Suppression Chokes
https://www.schurter.com /PG81_82
DLF
Linear Choke, flat design
Approvals and Compliances
Description
-
-
-
-
Linear choke
THT-terminals
Inductor horizontally positioned in housing
SMD version on request
Applications
-
-
-
-
-
Smoothing RFI suppression choke
RFI suppression choke
Chopper amplifiers
DC drives and stepper motor controls
Switching power supplies
Weblinks
pdf datasheet, html-datasheet, General Product Information, Distributor-
Stock-Check, Detailed request for product
Technical Data
Rated voltage
Rated Current
Rated inductance
Power Operating Frequency
Terminal Type
Weight
Material: Housing
Sealing Compound
up to 600 VDC
0.45 - 7 A @ Ta 70 °C
0.015 - 3 mH, Tol. ±15%
up to 20 kHz
THT
7 - 18 g
UL 94V-0
UL 94V-0
Isolation Voltage
Climatic Category
Allowable Operation Temp.
2 kV eff., winding to ambient
40/125/21 acc. to IEC 60068-1
-40 °C to 125 °C
Approvals and Compliances
Detailed information on product approvals, code requirements, usage instructions and detailed test conditions can be looked up in
Details about
Approvals
Application standards
Application standards where the product can be used
Organization
Design
Designed for applications acc.
Standard
IEC/UL 60950
Description
IEC 60950-1 includes the basic requirements for the safety of information
technologyequipment.
Compliances
The product complies with following Guide Lines
Identification
Details
CE declaration of conformity
Initiator
SCHURTER AG
Description
The CE marking declares that the product complies with the applicable
requirements laid down in the harmonisation of Community legislation on
its affixing in accordance with EU Regulation 765/2008.
EU Directive RoHS 2011/65/EU
The law SJ / T 11363-2006 (China RoHS) has been in force since 1 March
2007. It is similar to the EU directive RoHS.
On 1 June 2007, Regulation (EC) No 1907/2006 on the Registration,
Evaluation, Authorization and Restriction of Chemicals 1 (abbreviated as
"REACH") entered into force.
RoHS
China RoHS
REACH
SCHURTER AG
SCHURTER AG
SCHURTER AG
EMC Products
1
Suppression Chokes
https://www.schurter.com /PG81_82
DLF
All Variants
I
n
[A]
0.4
0.6
1.2
1.5
2
4
0.45
0.6
1
1.5
1.8
3
4.5
7
L
n
[mH]
1.5
0.65
0.17
0.11
0.06
0.015
3
3
1
0.5
0.3
0.1
0.05
0.02
R
cu
[mΩ]
2150
690
190
150
79
17
3300
1700
550
270
180
70
30.5
13
f
RES
[MHz]
0.5
1
2.8
8
12
28
-
0.3
0.8
1.2
3.3
7.5
-
20
Weight [g]
7g
7g
7g
7g
7g
7g
18 g
18 g
18 g
18 g
18 g
18 g
18 g
18 g
Housings
04-1
04-1
04-1
04-1
04-1
04-1
15-1
15-1
15-1
15-1
15-1
15-1
15-1
15-1
Packing unit [pcs.]
45
45
45
45
45
45
40
40
40
40
40
40
40
40
Order Number
DLF-18-0001
DLF-18-0002
DLF-18-0003
DLF-18-0004
DLF-18-0005
DLF-18-0006
DLF-28-0001
DLF-28-0002
DLF-28-0003
DLF-28-0004
DLF-28-0005
DLF-28-0006
DLF-28-0007
DLF-28-0008
Availability for all products can be searched real-time:https://www.schurter.com/en/Stock-Check/Stock-Check-
SCHURTER
The specifications, descriptions and illustrations indicated in this document are based on current
information. All content is subject to modifications and amendments. Information furnished is believed
to be accurate and reliable. However, users should independently evaluate the suitability and test each
product selected for their own applications.
EMC Products
3
30.11.2017
