2
Is Samacsys	N	N	N	N	N	-
Contact completed and terminated	TIN (98)	TIN (98)	TIN (98)	TIN (98)	TIN (98)	-
JESD-609 code	e3	e3	e3	e3	e3	-
Base Number Matches	1	1	1	1	1	-
