“Stay Connected”
with
®
Liquid Tight Cordgrips
Heyco -Tite
Liquid Tight Cordgrips
Right Angle, NPT Hubs
with Integral Sealing Ring
The Ultimate in Liquid Tight Strain Relief Protection
Patented Fold Over Design
CABLE DIA. RANGE
PART NO.
Black
Gray
DESCRIPTION
A
or Clearance
Hole Dia.
®
NO O-RING
REQUIRED!
in.
mm.
PART DIMENSIONS
B
C
D
E
F
Right
Max O.A. Thread Sealing Wrenching
Angle
Length
Length
Nut
Nut
Height
(Closed)
Length
Flat Size
in. mm. in. mm. in. mm. in. mm. in. mm. in. mm.
.86 22,0 .63 16,0
.065 - .210 1,7 - 5,3
M4560 M4561
RLTCG 1/4 90
.115 - .250 2,9 - 6,4
M4562 M4563
LTCG 1/4 90
.065 - .230 1,7 - 5,8
M8560 M8561
RLTCG 3/8 90
.105 - .315 2,7 - 8,0
M8562 M8563
LTCG 3/8 90
.095 - .290 2,4 - 7,4
M4564 M4565
RLTCG 1/2 90
.170 - .450 4,3 - 11,4
M8564 M8565
LTCG 1/2 90
Standard colors black and gray.
.540 13,7 .69 17,5 1.67 42,5 .45 11,4
.680 17,3 .88 22,3 1.93 48,9 .49 12,4 1.07 27,1 .82 20,8
.875 22,2 1.06 26,9 2.41 61,2 .61 15,5 1.38 35,1 .98 24,9
D
F
A
NPT HUB
INTEGRAL SEALING RING
C
PART ACCOMMODATES
CABLE DIAMETERS
SHOWN IN CHART ABOVE
SUGGESTED
CLEARANCE HOLE
FOR NONTHREADED
MOUNTING
B
E
INTEGRAL SEALING RING
•
Cordgrip is molded in the open position
for ease of installation. After cable
insertion, the fitting snaps closed,
bending the cable without damage. This
assembly method saves considerable
time and money.
•
Part design provides liquid tight
integrity even in the open position.
•
Integral Sealing Ring ensures a
superior seal at the clearance or
threaded mounting hole location,
every time.
•
Widest range of approved cable
diameters.
•
IP 68 rated.
•
Approved for
NEMA 4, 4X, 6 and 6P
applications.
•
Acme threads on body prevent
skipping and speed installation.
•
Multiple sizes for flexible cord
diameters ranging from .065˝ (1,7 mm)
to .450˝ (11,4 mm).
•
We recommend using the fitting with
the smallest maximum diameter that
will fit your application.
•
Patented.
•
Locknuts not included.
For nylon
locknut specifications or to order
locknuts separately, see page 3-47.
•
For Heyco Liquid Tight Threaded Plugs,
see page 3-51.
•
Consult Heyco for cordgrips molded
in other colors.
Material
Certifications
Nylon 6/6 w/Buna N or TPE Sealing Gland
Listed under Underwriters’ Laboratories File E51579
Recognized under Components Program of Underwriters’ Laboratories
File E51579
Certified by Canadian Standard Association File 93876C
Approved for NEMA 4, 4X, 6 and 6P Applications
94V-2
Static -40°F (-40°C) to 239°F (115°C)
Dynamic -4°F (-20°C) to 212°F (100°C)
IP 68 (70 PSI, 5 BAR)
Flammability Rating
Temperature Range
IP Rating
Quick
Specs
3-8
