IDCS-2512
www.vishay.com
Vishay Dale
High Current, Surface Mount Inductors - Shielded
FEATURES
•
•
•
•
•
High energy storage
Low resistance
Magnetically shielded
Tape and reel packaging for automatic handling
Material categorization:
for definitions of compliance please see
www.vishay.com/doc?99912
ELECTRICAL SPECIFICATIONS
Inductance Range:
1.0 μH to 10 000 μH, tested at 0.1 V
RMS
Inductance Tolerance:
20 %, tighter tolerance available
upon request
Operating Temperature:
-40 °C to +125 °C
Resistance to Solder Heat:
260 °C for 10 s
MECHANICAL SPECIFICATIONS
Core:
ferrite
Wire:
enamelled copper wire
Base:
ceramic
Terminals:
gold over nickel
Adhesive:
epoxy resin
RATED DC CURRENT (A)
(1)
3.0
2.8
1.8
1.6
1.4
1.2
1.0
0.80
0.70
0.60
0.50
0.40
0.30
0.26
0.22
0.20
0.19
0.18
0.15
0.12
0.10
0.08
0.06
0.04
0.02
STANDARD ELECTRICAL SPECIFICATIONS
INDUCTANCE (μH)
1.0
1.5
2.2
3.3
4.7
6.8
10
15
22
33
47
68
100
150
220
330
470
680
1000
1500
2200
3300
4700
6800
10 000
Note
(1)
40 °C temperature rise
TOLERANCE
± 20 %
± 20 %
± 20 %
± 20 %
± 20 %
± 20 %
± 20 %
± 20 %
± 20 %
± 20 %
± 20 %
± 20 %
± 20 %
± 20 %
± 20 %
± 20 %
± 20 %
± 20 %
± 20 %
± 20 %
± 20 %
± 20 %
± 20 %
± 20 %
± 20 %
TEST FREQUENCY L (kHz)
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
DCR MAX. ()
0.040
0.045
0.050
0.055
0.060
0.065
0.075
0.090
0.11
0.19
0.23
0.29
0.48
0.59
0.90
1.4
1.8
2.2
3.4
4.2
8.5
11.0
13.9
25.0
32.8
DIMENSIONS
in inches [millimeters]
A Max.
B
Max.
D
Max.
G
F
E
I
J
H
A
(Max.)
0.260
[6.60]
B
(Max.)
0.175
[4.45]
D
(Max.)
0.115
[2.92]
E
0.050
[1.27]
F
0.040
[1.02]
G
0.170
[4.32]
H
0.055
[1.40]
I
0.160
[4.06]
J
0.140
[3.56]
DESCRIPTION
IDCS-2512
MODEL
10 μH
INDUCTANCE VALUE
± 20 %
INDUCTANCE TOLERANCE
ER
PACKAGE CODE
e4
JEDEC LEAD (Pb)-FREE STANDARD
GLOBAL PART NUMBER
I
D
C
S
2
5
SIZE
1
2
E
R
1
0
INDUCTANCE
VALUE
0
M
INDUCTANCE
TOLERANCE
PRODUCT FAMILY
Revision: 21-Apr-17
PACKAGE
CODE
Document Number: 34009
1
For technical questions, contact:
magnetics@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
Legal Disclaimer Notice
