SERIES:
VSK-S25-T
│
DESCRIPTION:
AC-DC POWER SUPPLY
FEATURES
• up to 25W continuous power
• compact chassis mount design
•
•
•
•
•
universal input (85~264 Vac / 100~370 Vdc)
single, regulated output from 5~48 Vdc
over voltage, over current, and short circuit protections
UL/cUL safety approvals
efficiency up to 87%
MODEL
VSK-S25-5U-T
VSK-S25-9U-T
VSK-S25-12U-T
VSK-S25-15U-T
VSK-S25-24U-T
VSK-S25-48U-T
Notes:
output
voltage
(Vdc)
output
current
max
(A)
output
power
max
(W)
ripple
and noise
1
typ
(mVp-p)
efficiency
typ
(%)
5
9
12
15
24
48
4.1
2.5
2.1
1.6
1.1
0.5
20.5
22.5
25
25
25
25
50
50
50
50
50
50
79
81
83
84
85
87
1. Ripple and noise are measured at 20 MHz BW by “parallel cable” method with 1 uF ceramic and 10 uF electrolytic capacitors on the output.
PART NUMBER KEY
VSK-S25 -
XXU
- T
Base Number
Output Voltage
cui.com
For more information, please visit the
product page.
CUI Inc
│
SERIES:
VSK-S25-T
│
DESCRIPTION:
AC-DC POWER SUPPLY
date
06/11/2015
│
page
2 of 7
INPUT
parameter
voltage
frequency
current
inrush current
leakage current
input fuse
at 115 Vac
at 230 Vac
at 115 Vac
at 230 Vac
at 230 Vac, 50 Hz (RMS)
3.15 A/250 V, slow-blow type (included on chassis)
16
30
0.1
conditions/description
min
85
100
47
typ
max
264
370
63
600
340
units
Vac
Vdc
Hz
mA
mA
A
A
mA
OUTPUT
parameter
conditions/description
5 Vdc output model
9 Vdc output model
12 Vdc output model
15 Vdc output model
24 Vdc output model
48 Vdc output model
at full load
at 10~100% load
±0.5
±1
±2
±10
at 115 Vac
at 230 Vac
15
80
65
±0.02
min
typ
max
12,000
5,600
5,400
2,400
1,400
800
units
μF
μF
μF
μF
μF
μF
%
%
%
%
ms
ms
kHz
%/°C
capacitive load
line regulation
load regulation
voltage set accuracy
adjustability
hold-up time
switching frequency
temperature coefficient
PROTECTIONS
parameter
over current protection
short circuit protection
conditions/description
auto restart
continuous, auto restart
5 Vdc output model
9 Vdc output model
12 Vdc output model
15 Vdc output model
24 Vdc output model
48 Vdc output model
7.5
12
20
20
30
60
Vdc
Vdc
Vdc
Vdc
Vdc
Vdc
min
110
typ
max
units
%
over voltage protection
SAFETY & COMPLIANCE
parameter
isolation voltage
safety approvals
safety class
conducted emissions
radiated emissions
ESD
radiated immunity
EFT/burst
conditions/description
input to output for 1 minute
input to ground for 1 minute
UL60950-1, CE
class I
CISPR22/EN55022, Class B
CISPR22/EN55022, Class B
IEC/EN61000-4-2 Class B, contact ±6 kV/air ±8 kV
IEC/EN61000-4-3 Class A, 10V/m
IEC/EN61000-4-4 Class B, ±2 kV
IEC/EN61000-4-4 Class B, ±4 kV (external circuit required, see figure 2)
min
3,000
2,000
typ
max
units
Vac
Vac
cui.com
For more information, please visit the
product page.
CUI Inc
│
SERIES:
VSK-S25-T
│
DESCRIPTION:
AC-DC POWER SUPPLY
date
06/11/2015
│
page
3 of 7
SAFETY & COMPLIANCE (CONTINUED)
parameter
surge
conducted immunity
PFM
voltage dips & interruptions
MTBF
RoHS
conditions/description
min
typ
max
units
IEC/EN61000-4-5 Class B, ±1 kV/±2 kV
IEC/EN61000-4-5 Class B, ±2 kV/±4 kV (external circuit required, see figure 2)
IEC/EN61000-4-6 Class A, 10 Vr.m.s
IEC/EN61000-4-8 Class A, 10 A/m
IEC/EN61000-4-11 Class B, 0%-70%
as per MIL-HDBK-217F at 25°C
2011/65/EU
300,000
hrs
ENVIRONMENTAL
parameter
operating temperature
storage temperature
storage humidity
non-condensing
conditions/description
see derating curves
min
-40
-40
typ
max
70
105
95
units
°C
°C
%
DERATING CURVES
load vs. ambient temperature
(at 100~240 Vac)
100
80
60
40
20
load vs. input voltage (Vac)
(at 25°C)
100
75
60
100
75
60
load vs. input voltage (Vdc)
(at 25°C)
~
~
Safe operating area
40
20
120
~
~
Load (%)
Load (%)
~
~
Safe operating area
Safe operating area
40
20
~
~
~
~
Load (%)
-40
-10
50
70
Ambient Temperature (°C)
85
95 100 105
115
125
235 240 245
255
264
100
~
~
340
370
Input Voltage (Vac)
Input Voltage (Vdc)
cui.com
For more information, please visit the
product page.
CUI Inc
│
SERIES:
VSK-S25-T
│
DESCRIPTION:
AC-DC POWER SUPPLY
date
06/11/2015
│
page
4 of 7
MECHANICAL
parameter
dimensions
case material
weight
cooling
convection cooling
conditions/description
96.10 x 54.00 x 32.00 (3.783 x 2.126 x 1.259 inch)
UL94V-0
170
g
min
typ
max
units
mm
MECHANICAL DRAWING
units: mm[inches]
tolerance: ±0.50[±0.020]
wire range: 24~12 AWG
PIN CONNECTIONS
PIN
1
2
3
4
5
6
7
8
FUNCTION
GND
AC(N)
AC(L)
-Vo
NC
TRIM
NC
+Vo
Top View
Side View
cui.com
For more information, please visit the
product page.
CUI Inc
│
SERIES:
VSK-S25-T
│
DESCRIPTION:
AC-DC POWER SUPPLY
date
06/11/2015
│
page
5 of 7
TYPICAL APPLICATION CIRCUIT
Figure 1
AC (L)
FU S E
AC(L)
MO V 1
+Vo
C1
C2
T VS
LO AD
AC D C
AC(N)
-Vo
AC (N)
Table 1
Recommended External Circuit Components
MODEL
VSK-S25-5U-T
VSK-S25-9U-T
VSK-S25-12U-T
VSK-S25-15U-T
VSK-S25-24U-T
VSK-S25-48U-T
Note:
FUSE
1
3.15A/250V
3.15A/250V
3.15A/250V
3.15A/250V
3.15A/250V
3.15A/250V
MOV1
S14K350
S14K350
S14K350
S14K350
S14K350
S14K350
C1
1µF
1µF
1µF
1µF
1µF
1µF
C2
330μF
330μF
330μF
330μF
120μF
68μF
TVS
SMBJ7.0A
SMBJ12A
SMBJ20A
SMBJ20A
SMBJ30A
SMBJ64A
1. Fuse included on chassis
EMC RECOMMENDED CIRCUIT
Figure 2
FUSE
AC( L)
CY1
MOV1
CX
CY2
LDM
LCM
AC(L)
+Vo
C1
C2
TVS1
RL
+
ACDC
-Vo
AC(N)
AC(N)
Table 2
Recommended External Circuit Components
MOV1
CY1, CY2
CX
LCM
LDM
Note:
Also refer to Table 1
S14K350
1000pF/400Vac
0.1μF/275Vac
10mH
4.7μH/2A
