“Stay Connected with” HEYware
HEYClip Hinged Cable Holders
•
Lock securely and adhere to most
clean, dry surfaces.
•
Part No. 3309 maximum flat wire
height .50˝ (12,7 mm), width 1.25˝
(31,8 mm)
•
Part No. 3395 maximum flat wire
height .25˝ (6,4 mm), width 1.25˝
(31,8 mm)
•
Part No. 3397 maximum flat wire
height .25˝ (6,4 mm), width 2.50˝
(63,5 mm)
WIRE CAPACITY
PART
NO.
Natural
DESCRIPTION
A
Length
in.
mm.
CH H-37-111
CH H-55-75
CH HA-25-125*
CH HA-50-125*
CH HA-25-250
1.57
1.22
1.75
1.75
3.00
40,0
31,0
44,5
44,5
76,2
in.
.37 x 1.11
.55 x .75
.25 x 1.25
.50 x 1.25
.25 x 2.50
mm.
28,1 x 9,3
19,1 x 13,9
5,6 x 31,8
11,2 x 31,8
12,7 x 63,5
12136
12139
3395
3309
3397
™
ALL NEW
PRODUCT!
PART DIMENSIONS
B
C
D
Width
Height
MH Spacing
in.
mm.
in.
mm.
in.
mm.
.31
.31
.75
.75
.75
8,0
8,0
19,1
19,1
19,1
.52
.73
.50
.75
.50
13,3
18,6
12,7
19,1
12,7
.787
.630
20,0
16,0
Double Arrowhead Mount
For Panels from .030˝ (0,8 mm) to .039˝ (1,0 mm) Thick
For Panels up to .118˝ (3,0 mm) Thick
Adhesive Back Mount
Standard color Natural. *Standard color Gray.
C
B
A
HEYClip Hinged Edge Cable Holders
™
Designed for Rectangular Edge Slot or Through-Hole Mounting -
suitable for retrofit applications
•
Designed for rectangular mounting
hole or edge slot mounting.
•
Hinged latch design permits retrofitting
into pre-wired applications.
•
Route cables and protect them from
sharp edges.
WIRE
CAPACITY
in.
mm.
PANEL DIMENSIONS
Thru Hole or Edge Slot
X
Y
Z
W
in. mm. in. mm. in. mm. in. mm.
.98 25,0
Thickness
in.
mm.
3300
CH HE-25
PART DESCRIPTION
NO.
Natural
PART DIMENSIONS
A
in.
mm.
in.
B
mm.
.77 x 19,5 x .858 21,8 .421 10,7 .161 4,1
.20
5,2
.77 x 19,5 x
.870 22,0 .710 18,0 .200 5,0
.47 12,0
.031 - 0,8 -
.063 1,6
2,0
.020 - 0,5 -
.063 1,6
1.19 30,2 .47 12,0
1.02 26,0 .079
.98 25,0
3301
CH HE-22
1.22 31,0 .75 19,0
Standard color natural.
W
W
B
Y
Z
Y
Z
A
.26
(6,6 mm)
X
Through Hole
X
Edge Slot
CH HE Series
Quick
Specs
7-58
Material
Flammability Rating
Temperature Range
Nylon 6/6
94V-2
32°F (0°C) to 185°F (85°C)
