22×16.5×16.5
Features
Patent No. 99204096.5
Small size, light weight, Low price.
Sensitive operation, good synchronism.
Low coil power consumption.
PC board mounting.
Suitable for electrical application, telecommunication, automatic control, wireless radio remote control and
sound control toy application.
Ordering Information
JZC-7F 10 DC12V S 0.6
1
2
3
4
5
4 Enclosure：S: Sealed type；NIL: Dust cover
5 Coil power consumption：0.5:0.5W；0.6:0.6W
1 Part number：JZC-7F（4099）
2 Contact Current：01:1A；05:5A；10:10A
3 Coil rated Voltage(V)：DC:3,6,9,12,24
Contact Data
Contact Arrangement
Contact Material
Contact Rating (resistive)
Max. Switching Power
Max. Switching Voltage
Contact Resistance or Voltage drop
Operation
Electrical
life
Mechanical
2A DPSTNO
f2B
DPSTNC
f2C
DPDT(B-M)
Ag CdO (Au clad) AgSnO
2
(Au clad)
0.5W:1A,2A,3A/277VAC,30VDC;
0.6W:3A,5A,10A/277VAC,30VDC
0.5W:90W 360VA; 0.6W:250W 1600VA
50VDC 380VAC
Max. Switching Current:10A
50m
Item 3.12 of IEC255-7
5
10
Item 3.30 of IEC255-7
7
10
Item 3.31 of IEC255-7
Coil Parameter
Coil voltage
VDC
Pickup
voltage
VDC(max)
(75%of rated
voltage )
2.25
4.50
6.75
9.00
18.0
2.25
4.50
6.75
9.00
18.0
release voltage
VDC(min)
(10% of rated
voltage)
0.3
0.6
0.9
1.2
2.4
0.3
0.6
0.9
1.2
2.4
Dash
numbers
Coil
resistance
±10%
Coil power
consumption
W
Operate
Time
ms
Release
Time
ms
Rated
003-500
006-500
009-500
012-500
024-500
003-600
006-600
009-600
012-600
024-600
3
6
9
12
24
3
6
9
12
24
Max.
3.9
7.8
11.7
15.6
31.2
3.9
7.8
11.7
15.6
31.2
18
72
162
288
1152
15
60
135
240
960
0.5
10
5
0.6
10
5
CAUTION
:
1.The use of any coil voltage less than the rated coil voltage will compromise the operation of the relay.
2.Pickup and release voltage are for test purposes only and are not to be used as design criteria.
73
Ambient Temperature
Relative Humidity
Mass
-40~70
85% (at 40)
12g
IEC68-2-3Test Ca
Qualification inspection:
Perform the qualification test as specified in the table
of IEC255-19-1 and minimum sample size 24.
Safety approvals
Safety approval
Load
UL&CUR
5A/277VAC 30VDC
Dimensions (Unit: mm)
mm
0.3
0.5
1.0
1.5
2.1
2.5
4.5
5.1
10.2
12.7
16.5
22
>àçÇá
Dimensions
Mounting (Bottom views)
0.012
0.020
0.039
0.059
0.083
0.098
0.177
0.201
0.401
0.500
0.650
0.886
Wiring diagram(Bottom views)
NOTES
1).Dimensions are in millimeter.
2).Inch equivalents are given for general information only.
