(3/7)
E M C
C o m p o n e n t s
Product compatible with RoHS directive
AEC-Q200
Common Mode Filters
For automobile signal line
FEATURES
Optimal common mode filter for removing noise without straining the transmission signal and for transmitting high-quality signals.
Optimal countermeasure for common mode noise induced during data transmission for digital signal processing such as in CAN-bus
systems.
SMD type structure makes it optimal for surface mounting.
APPLICATION
CAN-bus systems, etc,
PART NUMBER CONSTRUCTION
ZJYS81R5
Series
•
Type name
pr
od
uc
st ts
op w
pe il
d lb
pr e
od or
uc ha
tio ve
n
be
en
-
2P
L
25
T
-
Number of lines
2P
2 lines
Winding type
L
Non code
Split coil
Bifilar coil
Product internal
code
25
Packaging style
T
ø330mm reel
Package quantity
Individual weight
(pieces/reel)
1,500
（g）
0.4
Overview of ZJYS81R5 Type
G01
G01
Internal code
OPERATING TEMPERATURE RANGE, PACKAGE QUANTITY, PRODUCT WEIGHT
Temperature range
Operating
Storage
Type
temperature
temperature
（°C）
（°C）
ZJYS81R5
–40 to +125
–40 to +125
The Storage temperature range is for after the circuit board is mounted.
RoHS Directive Compliant Product: See the following for more details related to RoHS Directive compliant products. http://product.tdk.com/en/environment/rohs/
Halogen-free: Indicates that Cl content is less than 900ppm, Br content is less than 900ppm, and that the total Cl and Br content is less than 1500ppm.
Please be sure to request delivery specifications that provide further details on the features and specifications of the products for proper and safe use.
Please note that the contents may change without any prior notice due to reasons such as upgrading.
