8230-22 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> inductor> 8230-22

8230-22: DescriptionFixed Inductors 1.2uH 10%; CategoryPassive components inductor; File Size216KB，2 Pages; ManufacturerBourns; Websitehttp://www.bourns.com

Download Datasheet Parametric View All

8230-22 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	8230-22	-	-	View	Buy Now

8230-22 Overview

Fixed Inductors 1.2uH 10%

8230-22 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	Bourns
Reach Compliance Code	compliant
ECCN code	EAR99
structure	Epoxy Coated
core material	IRON
DC Resistance	0.18 Ω
Nominal inductance(L)	1.2 µH
Inductor Applications	RF INDUCTOR
Inductor type	GENERAL PURPOSE INDUCTOR
Lead diameter	0.508 mm
Lead length	33.27 mm
Manufacturer's serial number	8230
Number of functions	1
Number of terminals	2
Maximum operating temperature	105 °C
Minimum operating temperature	-55 °C
Package diameter	3.048 mm
Package length	7.62 mm
Package form	Axial
Minimum quality factor (at nominal inductance)	25
Maximum rated current	0.825 A
self resonant frequency	150 MHz
series	8230
Shape/Size Description	TUBULAR PACKAGE
shield	NO
surface mount	NO
Terminal location	AXIAL
Terminal shape	WIRE
Test frequency	7.9 MHz
Tolerance	10%
Base Number Matches	1

Preview

Download Datasheet

View All

Features

■

Formerly

Applications

■

DC/DC converters

■

Power supplies

■

General use

model

■

Current rating up to 1.1 A

■

Inductance range: 1.0

μH

to 1,000

μH

■

RoHS compliant*

8230 Series Conformal Coated RF Choke

Electrical Speciﬁcations (@ 25 °C)

Inductance

Bourns Part No.

8230-94-RC

8230-96-RC

8230-00-RC

8230-02-RC

8230-04-RC

8230-06-RC

8230-08-RC

8230-10-RC

8230-12-RC

8230-14-RC

8230-16-RC

8230-18-RC

8230-20-RC

8230-22-RC

8230-24-RC

8230-26-RC

8230-28-RC

8230-30-RC

8230-32-RC

8230-34-RC

8230-36-RC

8230-38-RC

8230-40-RC

8230-42-RC

8230-44-RC

8230-46-RC

8230-48-RC

8230-50-RC

8230-52-RC

8230-54-RC

8230-56-RC

8230-58-RC

8230-60-RC

8230-62-RC

8230-64-RC

8230-66-RC

8230-68-RC

8230-70-RC

8230-72-RC

8230-74-RC

8230-76-RC

8230-78-RC

8230-80-RC

8230-82-RC

8230-84-RC

8230-86-RC

8230-88-RC

8230-90-RC

8230-92-RC

(μH)

0.10

0.12

0.15

0.18

0.22

0.27

0.33

0.39

0.47

0.56

0.68

0.82

1.0

1.2

1.5

1.8

2.2

2.7

3.3

3.9

4.7

5.6

6.8

8.2

100

120

150

180

220

270

330

390

470

560

680

820

1,000

Tol. (%)

±10

Min.

Test

Frequency

(MHz)

7.9

2.5

0.79

SRF

(MHz)

Min.

690

650

600

550

510

430

410

380

340

300

275

250

230

150

140

125

115

100

9.0

8.0

4.0

6.6

6.0

5.0

4.2

3.8

3.4

DCR

(Ω)

Max.

0.07

0.08

0.10

0.12

0.14

0.16

0.20

0.30

0.35

0.50

0.60

0.85

1.00

0.18

0.22

0.30

0.40

0.50

0.85

1.0

1.2

1.8

2.0

2.7

3.7

2.7

2.8

3.1

3.3

3.5

3.4

3.6

4.5

5.7

6.7

7.3

8.0

Idc

(mA)

1100

1010

935

875

780

640

590

495

450

380

350

825

745

640

550

495

380

350

320

260

245

210

180

210

205

195

190

185

187

180

165

145

135

130

125

Core

Material

Phenolic

Ferrite

General Speciﬁcations

Temperature Rise ................ 35 °C at Idc

Operating Temperature

................................ -55 °C to +105 °C

Storage Temperature

................................ -55 °C to +105 °C

Dielectric Strength ................... 500 Vrms

Materials

Core ................................See value table

Wire ............................ Enameled copper

Terminal Coating................................. Sn

Coating .................................Epoxy resin

Packaging

Standard..................1000 pcs. per bag

Optional ......5000 pcs. per 14-inch reel

How to Order

8230 - 22 - __ - RC

Model

Value Code

(See table)

Packaging Code

Blank = 1000 pcs./bag

TR = 5000 pcs./14-inch reel

Compliance Code

RC = RoHS compliant*

Examples:

• 8230-22-RC = 1.20 mH packaged

1000 pcs./bag.

• 8230-50-TR-RC = 18 mH packaged

5000 pcs./14-inch reel.

Electrical Schematic

*RoHS Directive 2002/95/EC Jan. 27, 2003 including annex and RoHS Recast 2011/65/EU June 8, 2011.

Speciﬁcations are subject to change without notice.

Customers should verify actual device performance in their speciﬁc applications
